4A2B–32 DIFFERENTIAL (REAR 244mm) 2. Measuring the overall length of the pressurering, friction disc and friction plate. D Mount the pinion shaft in the pressurering and then D Measure the length between the plates over the 425RS065 3. After measuring dimensions A,B,C and D, make adjustment in the following manner: D Measure the thickness (E) of the spring disc. × 2 discs 4. Select the friction disc & plate so as to satisfy the following equation: Thickness Backlash adjustment of the side gear in 1. Measuring the depth of the differential cage. (F–B): 95.63 mm (3.76 in) (G): 15.63 mm (0.62 in) 425RS066 2. Measuring the dimension between the thrust washers at both ends. D Assemble the side gear, pinion, pinion shaft, D Have the side gear contact to the pinion to make the D Measure the dimension (H) between thrust 425RS067 |
