Mazda MX-5 (2018 year). Manual - part 30





▼ Contact Authorized Mazda Dealer and Have Vehicle Inspected

If any of the following warning lights or the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.

Signal

Warning

Master Warning In-

dication/Warning

Light

*

Type A instrument cluster

(Master warning indication)
Displays when notification of the system malfunctions is required.
Check the message indicated in the display and consult an Authorized Mazda Dealer.
(Master warning light)
The master warning light displays when a warning message occurs.
This indicates a malfunction with the vehicle system. Check the message indicated in the
display and consult an Authorized Mazda Dealer.
For details, refer to the explanations for the warning/indicator lights, in the warning/indi-
cator lights section, which match the symbol in the upper part of the display.
If a message is not indicated in the display, operate the INFO switch to display the “Warn-
ing” screen.
Refer to Message Indicated in Multi-information Display and INFO switch on page 4-18.

Type B instrument cluster

The light illuminates continuously if any one of the following occurs. Consult an Author-
ized Mazda Dealer.

There is a malfunction in the battery management system.

There is a malfunction in the brake switch.

Electric Vacuum

Pump Warning

Light

The light turns on if the electric vacuum pump system has a problem. Have your vehicle
inspected at an Authorized Mazda Dealer.

ABS Warning Light

If the ABS warning light stays on while you're driving, the ABS control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an Authorized Mazda Dealer as soon as possible.

NOTE

When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.

The brake assist system does not operate while the ABS warning light is illuminated.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-36

*Some models.

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Signal

Warning

Check Engine Light

If this light illuminates while driving, the vehicle may have a problem. It is important to
note the driving conditions when the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:

The engine's electrical system has a problem.

The emission control system has a problem.

The fuel tank level being very low or approaching empty.

The fuel-filler cap is missing or not tightened securely.

If the check engine light remains on, or it flashes continuously , do not drive at high
speeds and consult an Authorized Mazda Dealer as soon as possible.

Automatic Trans-

mission Indication/

Warning Light

*

The indication/light illuminates when the transmission has a problem.

CAUTION

If the automatic transmission warning indication/light illuminates, the transmission has an
electrical problem. Continuing to drive your Mazda in this condition could cause damage to
your transmission. Consult an Authorized Mazda Dealer as soon as possible.

(Illuminate)

TCS/DSC Indicator

Light

If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer.

Air Bag/Seat Belt

Pretensioner System

Warning Light

A system malfunction is indicated if the warning light constantly flashes, constantly illu-
minates or does not illuminate at all when the ignition is switched ON. If any of these oc-
cur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate
in an accident.

WARNING

Never tamper with the air bag/pretensioner systems and always have an Authorized Mazda
Dealer perform all servicing and repairs:
Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner could
accidentally activate or become disabled causing serious injury or death.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-37

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Signal

Warning

(Flashing)

Tire Pressure Moni-

toring System

Warning Light

If the tire pressure monitoring system has a malfunction, the tire pressure warning light
flashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.

WARNING

If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, decrease vehicle speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, it is dangerous to drive the vehicle at high speeds, or
perform sudden maneuvering or braking. Vehicle drivability could worsen and result in an
accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed to a
place where air may be added and the system monitored again by an Authorized Mazda
Dealer or a tire repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have
the problem taken care of as soon as possible before it develops into a more serious situa‐
tion that could lead to tire failure and a dangerous accident.

(Red)

KEY Warning Indi-

cation

*

“Keyless System malfunction” is displayed
This message is displayed if the advanced keyless entry & push button start system has a
problem.
Contact an Authorized Mazda Dealer.

CAUTION

If the message is indicated, or the push button start indicator light (amber) flashes, the en‐
gine may not start. If the engine cannot be started, try starting it using the emergency oper‐
ation for starting the engine, and have the vehicle inspected at an Authorized Mazda Deal‐
er as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-9.

(Amber)

KEY Warning Indi-

cation

*

“Ignition is on” is displayed
This message is displayed when the driver's door is opened without switching the ignition
off.
“Key not detected” is displayed
This message is displayed when any of the following operations is performed with the key
out of the operational range or placed in areas inside the cabin where it is difficult for the
key to be detected.

