7A–154 AUTOMATIC TRANSMISSION (AW30-40LE) 248RY00051 248RY00052 248RY00053 248RY00054 Important operations Check operation of No.1 one–way clutch Hold the planetary sun gear and turn the second brake 3. Oil seal ring (Metal) Remove two oil seal rings. 4. Snap ring Remove the snap ring with snap ring pliers. INSPECTION AND REPAIR Check planetary sun gear bushing Using a dial indicator, measure the inside diameter of the If the inside diameter is greater than the maximum, replace mm (in.) Maximum inside diameter 27.08 (1.0661) |
