passenger-side air bag module squib connector. Remove 4 passenger-side air bag module mounting nuts. 2. To install, reverse removal procedure. Ensure passenger-side air bag module squib connector audibly clicks when connecting connector. Activate air bag system. Perform system operation check to ensure Removal & Installation (E Class) 1. Before proceeding, see SERVICE PRECAUTIONS . Disable air bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM . Remove ignition key. Remove 2 central mounting bolts for 2. If necessary to replace passenger air bag installation frame, remove 4 frame mounting bolts. Remove installation frame from vehicle. 3. To install air bag module or installation frame, reverse removal procedure. Activate air bag system. Perform system operation check to ensure system is functioning properly. See SYSTEM OPERATION Removal & Installation (S Class) 1. Before proceeding, see SERVICE PRECAUTIONS . Disable air bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM . Remove ignition key. Open glove box door. Remove 4 clips 2. Disconnect passenger-side air bag module squib connector. Remove 4 passenger-side air bag module mounting nuts. Remove passenger-side air bag module through glove box opening. Place module away 3. To install, reverse removal procedure. Ensure module squib connector audibly clicks when connecting connector. Activate air bag system. Perform system operation check to ensure system is functioning Removal & Installation (SL Class) 1. Before proceeding, see SERVICE PRECAUTIONS . Disable air bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM . Remove ignition key. Remove cover below instrument panel. 2. Remove air bag panel (3 Phillips screws and 2 hex bolts). Unplug connector at squib of passenger-side air bag unit. Remove mounting bolts. Pull off and take air bag out of panel opening. 3. To install air bag module, reverse removal procedure. Activate air bag system. Perform system operation check to ensure system is functioning properly. See SYSTEM OPERATION CHECK . Removal & Installation (CLK 320) 1. Before proceeding, see SERVICE PRECAUTIONS . Disable air bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM . Remove ignition key. Remove instrument panel. Disconnect 2. To install air bag module, reverse removal procedure. Activate air bag system. Perform system operation
1998 Mercedes-Benz ML320 AIR BAG RESTRAINT SYSTEM 1998 AIR BAG RESTRAINT SYSTEMS Mercedes-Benz
