7A–134 AUTOMATIC TRANSMISSION (AW30-40LE) 248RY00028 248RY00029 248RY00061 248RY00002 Important operations Remove direct clutch drum assembly from forward clutch Check piston stroke of direct clutch (C-2) Using a dial indicator, measure the direct clutch piston 2 , 57– 114 psi or 392– 785 kPa) as shown. 5. Snap ring Place special tool and a suitable ring on the spring retainer mm (in.) Piston stroke 1.6– 1.9 (0.0630– 0.0748) |
