4A2A–8 DIFFERENTIAL (REAR 220mm) Differential Assembly Differential Assembly and Associated Parts 425RW055 Legend (1) Bolt and Nut (3) Parking Brake Cable Removal 1. Jack up and support the frame with stands. Steering section. 3. Drain the differential oil. Shaft in this section. 5. Remove the ABS speed sensor(ABS model only). Refer to 4–Wheel Anti–lock Brake System (ABS) in 6. Remove the parking brake cable fastening clip and disconnect the equalizer section. Refer to Parking 7. Remove the bearing holder fixing nuts. the oil seal by axle shaft. 9. Remove differential carrier mounting bolts and nuts. 10. Remove differential assembly. |
