(2) Apply 50 mm (2 in.) masking tape in 150 mm (6 in.) lengths along weatherstrips, weld seams or POSSIBLE CAUSE OF WIND NOISE • Moldings standing away from body surface can catch wind and whistle. • Gaps in sealed areas behind overhanging body flanges can cause wind-rushing sounds. • Misaligned movable components. • Missing or improperly installed plugs in pillars. • Weld burn through holes. STANDARD PROCEDURE STANDARD PROCEDURE - PLASTIC BODY There are many different types of plastics used in today’s automotive environment. We group plastics in Rigid Plastics: Examples of rigid plastic use: Fascias, Hoods, Doors, and other Body Panels, which include SMC, Semi - Rigid Plastics: Examples of semi-rigid plastic use: Interior Panels, Under Hood Panels, and other Body Trim Panels. Flexible Plastics: Examples of flexible plastic use: Fascias, Body Moldings, and upper and lower Fascia Covers. Repair Procedure: The repair procedure for all three categories of plastics is basically the same. The one difference is be specific for each substrate, rigid repair material Adhesion Promoter / Surface Modifier: Adhesion Promoters/Surface Modifiers are required for certain plastics. All three categories may have plastic identification and repair procedures. SAFETY PRECAUTION AND WARNINGS WARNING: • EYE PROTECTION SHOULD BE USED WHEN SERVICING COMPONENTS. PERSONAL INJURY CAN RESULT. • USE AN OSHA APPROVED BREATHING MASK WHEN MIXING EPOXY, GRINDING, AND SPRAYING • AVOID PROLONGED SKIN CONTACT WITH RESIN, PETROLEUM, OR ALCOHOL BASED SOL- • DO NOT VENTURE UNDER A HOISTED VEHI- CLE THAT IS NOT PROPERLY SUPPORTED ON STANDS. PERSONAL INJURY CAN RESULT. NOTE: • When holes must be drilled or cut in body pan- els, verify locations of internal body components • Do not use abrasive chemicals or compounds on undamaged painted surfaces around repair RIGID, SEMI-RIGID, AND FLEXIBLE PLASTIC PARTS TYPES CODE FAMILY NAME COMMON TRADE NAME TYPICAL APPLICATION ASA ACRYLONITRILE STYRENE LURAN S CONSOLES, GRILLES ABS ACRYLONITRILE BUTADI- TERLURAN 9 A” PILLARS, CONSOLES, GRILLES ABS/PC ABS/PC ALLOY PULSE, PROLOY, BAY- DOORS, INSTRUMENT PAN- VA BODY 23 - 3 |
