VEHICLE SECURITY SYSTEM SYMPTOMS SEC-181 < SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B SEC N O P SYMPTOM DIAGNOSIS VEHICLE SECURITY SYSTEM SYMPTOMS Symptom Table INFOID:0000000007355821 *: Check the system is in the armed phase. Procedure Diagnostic procedure Refer to page Symptom 1 Vehicle security sys- Door switch Check door switch (LF, RF, LR, RR, back) Glass ajar switch Check glass hatch ajar switch Key cylinder switch Check key cylinder switch — Check Intermittent Incident Security indicator does not turn ON. Check vehicle security indicator Check Intermittent Incident 2 * Vehicle security Any door is opened. Check door switch (LF, RF, LR, RR, back) Glass ajar switch Check glass hatch ajar switch — Check Intermittent Incident 3 Vehicle security Horn alarm Check horn switch Check Intermittent Incident 4 Vehicle security sys- Key cylinder switch Check key cylinder switch Check Intermittent Incident August 2012 2012 Pathfinder 2012 Pathfinder |
