Mazda MX-5 (2018 year). Manual

6. Say: [Beep] “XXXXX... (Ex. Device

B)”

7. Prompt: “XXXXX... (Ex. Device B).

Is this correct?”

8. Say: [Beep] “Yes” or “No”
9. If “Yes”, go to Step 10. If “No”, the

procedure returns to Step 5.

10. Prompt: “XXXXX... (Ex. Device B)

selected.”

NOTE



When the selected device connection is
completed, the or symbol is
displayed.



Some Bluetooth

audio devices need a

certain amount of time before the or
symbol is displayed.



Device (Music player) selection can also
be done by operating the panel button.

▼ Deleting a device (Bluetooth

Hands-Free)

Registered devices (Mobile phone) can be
deleted individually or collectively.

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.”

4. Say: [Beep] “Pairing options”
5. Prompt: “Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.”

NOTE
A registered device (Mobile phone) can
be deleted using the registration list.

6. Say: [Beep] “Delete”
7. Prompt: “Please say the name of the

device you would like to delete.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C), or all.
Which device please?”

8. Say: [Beep] “X” (Say the number of

the device to be deleted.)

NOTE
Say “All” to delete all devices (Mobile
phone).

9. Prompt: “Deleting XXXXX... (Ex.

device B...) (Registered device tag). Is
this correct?”

10. Say: [Beep] “Yes”
11. Prompt: “Deleted”

▼ Registered device editing

(Bluetooth

Hands-Free)

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.”

4. Say: [Beep] “Pairing options”
5. Prompt: “Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.”

6. Say: [Beep] “Edit”
7. Prompt: “Please say the name of the

device you would like to edit.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C). Which
device please?”

Interior Features

Audio Set [Type A (non-touchscreen)]

5-42

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

8. Say: [Beep] “X” (Say the number of

the device to be edited.)

9. Prompt: “New name please?”
10. Say: [Beep] “XXXXX... (Ex. Device

C)” (Speak a “device tag” an arbitrary
name for the device.)

11. Prompt: “XXXXX... (Ex. device C)

(Device tag), is this correct?”

12. Say: [Beep] “Yes”
13. Prompt: “New name saved.”

▼ Bluetooth

Audio Preparation

Bluetooth

audio device set-up

Bluetooth

audio pairing, changes,

deletions, and display of paired device
information can be performed.
1. The mode changes as follows each

time the menu button (

) is

pressed. Select “BT SETUP”.

* Depending on the mode selected, the
indication changes.

2. Turn the audio control dial and select a

desired mode.

Display

Mode

Function

PAIR DE-
VICE

Pairing mode

Bluetooth

audio de-

vice pairing

LINK
CHANGE

Link change
mode

Changing link to Blue-
tooth

audio device

PAIR DE-
LETE

Pairing dele-
tion mode

Deleting link to Blue-
tooth

audio device

DEVICE
INFO

Device infor-
mation dis-
play mode

Displaying vehicle's
Bluetooth

unit infor-

mation

3. Press the audio control dial to

determine the mode.

▼ Bluetooth

audio device pairing

(Bluetooth

Audio)

Any Bluetooth

audio device must be

paired to the vehicle's Bluetooth

unit

before it can be listened to over the
vehicle's speakers.
A maximum of seven devices including
Bluetooth

audio devices and hands-free

mobile phones can be paired to one
vehicle.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-43

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

NOTE



If a Bluetooth

device has already been

paired to the vehicle as a hands-free
mobile phone, it does not need to be
paired again when using the device as a
Bluetooth

audio device. Conversely, it

does not need to be paired again as a
hands-free mobile phone if it has
already been paired as a Bluetooth

audio device.



Device registration can also be done
using voice recognition.

Concerning the operation of a Bluetooth

audio device itself, refer to its instruction
manual.
Some Bluetooth

audio devices have PIN

codes (four digits). Refer to the audio
device's instruction manual because the
pairing procedure differs depending on
whether it has a PIN code or not.

Pairing a Bluetooth

audio device

which has a four-digit PIN code

1. Using the audio control dial, select the

pairing mode “PAIR DEVICE” in the
“BT SETUP” mode. (Refer to
“Bluetooth

audio device set-up” for

details.)

