POWER ASSISTED BRAKE SYSTEM 5C – 13 CHECKING BRAKE PEDAL HEIGHT The push rod serves as the brake pedal stopper when Adjust Brake Pedal the pedal is fully returned by the pedal return Pedal Free Play (L1) mm (in) 6 – 10 (0.23 – 0.39) Pedal Height (L2) mm (in) LHD RHD 208 – 218 211 – 221 (8.19 – 8.58) (8.31 – 8.70) NOTE: 2. If the measured value is not within the above range, adjust the brake pedal as follows: away from the brake pedal. d) Loosen the lock nut on the push rod. by rotating the push rod in the appropriate f) Tighten the lock nut to the specified torque. Lock Nut Torque N·m (kg·m/lb·ft) 20 (2.0 / 15) g) Adjust the stop light switch to the specified clearance (between switch housing and brake Clearance mm (in) 0 – 0.2 (0 – 0.008) NOTE: h) Tighten the stop light switch lock nut. Connect the stop light switch connector. Switch Floor panel (L3) (A) (L2) (L1) Lock nut (A) |