The push button start is pressed with the ignition switched off

The ignition is switched on

All doors are closed without switching the ignition off

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-38

*Some models.

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Signal

Warning

(Red)

(Illuminate)

KEY Warning

Light

*

If any malfunction occurs in the keyless entry system, it illuminates continuously.

CAUTION

If the key warning indicator light illuminates or the push button start indicator light (amber)
flashes, the engine may not start. If the engine cannot be started, try starting it using the
emergency operation for starting the engine, and have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.

Refer to Emergency Operation for Starting the Engine on page 4-9.

(Illuminate)

Lane Departure

Warning System

(LDWS) Warning

Indication/Warning

Light

*

The warning indication/warning light illuminates if there is a problem with the system.
Have your vehicle inspected at an Authorized Mazda Dealer.

The LDWS does not operate when the warning indication/warning light illuminates.

CAUTION

 A problem in the system may be indicated under the following conditions. Have your ve‐

hicle inspected at an Authorized Mazda Dealer.

 When the warning indication/warning light illuminates while driving the vehicle.

When the system is canceled automatically, the warning indication/warning light illu‐
minates. Normally, the system restores automatically and the warning indication/
warning light turns off, however, if the warning indication/warning light illuminates,
there may be a problem with the system.

 The warning indication/warning light does not illuminate when the ignition is switched

ON.

 Always use tires for all wheels that are of the specified size, and the same manufacture,

brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the LDWS may not operate
normally.

 When an emergency spare tire is used, the system may not operate normally.

NOTE

If the windshield area in front of the Forward Sensing Camera (FSC) is fogged or ob-
structed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.

(Amber)

High Beam Control

System (HBC)

Warning Indication/

Warning Light

*

The warning indication/warning light illuminates if there is a problem with the system.
Have your vehicle inspected at an Authorized Mazda Dealer.

NOTE

If the windshield area in front of the Forward Sensing Camera (FSC) is fogged or ob-
structed, the warning indication/warning light illuminates temporarily. If the warning in-
dication/warning light illuminates, there may be a problem with the system.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-39

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Signal

Warning

Blind Spot Monitor-

ing (BSM) Warning

Indication

*

The message is displayed when the system has a malfunction. Have your vehicle inspect-
ed by an Authorized Mazda Dealer.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause. However, it does not indicate a malfunction.

Blind Spot Monitor-

ing (BSM) OFF In-

dicator Light

*

A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.

The light does not turn on when the ignition is switched ON.

The light remains on even when the Blind Spot Monitoring (BSM) system can be operat-
ed.

The light turns on while driving the vehicle.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator light
in the instrument cluster illuminates). However, it does not indicate a malfunction.

Retractable Hardtop
Warning Indication

*

The message is displayed when the system has a malfunction. Have your vehicle inspect-
ed by an Authorized Mazda Dealer.

LED Headlight

Warning Light

This light illuminates if there is a malfunction in the LED headlight. Have your vehicle
inspected by an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-40

*Some models.

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

▼ Taking Action

Take the appropriate action and verify that the warning light turns off.

Signal

Warning

Action to be taken

Seat Belt Warning

Light

Except Mexico
The seat belt warning light turns on if the
driver or passenger's seat is occupied and
the seat belt is not fastened with the ignition
switched ON.
If the driver or passenger's seat belt is un-
fastened (only when the passenger's seat is
occupied) and the vehicle is driven at a
speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re-
mains illuminated.

NOTE

The warning light flashes for about 6 sec-
onds if the driver's seat belt is not fastened
when the ignition is switched ON.

To allow the passenger occupant classifi-
cation sensor to function properly, do not
place and sit on an additional seat cushion
on the passenger's seat. The sensor may
not function properly because the addi-
tional seat cushion could cause sensor in-
terference.

If a small child is seated on the passeng-
er's seat, the warning light may not oper-
ate.

