DOOR DLK-199 < REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B DLK N O P 4. Remove the door-side hinge nuts, and the door assembly. Installation Installation is in the reverse order of removal. Align the front door. Refer to . REAR DOOR Removal 1. Remove the door finisher. Refer to INT-15, "Removal and Installation" . 2. Remove the inner seal. AV-38, "Removal and Installation" AV-260, "Removal and Installation of Rear Door Speaker" (BOSE AUDIO WITHOUT NAVIGATION) or AV-425, "Removal and Installation of Rear Door Speaker" (BOSE AUDIO WITH NAVIGATION). 4. Remove the rear door tweeter. Refer to AV-426, "Removal and Installation of Rear Tweeter" AUDIO WITH NAVIGATION). 5. Remove the rear door glass and regulator. Refer to GW-19, "Rear Door Glass Regulator" . 6. Remove the door harness. 8. Remove the door-side hinge nuts, and remove the door assem- bly. Installation Installation is in the reverse order of removal. Align the rear door. Refer to BACK DOOR Removal Door hinge nuts 24.5 N·m (2.5 kg-m, 18 ft-lb) LIIA1727E Check link to hinge pillar 14.7 N·m (1.5kg-m, 11ft-lb) LIIA1726E Door hinge nuts 25.8N·m (2.6Kg-m, 19 ft-lb) LIIA1727E August 2012 2012 Pathfinder 2012 Pathfinder |
