6E–326 ENGINE DRIVEABILITY AND EMISSIONS 4. Pull the relay straight up and out of the fuse and relay box. TS23986 Installation Procedure 1. Insert the relay into the correct place in the fuse and relay box with the catch slot facing forward. 2. Press down until the catch engages. D An audible “click” will be heard. 3. Install the fuse and relay box cover. TS23986 EVAP Canister Hoses Service Information To view the routing of the EVAP canister hoses, refer to EVAP Canister Removal Procedure 1. Disconnect the negative battery cable. 014RW145 3. Remove the retaining two bolts on the mounting bracket and slide the canister out of mounting 014RW146 Inspection Procedure 1. Inspect the hoses for cracks and leaks. |
