Engine version factor (gasoline/diesel) National factor (The kilometer or mileage is coded in accordance with the national version.) Distance travelled : ASSYST is supplied with the 4 wheel speeds from the traction systems control module (N47) over the Time ASSYST is supplied with the time information from the clock integrated in the instrument cluster. ACTIVE SERVICE SYSTEM (ASSYST) SURVEY MODEL/ENGINE/SENSOR/INSTRUMENT CLUSTER - GF00.20-P-0003- The table below (status: March 1999) lists the various vehicle models with the different engines and the In addition, the table also indicates whether an instrument cluster with multifunction display is fitted. Model Engine Oil level sensor Multifunction display with engine 129 112, 113 103, 104, 119, 120 Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 - 140 - 104, 119, 120, 606 Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 - 163 112, 113, 612 111 Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 - 168 166, 668 - Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 - 170 112 Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 - 202 112, 113, 611 104, 111, 601, 604, 605 Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 - 208 112, 113 111 Oil sensor (oil level/temperature/quality, B40) Oil level indicator switch S43 Engine 112 only and Gulf States: engine 111 210 112, 113, 611 104, 111, 602, 605, 606 Oil sensor (oil level/temperature/quality, B40) Engines 112,113 Gulf States, , : on all engines fitted; others:
2004 Mercedes-Benz ML350 1998-2005 GENINFO Overall vehicle - 163 Chassis
