Opel Frontera UBS. Service manual - part 1074
4D2–12 TRANSFER CASE (TOD)
Transfer Cover Assembly
Disassembled View
261RW007
Legend
(1) Coil Assembly(2) Snap Ring(3) Ball Bearing
(4) Speed Gear and Tone Wheel(5) Ball Bearing(6) Transfer Cover Assembly(7) Front and Rear Speed Sensors
Disassembly
1. Using snap ring pliers, remove the snap ring.
261RW047
