Mercedes-Benz ML320. Service manual - part 76





131

Controls in detail

Good visibility

Headlamp cleaning system*

The button is located on the right side of
the dashboard.

Headlamp washer button

Switch on ignition.

Briefly press the upper part of button.

The headlamps will be cleaned with a
high-pressure water jet.

Information on filling up the washer reser-
voir can be found in the “Operation” sec-
tion (

page 224).

Rear window wiper

The rear window wiper will also automati-
cally engage if the windshield wiper is en-
gaged and the gear selector lever is placed
in reverse.

Rear window wiper with rain sensor*

Rear window wiper intervals are controlled
automatically according to the amount of
water on the windshield and the speed of
the vehicle, if:

rear window wiper is switched on

front windshield wipers are switched to
intermittent wiping

The interval for the rear window wiper re-
mains constant when the windshield wiper
interval is ten seconds or more.

132

Controls in detail

Good visibility

Sun visor

The sun visors protect you from sun glare
while driving.

1 Mirror cover
2 Mounting

Swing sun visors down when you expe-
rience glare.

To use mirror, lift cover 1 up.

Illuminated vanity mirrors

Turn the key in steering lock to
position 1 (

page 33).

Lift cover up.

The lamp switches on.

Warning!

G

Do not use the vanity mirror while driving.

Keep the mirrors in the sun visors closed
while vehicle is in motion. Reflected glare
can endanger you and others.

i

If sunlight enters through a side win-
dow, disengage sun visor from
mounting 2 and pivot to the side.

133

Controls in detail

Good visibility

Rear window defroster

The rear window defroster uses a large
amount of power. To keep the battery
drain to a minimum, switch off the defrost-
er as soon as the rear window is clear. The
defroster is automatically deactivated
after approximately 6 to 17 minutes of
operation depending on the outside tem-
perature.

Activating

Switch ignition on.

Press button

F (

page 135).

The indicator lamp on the button
comes on.

Deactivating

Press button

F again.

The indicator lamp on the button goes
out.

Warning!

G

Any accumulation of snow and ice should be
removed from the rear window before driv-
ing. Visibility could otherwise be impaired,
endangering you and others.

!

If the rear window defroster switches
off too soon and the indicator lamp
starts flashing, this means that too
many electrical consumers are operat-
ing simultaneously and there is insuffi-
cient voltage in the battery. The system
responds automatically by deactivating
the rear window defroster.

As soon as the battery has sufficient
voltage, the rear window defroster au-
tomatically turns itself back on.

134

Controls in detail

Automatic climate control

Automatic climate control
