CHASSIS AND BODY MAINTENANCE MA-27 C D E F G H I J K M A B MA 2006 Pathfinder Checking Front Final Drive Oil ELS001OV CAUTION: If using the vehicle for towing, the final drive oil must be replaced as specified. Refer to OIL LEAKAGE AND OIL LEVEL 1. Make sure that oil is not leaking from the final drive assembly or around it. 2. Check oil level from the filler plug hole as shown. CAUTION: Do not start engine while checking oil level. 3. Install the filler plug with a new gasket on it to the final drive CAUTION: Do not reuse gasket. Changing Front Final Drive Oil ELS001OW CAUTION: If using the vehicle for towing, the final drive oil must be replaced as specified. Refer to DRAINING 1. Stop the engine. 2. Remove the drain plug and gasket. Drain the gear oil. 3. Install the drain plug with a new gasket to the final drive asssem- . CAUTION: Do not reuse gasket. FILLING 1. Remove the filler plug and gasket. Fill with new gear oil until the 2. After refilling oil, check the oil level. Install the filler plug with a CAUTION: Do not reuse gasket. Checking Rear Final Drive Oil ELS001OX CAUTION: If using the vehicle for towing, the final drive oil must be replaced as specified. Refer to OIL LEAKAGE AND OIL LEVEL 1. Make sure that oil is not leaking from the final drive assembly or around it. LDIA0176E LDIA0175E Oil grade and capacity Refer to . LDIA0176E |