2. Press the audio control dial to

determine the mode. After “ENTER
PIN” is displayed on the audio display
for three seconds, “PIN 0000” is
displayed and the PIN code can be
input.

3. Input the PIN code of your Bluetooth

audio device by pressing channel
preset buttons 1 to 4 while “PIN 0000”
is displayed.
Press channel preset button 1 to input
the first digit, 2 for the second, 3 for
the third, and 4 for the forth. For
example, if the PIN code were “4213”
press channel preset button 1 four
times (1, 2, 3, 4), button 2 twice (1, 2),
button 3 once (1), and button 4 three
times (1, 2, 3). If the “PIN 0000”
display disappears before finishing the
PIN code input, repeat the procedure
from Step 1.

NOTE
Some devices accept only a particular
pairing code (Usually, “0000” or
“1234”).
If pairing cannot be completed, refer to
the owner's manual of your mobile
device, and try those numbers if
necessary.

4. Press the audio control dial while the

input PIN code is displayed.
“PAIRING” flashes on the audio
display.

5. Operate the Bluetooth

audio device

and set it to the pairing mode while
“PAIRING” is flashing.

6. When the pairing is completed, and

“PAIR SUCCESS” are displayed after
about 10-30 seconds, after which
“PAIR SUCCESS” continues to be
displayed for three seconds, and then
the unit returns to the normal display.

NOTE



Some Bluetooth

audio devices need

a certain amount of time before the
symbol is displayed.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-44

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27



If the pairing failed, “Err” flashes
for three seconds.



Pairing cannot be performed while
the vehicle is moving. If you attempt
to perform pairing while the vehicle
is moving, “PAIR DISABLE” is
displayed.



If seven Bluetooth

audio devices

have already been paired to the
vehicle, pairing cannot be performed
and “MEMORY FULL” is
displayed. Delete one paired device
to pair another one.

Pairing a Bluetooth

audio device

which does not have a four-digit PIN
code

1. Using the audio control dial, select the

pairing mode “PAIR DEVICE” in the
“BT SETUP” mode. (Refer to
“Bluetooth

audio set up” for details.)

2. Press the audio control dial to

determine the mode. After “ENTER
PIN” is displayed on the audio display
for three seconds, “PIN 0000” is
displayed and the PIN code can be
input.

3. Press the audio control dial while “PIN

0000” is displayed. “PAIRING”
flashes on the audio display.

4. Operate the Bluetooth

audio device

and set it to the pairing mode while
“PAIRING” is flashing.

5. As the Bluetooth

audio device

requires a PIN code, input “0000”.

6. When the pairing is completed, and

“PAIR SUCCESS” are displayed after
about 10-30 seconds, after which
“PAIR SUCCESS” continues to be
displayed for three seconds, and then
the unit returns to the normal display.

NOTE



If pairing cannot be completed, try
“1234” instead. Refer to the owner's
manual of your mobile device for the
right PIN code.



Some Bluetooth

audio devices need

a certain amount of time before the
symbol is displayed.



If the pairing failed, “Err” flashes
for three seconds.



Pairing cannot be performed while
the vehicle is moving. If you attempt
to perform pairing while the vehicle
is moving, “PAIR DISABLE” is
displayed.



If seven Bluetooth

audio devices

have already been paired to the
vehicle, pairing cannot be performed
and “MEMORY FULL” is
displayed. Delete one paired device
to pair another one.

▼ Device selection (Bluetooth

Audio)

If several devices have been paired, the
Bluetooth

unit links the device last

paired. If you would like to link a different
paired device, it is necessary to change the
link. The order of device priority after the
link has been changed is maintained even
when the ignition is switched off.
1. Using the audio control dial, select the

link change mode “LINK CHANGE”
in the “BT SETUP” mode. (Refer to
“Bluetooth

audio device set-up” for

details.)

2. Press the audio control dial to

determine the mode.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-45

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

3. The name of the currently linked

Bluetooth

audio device is displayed.

If no Bluetooth

audio device is

currently linked, the name of the first
device among the paired devices is
displayed.

4. Turn the audio control dial to select the

name of the device you would like to
link.

Device name 1

Device name 2

Device name 3

Device name 4

Device name 5

Device name 6

Device name 7

5. Press the audio control dial to select

the device you would like to link. The

symbol disappears, and “PAIRING”

flashes in the audio display.

