(14) Remove the transmission oil filter (1) and o-ring from the electrohydraulic control unit. (15) Clean the inside of the oil pan (3) of any debris. Inspect the oil pan gasket (2) and replace if (16) Install a new oil filter (1) and o-ring into the electrohydraulic control unit. (17) Install the oil pan (3) and gasket (2) onto the transmission. (18) Install the oil pan bolts (5) and retainers (4). Torque the bolts to 8 N·m (70 in.lbs.). (19) Lower the vehicle and add 7.0 L (7.4 qts.) of transmission fluid to the transmission. (20) Check the oil level (Refer to 21 - TRANSMIS- SION/AUTOMATIC - NAG1/FLUID AND FILTER - FREEWHEELING CLUTCH DESCRIPTION Freewheeling clutches (Fig. 154) are installed in the front planetary gear set between the sun gear The freewheel consists of an outer race (4), an inner race (7), a number of locking elements (3) and OPERATION The freewheeling clutch (Fig. 155) optimizes indi- vidual gearshifts. They lock individual elements of a If the inner race (7) of the freewheeling clutch is locked and the outer race (4) turns counter-clockwise Fig. 154 Freewheeling Clutch 1 - ROTATION DIRECTION “A 9 2 - ROTATION DIRECTION “B 9 3 - LOCKING ELEMENTS Fig. 155 Freewheeling Clutch 1 - ROTATION DIRECTION “A 9 2 - ROTATION DIRECTION “B 9 3 - LOCKING ELEMENTS VA AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION 21 - 135 |
