Opel Frontera UBS. Service manual - part 1634
8D–214
WIRING SYSTEM
Parts Location (RHD)
Legend
(1) G-9(2) High Mounted Stoplight(3) B-13 or B-14(4) H-32(5) Stoplight-RH (Body)(6) R-12(7) Stoplight-RH (Bumper)
(8) F-8(9) F-7
(10) Stoplight-LH (Bumper)(11) H-33(12) H-37(13) Stoplight-LH (Body)(14) R-13(15) R-3, R-4
1
2
3
4
5
6
8
7
9
10
11
12
13
14
15
D08RW877
