(10) Install and tighten the screw that secures the front seat belt lower anchor to the outboard side of (11) If the vehicle is so equipped, snap the plastic cover over the screw that secures the front seat belt (12) Do not reconnect the battery negative cable at this time. The supplemental restraint system verifi- FRONT SEAT BELT BUCKLE REMOVAL WARNING: To avoid personal injury or death, during following any seat belt service, carefully inspect all seat belts, buckles, mounting hardware, replacement parts listed in the DaimlerChrysler Mopar Parts Catalog. (1) On the driver side only, move the seat to its most forward position for easiest access to the seat (2) On the driver side only, remove the wire ties that secure the seat belt switch pigtail wire to the (3) On the driver side only, pull the seat belt switch pigtail wire out through the clearance hole in (4) If the vehicle is so equipped, unsnap and remove the plastic cover from the screw that secures (5) Remove the screw that secures the front seat belt buckle lower anchor to the inboard side of the (6) Remove the front seat belt buckle from the inboard side of the front seat frame. INSTALLATION WARNING: To avoid personal injury or death, during following any seat belt service, carefully inspect all seat belts, buckles, mounting hardware, replacement parts listed in the DaimlerChrysler Mopar Parts Catalog. (1) Position the front seat belt buckle to the inboard side of the front seat frame (Fig. 26). (2) Install and tighten the screw that secures the front seat belt buckle lower anchor to the inboard Fig. 26 Front Seat Belt Buckle Remove/Install 1 - SEAT RISER COVER PANEL VA RESTRAINTS 8O - 23 |