NOTE
When “GO BACK” is selected and the
audio control dial is pressed, the
display returns to “LINK CHANGE”.

6. If the link to the desired device is

successful, the symbol is displayed
again, together with “LINK
CHANGED”. “LINK CHANGED” is
displayed for three seconds, then it
returns to the normal display.

NOTE



Some Bluetooth

audio devices need

a certain amount of time before the
symbol is displayed.



If a hands-free type mobile phone
has been the most recently paired
device, the Bluetooth

unit links this

device. If you would like to use a
Bluetooth

audio type device which

has been previously paired to the
Bluetooth

unit, the link must be

changed to this device.



If an error occurs while trying to
link a device, “Err” flashes in the
audio display for three seconds, and
the display returns to “LINK
CHANGE”. If this occurs, check the
pairing status of the Bluetooth

audio device and the location of the
device in the vehicle (not in the trunk
or a metal-type box), and then try
the link operation again.



Device selection can also be done
using voice recognition.

How to confirm the device currently
linked

Switch to the link-change mode. (Refer to
“Changing the link to a Bluetooth

audio

device”)
The device name displayed first is the
device which is currently linked.

▼ Deleting a device (Bluetooth

Audio)

1. Using the audio control dial, select the

pairing delete mode “PAIR DELETE”
in the “BT SETUP” mode. (Refer to
“Bluetooth

audio device set-up” for

details.)

Interior Features

Audio Set [Type A (non-touchscreen)]

5-46

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

2. Press the audio control dial to

determine the mode.

3. The name of the first device among the

paired devices is displayed.

4. Rotate the audio control dial and select

the name of the paired device you
would like to delete.

Device name 1

Device name 2

Device name 3

Device name 4

Device name 5

Device name 6

Device name 7

NOTE
Only the names of paired devices can
be displayed. If only one device is
paired, only the name for this device is
displayed.

5. If a selection other than “GO BACK”

is made and the audio control dial is
pressed, “SURE ? NO” is displayed.

6. Rotate the audio control dial clockwise

and switch the display to “SURE ?
YES”.

NOTE
The display changes as follows
depending on whether the audio
control dial is rotated clockwise or
counterclockwise.

-Clockwise: “SURE ? YES” displayed
-Counterclockwise: “SURE ? NO”
displayed

7. Press the audio control dial to delete

the selected device.

NOTE
Select “GO BACK” and press the
audio control dial to return to the
“PAIR DELETE” display.

8. “PAIR DELETED” is displayed for

three seconds after the deletion is
completed, and then it returns to the
normal display.

NOTE
If an error occurs while trying to
delete the paired device, “Err” flashes
in the display for three seconds and the
display returns to “LINK DELETE”.

▼ Bluetooth

audio device information

display

1. Using the audio control dial, select the

pair device information display mode
“DEVICE INFO” in the “BT SETUP”
mode. (Refer to “Bluetooth

audio

device set-up” for details.)

2. Press the audio control dial to

determine the mode.

3. The name of the Bluetooth

unit

device is displayed.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-47

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

4. Rotate the audio control dial to select

the information for the Bluetooth

unit

which you would like to view.

Device name

BT address

NOTE
When “GO BACK” is selected and the
audio control dial is pressed, the
display returns to “DEVICE INFO”.

Available Language

The available languages are English,
Spanish, and Canadian French. If the
language setting is changed, all of the
voice guidance and voice input commands
are done in the selected language.

NOTE



If the language setting is changed,
device registration is maintained.



Phonebook records are not cleared, but
each language has a separate
phonebook. Therefore, entries created in
one language will need to be re-entered
in the phonebook of the new language.



Do these steps before you start driving.
These less used functions are too
distracting to undertake while driving
until you are fully familiar with the
system.

(Method 1)

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.”

4. Say: [Beep] “Language”
5. Prompt: “Select a language: English,

French, or Spanish.”

6. Say: [Beep] “French” (Speak the

desired language:“English”, “French”
or “Spanish”)

NOTE
Other language settings can also be
made while in the current setting by
saying the name of the language in the
native pronunciation.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-48

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

7. Prompt: “French (Desired language)

selected. Is this correct?”

