REFRIGERATION SYSTEM HA-21 < SYSTEM DESCRIPTION > C D E F G H J K L M A B HA N O P Rear A/C AWIIA1539GB 1. Rear high- and low-pressure A/C pipes 2. Rear heater core hoses 3. Underfloor rear high- and low-pres- 4. Rear expansion valve 5. Rear drain hose Vehicle front August 2012 2012 Pathfinder |