Fasten the seat belts.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-41

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Signal

Warning

Action to be taken

Seat Belt Warning

Light

Mexico
The seat belt warning light turns on if the
driver or passenger's seat is occupied and
the seat belt is not fastened with the ignition
switched ON.
If the driver or passenger's seat belt is un-
fastened (only when the passenger's seat is
occupied) and the vehicle is driven at a
speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re-
mains illuminated. If a seat belt remains un-
fastened, the warning light flashes again for
a given period of time.

NOTE

Placing heavy items on the passenger's
seat may cause the passenger's seat belt
warning function to operate depending on
the weight of the item.

To allow the passenger seat weight sensor
to function properly, do not place and sit
on an additional seat cushion on the pas-
senger's seat. The sensor may not function
properly because the additional seat cush-
ion could cause sensor interference.

If a small child is seated on the passeng-
er's seat, the warning light may not oper-
ate.

Fasten the seat belts.

Door-Ajar/Trunk

lid-Ajar Warning Indi-

cation/Warning Light

The light turns on if any door/trunk lid is
not closed securely.

Close the door/trunk lid securely.

Low Fuel Warning

Light

The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).

NOTE

The light illumination timing may vary be-
cause fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture.

Add fuel.

Check Fuel Cap Warn-

ing Light

If the check fuel cap warning light illumi-
nates while driving, the fuel-filler cap may
not be installed properly.

Stop the engine and reinstall the fuel-filler
cap.
Refer to Refueling on page 3-26

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-42

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Signal

Warning

Action to be taken

Low Washer Fluid

Level Warning Indica-

tion/Warning Light

*

This warning light indicates that little wash-
er fluid remains.

Add washer fluid (page 6-26).



Tire Pressure Monitoring System Warning Light (Turns on)

Take the appropriate action and verify that the warning light turns off.

Warning

When the warning light illuminates, and the warning beep sound is heard when tire pressure is too low in one or
more tires.

WARNING

If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, decrease vehicle speed immediately and avoid sudden maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, it is dangerous to drive the vehicle at high speeds, or perform sudden maneuvering or braking. Vehicle
drivability could worsen and result in an accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can check the visual condition
of the tire and determine if you have enough air to proceed to a place where air may be added and the system
monitored again by an Authorized Mazda Dealer or a tire repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have the problem taken
care of as soon as possible before it develops into a more serious situation that could lead to tire failure and a
dangerous accident.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-43

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Action to be taken

Inspect the tires and adjust to the specified inflation pressure (page 6-36).

CAUTION

When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the
tire pressure sensors may be damaged.

NOTE

Perform tire pressure adjustment when the tires are cold. Tire pressure will vary according to the tire tempera-
ture, therefore let the vehicle stand for 1 hour or only drive it 1.6 km (1 mile) or less before adjusting the tire
pressures. When pressure is adjusted on hot tires to the cold inflation pressure, the TPMS warning light/beep
may turn on after the tires cool and pressure drops below specification.
Also, an illuminated TPMS warning light, resulting from the tire air pressure dropping due to cold ambient
temperature, may turn off if the ambient temperature rises. In this case, it will also be necessary to adjust the
tire air pressures. If the TPMS warning light illuminates due to a drop in tire air pressure, make sure to check
and adjust the tire air pressures.

After adjusting the tire air pressures, it may require some time for the TPMS warning light to turn off. If the
TPMS warning light remains illuminated, drive the vehicle at a speed of at least 25 km/h (16 mph) for 10 mi-
nutes, and then verify that it turns off.

Tires lose air naturally over time and the TPMS cannot tell if the tires are getting too soft over time or you
have a flat. However, when you find one low tire in a set of four-that is an indication of trouble; you should
have someone drive the vehicle slowly forward so you can inspect any low tire for cuts and any metal objects
sticking through tread or sidewall. Put a few drops of water in the valve stem to see if it bubbles indicating a
bad valve. Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous ―
take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the
best replacement tire for your vehicle.

If the warning light illuminates again even after the tire pressures are adjusted, there may be a tire puncture.