8. Say: [Beep] “Yes”
9. Prompt: “French (Desired language)

selected” (Spoken in the newly
selected language).

(Method 2)

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “French” (Say the desired

language: “English”, “French” or
“Spanish”). (Change the desired
language by saying the language
name.)

NOTE
Other language settings can also be
made while in the current setting by
saying the name of the language in the
native pronunciation.

3. Prompt: “Would you like to change

the language to French (Desired
language)?”

4. Say: [Beep] “Yes”
5. Prompt: “Please wait. Switching to

French phonebook. French selected”
(Spoken in the newly selected
language).

Security Setting

If a passcode is set, the system cannot be
activated unless the passcode is input.

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

Passcode setting

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.”

4. Say: [Beep] “Passcode”
5. Prompt: “Passcode is disabled. Would

you like to enable it?”

6. Say: [Beep] “Yes”
7. Prompt: “Please say a 4-digit

passcode. Remember this passcode. It
will be required to use this system.”

8. Say: [Beep] “XXXX” (Say a desired

4-digit passcode, “PCode”.)

9. Prompt:“Passcode XXXX (Passcode,

PCode). Is this correct?”

10. Say: [Beep] “Yes”
11. Prompt:“Passcode is enabled.”

Using Bluetooth

Hands-Free with a

passcode

1. Press the pick-up button or talk button

with a short press.

2. Prompt: “Hands-Free system is

locked. State the passcode to
continue.”

3. Say: [Beep] “XXXX” (Say the set

passcode “PCode”.)

Interior Features

Audio Set [Type A (non-touchscreen)]

5-49

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

4. If the correct passcode is input, voice

guidance “XXXXXX... (Ex. “Mary's
device”) (Device tag) is connected” is
announced.
If the passcode is incorrect, voice
guidance “XXXX (4-digit passcode,
Pcode) incorrect passcode, please try
again” is announced.

Canceling the passcode

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.”

4. Say: [Beep] “Passcode”
5. Prompt:“Passcode is enabled. Would

you like to disable it?”

6. Say: [Beep] “Yes”
7. Prompt:“Passcode is disabled.”

Confirmation Prompts

The confirmation prompt confirms the
command content to the user before
advancing to the operation requested by
the user. When this function is turned on,
the system reads out the voice input
command previously received and
confirms whether the command is correct
before advancing to the command
execution.
When the confirmation prompt function is
turned on:
(Ex. “Calling John's device. Is this
correct?”)
When the confirmation prompt function is
turned off:
(Ex. “Calling John's device.”)

NOTE
If the confirmation prompt function is
turned off when making an emergency
call, the system reads out and confirms the
command before executing it.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.”

4. Say: [Beep] “Confirmation prompts”
5. Prompt: “Confirmation prompts are

on/off. Would you like to turn
confirmation prompts off/on?”

6. Say: [Beep] “Yes”
7. Prompt: “Confirmation prompts are

off/on.”

Interior Features

Audio Set [Type A (non-touchscreen)]

5-50

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Bluetooth

Audio

Applicable Bluetooth

specification

(Recommended)
Ver. 2.0

Response profile



A2DP (Advanced Audio Distribution
Profile) Ver. 1.0



AVRCP (Audio/Video Remote Control
Profile) Ver. 1.0/1.3

A2DP is a profile which transmits only
audio to the Bluetooth

unit. If your

Bluetooth

audio device corresponds only

to A2DP, but not AVRCP, you cannot
operate it using the control panel of the
vehicle's audio system. In this case, only
the operations on the mobile device are
available the same as when a portable
audio device for a non-compliant
Bluetooth

device is connected to the

AUX terminal.

Function

A2DP

AVRCP

Ver. 1.0 Ver. 1.3

Playback

—

Pause

—

File (Track) up/down

—

Reverse

—

Fast-forward

—

Text display

—

X: Available
—: Not available

NOTE



The battery consumption of Bluetooth

audio devices increases while
Bluetooth

is connected.



If a general mobile phone device is USB
connected during music playback over
the Bluetooth

connection, the

Bluetooth

connection is disconnected.

For this reason, you cannot have music
playback over a Bluetooth

connection

and music playback using a USB
connection at the same time.



The system may not operate normally
depending on the Bluetooth

audio

device.

