7A–118 AUTOMATIC TRANSMISSION (AW30-40LE) 252RY00026 252RY00027 252RY00028 252RY00029 15. OD one-way clutch Remove OD one-way clutch with outer race. INSPECTION AND REPAIR Check discs Using a micrometer, measure the thickness of the discs. If the thickness is less than the minimum, replace the disc. Check piston return spring Using calipers, measure the free length of the return spring. Check OD direct clutch piston Check that check ball is free by shaking the piston. mm (in.) Minimum thickness 1.84 (0.0724) mm (in.) Standard length 15.8 (0.622) |
