Mercedes-Benz ML320. Service manual - part 270





AUDIO 30 APS DIAGNOSIS, BASIC KNOWLEDGE - AD82.61-P-2001A

MODEL 163,168,170, 208, 210 with CODE (353) Audio 30 APS



Used:

Tread depth less than 5 mm



In order to avoid damage
to control modules,
connectors must only be
disconnected or
connected with "terminal
15R:OFF
 "







Local or atmospheric
influences can cause
disruption to radio or
satellite reception.
Satellite reception is
possible only in the open
air.







Position finding with
assistance of global
positioning system data
(in degrees of longitude
and latitude) takes place
within a period of 1 to
20min after "ignition: ON
".







The audio 30 APS is a
navigation system with
integrated radio and CD
player and
 . It also
provides an interface for
external audio
components via a digital
data bus (D2B). Existing
DMNL deals mainly with
navigation system.
Diagnosis of the
following systems: radio,
D2B, loudspeaker
system (LS), CD
changer and sound
system
 can be extracted
from the appropriate
DMNL.







Audio 30 APS operating

GF82.61-P-0002-03A



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



AUDIO 30 APS DIAGNOSIS, FUNCTION CHECK - AD82.61-P-3001A

MODEL 163,168,170, 208, 210 with CODE (353) Audio 30 APS

notes



Audio 30 APS location of
components

Model 163

GF82.61-P-0002-01D





Model 168

GF82.61-P-0002-01B





Model 170

GF82.61-P-0002-01A





Models 208, 210

GF82.61-P-0002-01C



Location and assignment
of cable and plug
connections

Model 163

GF00.19-P-1000E





Model 168

GF00.19-P-1000GC





Model 170

GF00.19-P-1000B





Model 208

GF00.19-P-1000D





Model 210

GF00.19-P-1000A



Overview of electrical
wiring diagrams

Model 163

PE82.00-P-1100E





Model 168

PE82.00-P-1100GC





Model 170

PE82.00-P-1100B





Model 208

PE82.00-P-1100D





Model 210

PE82.00-P-1100A



Connection and use of
test equipment



AD00.00-P-1000AZ



Diagnostic tools, Audio
30 APS



AD82.61-P-2001-01A



Variant coding, radio and
navigation unit



AD82.61-P-2001-03A



Connector assignment,
radio and navigation unit



AD82.61-P-2001-02A



Audio 30 APS diagnosis, basic
knowledge



AD82.61-P-2001A



See specified diagnosis
manuals for function checks on
the following systems: radio
(RD), AM/FM antenna systems
(ATS) and loudspeaker system
(LSA).







Fuses okay







Battery voltage 11-14 V







Function check





Scope of test

Action/prerequisites

Nominal value

Possible cause /



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



remedy

1 GPS reception

Vehicle outdoors under free
sky
Ignition: ON
Radio and navigation unit
(A2/56): ON
Press "I" button (info).
Wait a few minutes if
necessary.

The current location is
indicated in terms of
latitude and longitude,
e.g.:
LONGIT. 9:01.37E
LATIT. 48:42.17N In
addition, the number of
satellites received is
indicated.

 It is necessary to

receive at least 3 satellite
signals for two-
dimensional GPS location
finding.
Local or atmospheric
influences can cause
interruptions in the
reception of the GPS
signals.

AD82.61-P-5001A

2 Navigation

Ignition: ON
Radio and navigation unit
(A2/56): ON
If necessary: insert navigation
CD ROM into radio and
navigation unit (A2/56)
 .
Press "NAV" button.
Check GPS reception (see
above) Enter a destination in
the vicinity with the aid of the
"ADDRESS ENTRY" menu
and activate guidance feature
by selecting:
FASTEST ROUTE or
SHORTEST ROUTE or OWN
SETTINGS.
Drive vehicle along test route

Route calculation may take
up to 30 s.
Recommendations for
guidance or output on the
radio loudspeakers ( voice
output
 ) and on the A2/56
display with the aid of
route guidance symbols
pictograms ).
Pay particular attention to
the time the voice
messages are output (the
messages should not be
output too early or too
late). Also observe bar
graph display.

 If the vehicle is on a

"non-digitized" road
(company yard, parking
lot, country road) the
display "OFF ROAD"
appears. When driving
outside of the digitized
map boundaries the
display "OFF MAP"
appears.

AD82.61-P-5001A



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



AUDIO 30 APS DIAGNOSIS, DTC MEMORY - AD82.61-P-4002A

MODELS 163,168,170, 208, 210 with CODE (353) Audio 30 APS



Audio 30 APS
diagnosis, previous
knowledge



AD82.61-P-2001A



Connect hand-held-
tester (HHT), read out
diagnostic trouble
code memory

Model 163 up to 31.8.01, 168

AD00.00-P-2000-
03C






Models 170, 208, 210

AD00.00-P-2000-
03A




Communication
between the HHT and
all other D2B
components also
takes place via the
diagnostic interface
of the radio and
navigation unit
(A2/56)
 .
ForDTC's affecting
the digital data bus
(D2B)
 , theCD
changer (A2/6)
 and
the sound system ,
remedy measures are
given in the
corresponding
diagnosis manuals.

See also: Information/Communication
Diagnosis Manual Index 13.1 Digital
data bus (D2B)
See also: Information/Communication
Diagnosis Manual Index 6.1 Compact
disc player with CD changer

AD82.00-P-1000AZ
AD82.64-P-1000AZ



Fuses okay







Battery voltage 11-
14V







The RDS data
evaluation is
deactivated during
HHT diagnosis.







Diagnostic trouble
code memory






DTC

Possible cause

Note

Remedy

No fault code

No fault detected

Nevertheless if there is a complaint: ?
Audio 30 APS diagnosis,
troubleshooting

AD82.61-P-5001A

B1000

Internal error in radio
and navigation unit



A2/56



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me