▼ Switching to Bluetooth

audio mode

To listen to music or voice audio recorded
to a Bluetooth

audio device, switch to the

Bluetooth

audio mode to operate the

audio device using the audio system
control panel. Any Bluetooth

audio

device must be paired to the vehicle's
Bluetooth

unit before it can be used.

Refer to Bluetooth

Preparation (Type A)

on page 5-39.
1. Turn on the Bluetooth

audio device's

power.

2. Switch the ignition to ACC or ON.

Make sure that the “ ” symbol is
displayed in the audio display. The
symbol is not displayed if an un-paired
Bluetooth

audio device is being used

or the vehicle's Bluetooth

unit has a

malfunction.

NOTE
Some Bluetooth

audio devices need a

certain amount of time before the “ ”
symbol is displayed.

3. Press the media button (

) to

switch to the Bluetooth

audio mode

and start playback.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-51

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

If the current device version is lower
than AVRCP Ver. 1.3: “BT Audio” is
displayed.
If the current device is AVRCP Ver. 1.3:
The playback time is displayed.

NOTE



If the Bluetooth

audio device does not

begin playback, press the Play/Pause
button (4).



If a call is received on a hands-free
mobile phone during playback from the
Bluetooth

audio device, the playback is

stopped. Playback from the Bluetooth

audio device resumes after the call ends.

▼ Playback

1. To listen to a Bluetooth

audio device

over the vehicle's speaker system,
switch the mode to Bluetooth

audio

mode. (Refer to “Switching to
Bluetooth

audio mode”)

2. To stop playback, press the Play/Pause

button (4).

3. Press the button again to resume

playback.

Selecting a file (track)

Selects the next file (track)

Short-press the track up button (

Selects the beginning of the current file
(track)

Short-press the track down button (

Fast-forward/Reverse (AVRCP Ver. 1.3)

Fast-forward

Press and hold the fast-forward button
(

Reverse

Press and hold the reverse down button
(

▼ Switching the display (only AVRCP

Ver. 1.3)

The information displayed on the audio
display changes as follows each time the
text button (3) is pressed during playback.

Button

Information displayed

on audio display

Elapsed time
Album name

Song name

Artist name

NOTE



If title information is not available, “NO
TITLE” is displayed.



This unit cannot display some
characters. Characters which cannot be
displayed are indicated by an asterisk
( ).

Interior Features

Audio Set [Type A (non-touchscreen)]

5-52

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Display scroll

Only 13 characters can be displayed at one
time. To display the rest of the characters
of a long title, press and hold the text
button (3). The display scrolls the next 13
characters. Press and hold the text button
(3) again after the last 13 characters have
been displayed to return to the beginning
of the title.

▼ Bluetooth

audio device information

display

If a Bluetooth

audio device is connected,

the following information is displayed in
the audio display.

Category

AVRCP Ver.

lower than 1.3

AVRCP

Ver. 1.3

Device name

Title

—

Artist name

—

Album name

—

File number

—

Playback time

—

Folder number

—

X: Available
—: Not available

NOTE
Some information may not display
depending on the device, and if the
information cannot be displayed, “NO
TITLE” is indicated.

Bluetooth

Hands-Free

▼ Making a Call

Phonebook Usage

Telephone calls can be made by saying the
name of a person (voice tag) whose phone
number has been registered in Bluetooth

Hands-Free in advance. Refer to
Phonebook registration.
1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Call”
3. Prompt: “Name please.”
4. Say: [Beep] “XXXXX... (Ex. “John's

phone”)” (Say a voice tag registered in
the phonebook.)

5. Prompt: “Calling XXXXX... (Ex.

“John's phone”) XXXX (Ex. “at
home”). Is this correct?” (Voice tag
and phone number location registered
in phonebook).

6. Say: [Beep] “Yes”
7. Prompt: “Dialing”

NOTE
The “Call” command and the voice tag
can be combined.
Ex. In Step 2, say, “Call John's phone”,
then, Steps 3 and 4 can be skipped.

Phonebook registration

Phone numbers can be registered to the
Bluetooth

Hands-Free phonebook.

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button

with a short press.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-53

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.”

4. Say: [Beep] “New entry”
5. Prompt: “Name please.”
6. Say: [Beep] “XXXXX... (Ex. “Mary's

phone”)” (Say a voice tag for the name
registered.)

