8D–182
WIRING SYSTEM
Interior Illumination Light
General Description
The circuit consists of a lighting switch, tail relay,
illumination controller and illumination lights.
All these lights come on when the lighting switch is
turned on with the switch turned to either parking or
headlight position.
The brightness of illumination lights except the ones
for ashtray, glove box and vanity mirror, can be
adjusted by the illumination controller.
