Mercedes-Benz ML320. Service manual - part 67





95

Controls in detail

Seats

Seats

Information on seat adjustment can be
found in the “Getting started” section
(

page 34).

Removing and installing front seat
head restraints

Information on head restraint adjustment
can be found in the “Getting started” sec-
tion (

page 34).

Front seat head restraints

Removing head restraints

Pull head restraint to its highest
position.

Push button 1 and pull out head
restraint.

Warning!

G

For your protection, drive only with properly
positioned head restraints.

Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an
accident or similar situation.

Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.

Do not interchange head restraints from
front and rear seat.

96

Controls in detail

Seats

Installing head restraint

Insert head restraint and push it down
to the stop.

Push button 1 and adjust head
restraint to the desired position
(

page 36).

Rear seat head restraints

Head restraint height

Raising:

Manually adjust the height of the head
restraint by pulling it upward.

Lowering:

To lower the head restraint, push
button 1 and press down on the head
restraint.

Head restraint tilt

Manually adjust the angle of the head
restraint.

Push or pull on the upper edge of the
head restraint cushion.

More informations on seats can be found
in the “Getting started” section
(

page 34).

Warning!

G

For your protection, drive only with properly
positioned head restraints.

Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an ac-
cident or similar situation.

Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.

97

Controls in detail

Seats

Removing and installing rear seat head
restraints

Removing rear seat head restraints

Pull head restraint to its highest
position.

Push button 1 and pull out head
restraint.

Installing rear seat head restraints

Insert head restraint and push it down
to the stop.

Push button 1 and adjust head
restraint to the desired position
(

page 36).

Stowing rear center head restraint

1 Rear center head restraint
2 Bar
3 Clip

Warning!

G

For your protection, drive only with properly
positioned head restraints.

Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an ac-
cident or similar situation.

Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.

Do not interchange head restraints from
front and rear seat.

i

For a better view toward the rear, you
can store the rear center head restraint
underneath the rear seat (

page 97).

컄컄

98

Controls in detail

Seats

Remove rear center head restraint
(

page 96).

If necessary, remove cargo floor plates,
see “Removing cargo floor plates”
(

page 162).

Slide rear seats forward, see “Adjusting
rear seat fore and aft” (

page 99).

Fold rear seat backrests down, see
“Folding down the backrest”
(

page 100).

From cargo compartment, attach rear
center head restraint 1 to underside
of rear center seat.

Make sure front side of head
restraint 1 is facing upward.

Press bar 2 on both sides into
clips 3.

Heated seats*

Both switches for the front seats are loca-
ted in the center console.

1 Normal heating
2 Rapid heating

Start the engine.

Switching on seat heating

Press upper switch position 1.

A red indicator lamp on the switch
lights up.

Switching off seat heating

Press upper switch position 1 again.

The indicator lamp on the switch turns
off.

Switching on rapid seat heating

Press lower switch position 2.

Both red indicator lamps on the switch
turn on.

i

The seat heater will be automatically
switched off after approximately
20 minutes.

i

The system switches over to normal
heating mode after approximately five
minutes. Only one red indicator lamp
remains on.

컄컄