7. Prompt: “Adding XXXXX... (Ex.

“Mary's phone”) (Registered voice
tag). Is this correct?”

8. Say: [Beep] “Yes”
9. Prompt: “Home, Work, Mobile, or

Other?”

10. Say: [Beep] “Mobile” (Say “Home” ,

“Work”, “Mobile”, or “Other”, for the
desired location to be registered.)

11. Prompt: “Mobile (Location to be

registered). Is this correct?”

12. Say: [Beep] “Yes”
13. Prompt: “Number, please.”
14. Say: [Beep] “XXXXXXXXXXX”

(Say the phone number to be
registered.)

15. Prompt: “XXXXXXXXXXX (Phone

number registration). After the beep,
continue to add numbers, or say
Go-Back to re-enter the last entered
numbers, or press the Pick-Up button
to save the number.”

16. (Registration)

Press the pick-up button or say
“Enter”, then go to Step 17.
(Adding/inputting telephone
number)
Say, “XXXX” (desired telephone
number), then go to Step 15.

(Telephone number correction)
Say, “Go Back”. The prompt replies,
“Go Back. The last entered numbers
have been removed.”. Then go back to
Step 13.

17. Prompt: “Number saved. Would you

like to add another number for this
entry?”

18. Say: [Beep] “Yes” or “No”.
19. If “Yes”, an additional phone number

registration can be made for the same
entry.
If “No”, the system returns to standby
status.

(Import contact)

Phonebook data from your device (Mobile
phone) can be sent and registered to your
Bluetooth

Hands-Free phonebook using

Bluetooth

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.”

4. Say: [Beep] “Import contact”
5. Prompt: “The hands free System is

ready to receive a contact from a
phone. Only a home, a work, and a
mobile number can be imported, This
process requires operation of a mobile
phone. refer to the phone's manual for
more information”

6. Device (Mobile phone) operation:

Select one entry from the phonebook
and send it using Bluetooth

7. Prompt: “X (Number of locations

which include data) numbers have
been imported. What name would you
like to use for these numbers?”

Interior Features

Audio Set [Type A (non-touchscreen)]

5-54

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

8. Say: [Beep] “XXXXX... (Ex. “Mary's

phone”)” (Say a voice tag for the name
registered.)

9. Prompt: “Adding XXXXX... (Ex.

“Mary's phone”) (Voice tag). Is this
correct?”

10. Say: [Beep] “Yes”
11. Prompt: “Number saved. Would you

like to import another contact?”

12. Say: [Beep] “Yes” or “No”
13. If “Yes”, the procedure proceeds to

Step 5.
If “No”, the system returns to standby
status.

Editing phonebook

The data registered to the Bluetooth

Hands-Free phonebook can be edited.

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.”

4. Say: [Beep] “Edit”
5. Prompt: “Please say the name of the

entry you would like to edit or say,
“List names”.”

6. Say: [Beep] “XXXXX... (Ex. “Mary's

phone”)” (Say the voice tag for the
registered name to be edited in the
phonebook.)

7. Prompt: “Home, Work, Mobile, or

Other?”

8. Say: [Beep] “Home” (Say the

registered location to be edited:
“Home”, “Work”, “Mobile”, or
“Other”.)

9. Prompt: “XXXXX... (Ex. “Mary's

phone”) (Registered voice tag) XXXX
(Ex. “Home”) (Registered location). Is
this correct?”

10. Say: [Beep] “Yes”
11. Prompt: “The current number is

XXXXXXXXXXX (Ex. “555-1234”)
(Currently registered number). New
number, please.”

NOTE
If there was no previous phone number
registered to a location (Ex. “Work”),
the prompt will only read out
“Number, please”

12. Say: [Beep] “XXXXXXXXXXX (Ex.

“555-5678”)” (Say the new phone
number to be registered.)

13. Prompt: “XXXXXXXX (Telephone

number) After the beep, continue to
add numbers, or say Go-Back to
re-enter the last entered numbers, or
press the Pick-Up button to save the
number.”

