6A–83 ENGINE MECHANICAL D Attach the piston to the connecting rod with the 015RS036 D With 5–8840–0551–0 Piston pin service set and a NOTE: Heat the connecting rod small end to a suitable 015RX001 Legend (1) Press Ram 4. Install piston ring with the piston ring expander. The compression ring must be set with the T mark (1) Marked T : No.1 Compression ring Marked T2 : No.2 Compression ring 015RS027 D Install piston rings in the following sequence. 1. Oil ring 1. Expander ring 2. 2nd compression ring D The compression rings must be set with the T or T2 Marked T : No.1 Compression ring Marked T2 : No.2 Compression ring D After installation, apply engine oil to the entire 015RS038 5. Install piston and connecting rod assembly. D Insert the bearings into the connecting rods and |