If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-44

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

KEY Indication (White)/KEY Warning Light (Red)

Take the appropriate action and verify that the warning light turns off.

Signal

Cause

Action to be taken

(White)

KEY Indication

*

The advanced key battery is dead.

Replace the key battery (page 6-33).

(Red)

(Flashing)

KEY Warning Light

*

(Red)

(Flashing)

KEY Warning Light

*

The advanced key is not within the opera-
tion range.

Bring the advanced key into the operation
range (page 3-7).

The advanced key is placed in areas inside
the cabin where it is difficult for the key to
be detected.

A key from another manufacturer similar to
the advanced key is in the operation range.

Take the key from another manufacturer
similar to the advanced key out of the op-
eration range.

Without the ignition switched off, the ad-
vanced key is taken out of the cabin, and
then all the doors are closed.

Bring the advanced key back into the cab-
in.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-45

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Message Indicated in Multi-information Display

*

If there is a notification from the vehicle, a message is displayed in the multi-information
display. Check the information and take the necessary action.


(Display example)

If the warning light turns on/flashes simultaneously or a symbol is indicated in the display,
check the information regarding the warning light or symbol. (page 4-26)

Display

Content

Action to be taken

Indicated when the push button start is
pressed while the selector lever is not in
the P position.

Shift the selector lever to the P position.

Indicated when the push button start is
pressed without depressing the brake
pedal.

Depress the brake pedal and press the
push button start.

Indicated when the push button start is
pressed without depressing the clutch
pedal.

Depress the clutch pedal and press the
push button start.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-46

*Some models.

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Message Indicated on Display

If a message is displayed in the center display (Type B audio), take appropriate action (in a
calm manner) according to the displayed message.


(Display example)

▼ Stop Vehicle in Safe Place Immediately

If the following messages are displayed in the center display (Type B audio), a vehicle
system may be malfunctioning. Stop the vehicle in a safe place and contact an Authorized
Mazda Dealer.

Display

Indicated Condition

Displays if the engine coolant temperature has increased excessively.

Displays if the charging system has a malfunction.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-47

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

▼ Verify Display Content

Displays in the following cases:

Display

Indicated Condition/Action to be taken

The following message is displayed when the temperature around the
center display is high.
Lowering the temperature in the cabin or the temperature around the
center display by avoiding direct sunlight is recommended.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-48

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Warning Sound is

Activated

▼ Lights-On Reminder

The lights-on reminder is operable when
the time setting

*1

 of the auto headlight off

function is off.
If lights are on and the ignition is switched
to ACC or off, a continuous beep sound
will be heard when the driver's door is
opened.

*

1 If the light switch is left on, the auto

headlight off function automatically
turns off the lights about 30 seconds
after switching the ignition off. The
time setting can be changed.
Refer to Personalization Features on
page 9-9.

NOTE

When the ignition is switched to ACC,
the “Ignition Not Switched Off (STOP)
Warning Beep” (page 7-50
) overrides
the lights-on reminder.

A personalized function is available to
change the sound volume for the
lights-on reminder.
Refer to Personalization Features on
page 9-9.

▼ Air Bag/Seat Belt Pretensioner

System Warning Beep

If there is a problem with the air bag/seat
belt pretensioner systems and the warning
light illumination, a warning beep sound
will be heard for about 5 seconds every
minute.


The air bag and seat belt pretensioner
system warning beep sound will continue
to be heard for approximately 35 minutes.
Have your vehicle inspected at an
Authorized Mazda Dealer as soon as
possible.

WARNING

Do not drive the vehicle with the air bag/
seat belt pretensioner system warning beep
sounding:
Driving the vehicle with the air bag/seat
belt pretensioner system warning beep
sounding is dangerous. In a collision, the
air bags and the seat belt pretensioner
system will not deploy and this could result
in death or serious injury. Contact an
Authorized Mazda Dealer to have the
vehicle inspected as soon as possible.