14. (Number Change)

Press the pick-up button, then go to
Step 15.
(Adding/inputting telephone
number)
Say, “XXXX” (desired telephone
number), then go to Step 13.
(Telephone number correction)
Say, “Go Back”. The prompt replies,
“Go Back. The last entered numbers
have been removed. Number, please.”.
Then go back to Step 12.

15. Prompt: “Number changed.”

Interior Features

Audio Set [Type A (non-touchscreen)]

5-55

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Phonebook data deletion

(Erasing individual phonebook data)

Individual data registered to the
Bluetooth

Hands-Free phonebook can be

cleared.

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.”

4. Say: [Beep] “Delete”
5. Prompt: “Please say the name of the

entry you would like to delete or say,
“List names”. ”

6. Say: [Beep] “XXXXX... (Ex. “John's

phone”) ” (Say the registered voice tag
to be deleted from the phonebook.)

7. Prompt: “Deleting XXXXX... (Ex.

“John's phone”) (Registered voice tag)
Home (Registered location). Is this
correct?”

8. Say: [Beep] “Yes”
9. Prompt: “XXXXX... (Ex. “John's

phone”) (Registered voice tag) Home
(Registered location) deleted.”

(Complete deletion of the phonebook
data)

All data registered to the Bluetooth

Hands-Free phonebook can be erased.

NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.”

4. Say: [Beep] “Erase all”
5. Prompt: “Are you sure you want to

erase everything from your Hands Free
system phonebook?”

6. Say: [Beep] “Yes”
7. Prompt: “You are about to delete

everything from your Hands Free
system phonebook. Do you want to
continue?”

8. Say: [Beep] “Yes”
9. Prompt: “Please wait, erasing the

Hands Free system phonebook.”

10. Prompt: “Hands-Free system

phonebook erased.”

Read-out of names registered to the
Bluetooth

Hands-Free phonebook

Bluetooth

Hands-Free can read out the

list of names registered to its phonebook.
1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.”

4. Say: [Beep] “List names”

Interior Features

Audio Set [Type A (non-touchscreen)]

5-56

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

5. Prompt: “XXXXX..., XXXXX...,

XXXXX... (Ex. “John's phone”,
Mary's phone, Bill's phone)” (Voice
guidance reads out the voice tags
registered to the phonebook.)
Press the talk button with a short press
during the read-out at the desired
name, and then say one of the
following voice commands to execute
it.



“Continue”: Continues the list
readout.



“Call”: Calls the registered
phonebook data when the talk button
is short-pressed.



“Edit”: Edits the registered
phonebook data when the talk button
is short-pressed.



“Delete”: Deletes the registered
phonebook data when the talk button
is short-pressed.



“Previous”: Returns to the previous
phonebook data in read-out when the
talk button is short-pressed.

6. Prompt: “End of list, would you like

to start from the beginning?”

7. Say: [Beep] “No”
8. The procedure returns to Step 3.

Redial Function

Redialing the number of the person
previously dialed using the phone is
possible.
1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Redial”
3. Prompt: “Dialing”

Telephone Number Input

NOTE
Practice this while parked until you are
confident you can do it while driving in a
non-taxing road situation. If you are not
completely comfortable, make all calls
from a safe parking position, and only
start driving when you can devote your
full attention to driving.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep] “Dial”
3. Prompt: “Number, please”
4. Say: [Beep] “XXXXXXXXXXX

(Telephone number)”

5. Prompt: “XXXXXXXXXXX.

(Telephone number) After the beep,
continue to add numbers, or say
Go-Back to re-enter the last entered
numbers, or press the Pick-Up button
to execute dialing.”

6. (Dialing)

Press the pick-up button or say “Dial”,
then go to Step 7.
(Adding/inputting telephone
number)
Say, “XXXX” (desired telephone
number), then go to Step 5.
(Telephone number correction)
Say, “Go Back”. The prompt replies,
“Go Back. The last entered numbers
have been removed.”. Then go back to
Step 3.

7. Prompt: “Dialing”

NOTE
The “Dial” command and a telephone
number can be combined.
Ex. In Step 2, say, “Dial 123-4567” then,
Steps 3 and 4 can be skipped.

Interior Features

Audio Set [Type A (non-touchscreen)]

5-57

MX-5_8GF7-EA-17J_Edition2

2017-10-31 14:07:27

Mazda MX-5 (2018 year). Manual - part 17
