4C–45 DRIVE SHAFT SYSTEM Universal Joint Reassembly 1. Install spider to flange yoke. Be sure to install the spider by aligning the setting marks made during 2. Apply a molybdenum–disulfide grease or a multi–purpose type grease NLGI No. 2 to inside of the Grease Amount: Approx. 1.2 g (0.042 oz) 401RS011 3. Using either a mallet (or copper hammer) or a press, install the needle roller bearing into the yoke so that CAUTION: The needle roller bearing cannot be 401RS012 4. Align setting marks (1) and join the yokes. 401RS028 5. Install snap ring. NOTE: Discard used snap rings and install new ones. Snap ring thickness and Identification color NOTE: Be sure to use snap rings of the same thickness |
