VEHICLE SECURITY SYSTEM SYMPTOMS SEC-109 < SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B SEC N O P VEHICLE SECURITY SYSTEM SYMPTOMS Symptom Table INFOID:0000000007355752 *: Check the system is in the armed phase. Procedure Diagnostic procedure Refer to page Symptom 1 Vehicle security sys- Door switch Check door switch (LF, RF, LR, RR, back) Glass ajar switch Check glass ajar switch Intelligent Key Check Intelligent Key system Key cylinder switch Check key cylinder switch — Check Intermittent Incident Security indicator does not turn ON. Check vehicle security indicator Check Intermittent Incident 2 * Vehicle security Any door is opened. Check door switch (LF, RF, LR, RR, back) Glass ajar switch Check glass ajar switch — Check Intermittent Incident 3 Vehicle security Horn alarm Check horn switch Check Intermittent Incident 4 Vehicle security sys- Intelligent Key Check Intelligent Key system Key cylinder switch Check key cylinder switch — Check Intermittent Incident August 2012 2012 Pathfinder 2012 Pathfinder |
