Opel Frontera UBS. Service manual - part 1593
8D–50
WIRING SYSTEM
Cable Harness Routing (LHD) – 3
1
2
3
4
5
6
7
8
9
10
11
D08RWB02
Legend
(1) H-39(2) Tail Gate Harness (RH)(3) Chassis Harness(4) Tail Gate Harness (LH)(5) RR Body Harness
(6) H-33(7) H-37, H-38(8) R-3, R-4(9) RR Body Harness
(10) H-31, H-32, H-46(11) Body Harness
