CONSULT-II CHECKING SYSTEM GI-41 C D E F G H I J K L M B GI 2006 Pathfinder NOTE: Symptom Check item CONSULT-II cannot access ● CONSULT-II DLC power supply circuit (Terminal 8) and ground circuit (Terminal 4). For detailed cir- . ● CONSULT-II DLC cable and CONSULT-II CONVERTER. CONSULT-II cannot access ● CONSULT-II program card (Check the appropriate CONSULT-II program card for the system. ● Power supply and ground circuit for the control unit of the system (For detailed circuit, refer to wir- ● Open or short circuit between the system and CONSULT-II DLC (For detailed circuit, refer to wiring ● Open or short circuit in CAN or K communication line. Refer to LAN-3, "Precautions When Using . |
