DRIVE LINE CONTROL SYSTEM (TOD) 4B2–84 Chart H lighting switch circuit Function of circuit Reads in the status of lighting switch and reduces the indicator brightness at night. Fail condition Even if the lighting switch is pressed on and off, brightness does not change. Indicator lamp status Transfer position All position (example TOD mode) D04RW056 |
