LIFTING MOTOR (FRONT) ADP-97 < DTC/CIRCUIT DIAGNOSIS > C D E F G H I K L M A B ADP N O P 1. Turn ignition switch OFF. 2. Disconnect driver seat control unit and lifting motor (front). 3. Check continuity between driver seat control unit harness con- nector and lifting motor (front) harness connector. 4. Check continuity between driver seat control unit harness con- nector and ground. Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness. 3. CHECK INTERMITTENT INCIDENT GI-37, "Intermittent Incident" . Is the inspection result normal? YES >> Replace driver seat control unit. Refer to NO >> Repair or replace the malfunctioning part. Driver seat control unit connector Terminal Lifting motor (front) connector Terminal Continuity B203 (A) 37 B206 (B) 1 Yes 45 5 Driver seat control unit connector Terminal Ground Continuity B203 (A) 37 No 45 ALJIA0472ZZ 2011 Pathfinder |