▼ Seat Belt Warning Beep

Except Mexico

If the driver's seat belt is not fastened
when the ignition is switched ON, a beep
sound will be heard for about 6 seconds. If
the driver or the passenger's seat belt is not
fastened and the vehicle is driven at a
speed faster than about 20 km/h (12 mph),
a beep sound will be heard again for a
specified period of time.
Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-49

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

NOTE

To allow the passenger occupant
classification sensor to function
properly, do not place and sit on an
additional seat cushion on the
passenger's seat. The sensor may not
function properly because the additional
seat cushion could cause sensor
interference.

If a small child is seated on the
passenger's seat, the warning beep may
not operate.

Mexico

If the vehicle speed exceeds about 20
km/h (12 mph) with the driver or
passenger's seat belt unfastened, a warning
beep sounds continuously. If the seat belt
remains unfastened, the beep sound stops
once and then continues for about 90
seconds. The beep stops after the driver or
passenger's seat belt is fastened.
Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).

NOTE

Placing heavy items on the passenger's
seat may cause the passenger's seat belt
warning function to operate depending
on the weight of the item.

To allow the passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the passenger's seat. The sensor may not
function properly because the additional
seat cushion could cause sensor
interference.

If a small child is seated on the
passenger's seat, the warning beep may
not operate.

▼ Retractable Hardtop Warning Beep

*

When operating the retractable hardtop
switch, the warning beep is activated when
the retractable hardtop operation begins
and when it is completed.
If there is a problem with the retractable
hardtop, the warning beep is activated
continuously while operating the switch. If
the warning beep is activated continuously
while operating the switch, have the
vehicle inspected at an Authorized Mazda
Dealer.

▼ Ignition Not Switched Off (STOP)

Warning Beep

If the driver's door is opened with the
ignition switched to ACC, a beep will be
heard continuously in the cabin to notify
the driver that the ignition has not been
switched OFF (STOP). Under this
condition, the keyless entry system will
not operate, the vehicle cannot be locked,
and the battery voltage will be depleted.

▼ Key Removed from Vehicle Warning

Beep

Vehicles with advanced keyless function

If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, the beep which
sounds outside of the vehicle will be heard
6 times, the beep which sounds inside the
vehicle will be heard 6 times, and the
KEY warning light (red) in the instrument
cluster flashes continuously to notify the
driver that the ignition has not been
switched OFF.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-50

*Some models.

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Vehicles without advanced keyless
function

If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, a beep will be heard
in the cabin 6 times and the KEY warning
light (red) in the instrument cluster turns
on continuously to notify the driver that
the ignition has not been switched OFF.

NOTE
Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key is
carried together with a metal object or it
is placed in a poor signal reception area.

▼ Request Switch Inoperable Warning

Beep (With the advanced keyless
function)

If the request switch is pressed with the
door open or ajar, or the ignition is not
switched OFF with a key being carried, a
beep will be heard outside for about 2
seconds to notify the driver that the door
or trunk lid cannot be locked.

▼ Key Left-in-trunk Compartment

Warning Beep (With the advanced
keyless function)

If the key is left in the trunk with all the
doors locked and the trunk lid closed, a
beep will be heard outside for about 10
seconds to notify the driver that the key is
in the trunk. In this case, take out the key
by pressing the electric trunk lid opener
and opening the trunk lid. The key taken
out of the trunk may not operate because
its functions have been temporarily
stopped. To restore the key's functions,
perform the applicable procedure (page
3-8).

▼ Key Left-in-vehicle Warning Beep

(With the advanced keyless
function)

If all the doors and trunk are locked using
another key while the key is left in the
cabin, the beep which sounds outside of
the vehicle will be heard for about 10
seconds to notify the driver that the key is
in the cabin. In this case, take out the key
by opening the door. A key taken out of
the vehicle using this method may not
operate because its functions have been
temporarily stopped. To restore the key's
functions, perform the applicable
procedure (page 3-8).

▼ Power Steering Warning Buzzer

If the power steering system has a
malfunction, the power steering
malfunction light turns on or flashes and
the buzzer operates at the same time.
Refer to Warning Indication/Warning
Lights on page 4-26.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-51

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27















Content   ..  28  29  30  31   ..
