Opel Frontera UBS. Service manual - part 1560





7C–2

CLUTCH

General Description

Clutch

(6VE1)

A07RW046

For 6VE1 (3.5L) and 4JX1 (3.0L) engine models, the
pull-type clutch is employed.  The pull-type clutch is

disengaged by pulling the release lever (release bearing)
to disengage the pressure plate.

CLUTCH

7C–3

Master Cylinder

(6VE1 LHD)

A07RW007

(6VE1 RHD)

A07RW066

7C–4

CLUTCH

(4JX1)

A07RW067

Damper Cylinder

(Except 6VE1 LHD)

A07RS004

In order to reduce the occurrence of noises at the clutch
hydraulic system, the damper cylinder is used in the

clutch hydraulic line between the master cylinder and
slave cylinder.

CLUTCH

7C–5

Slave Cylinder

A07RS005

Pressure Plate Assembly

A07RS006
