Mazda CX-3 (2019 year). Manual

CAUTION

In the following cases, turn the system off to prevent a mis-operation:

The vehicle is being towed or when towing another vehicle.
The vehicle is on a chassis roller.
When driving on rough roads such as in areas of dense grass or off-road.

Refer to Stopping the Advanced Smart City Brake Support (Advanced SCBS) System Operation
on page 4-121 on how to turn off the Advanced SCBS system.

NOTE

•

The Advanced SCBS system will operate under the following conditions.

•

The engine is running.

•

The Smart City Brake Support (SCBS) warning light (amber) does not illuminate.

•

(Object is vehicle ahead)
The vehicle speed is between about 4 to 80 km/h (2 to 50 mph).

•

(Object is a pedestrian)
The vehicle speed is between about 10 to 80 km/h (6.2 to 50 mph).

•

The Advanced SCBS system is not turned off.

•

Under the following conditions, the Advanced SCBS system may not operate normally:

•

The Advanced SCBS system will not operate if the driver is deliberately performing
driving operations (accelerator pedal and steering wheel).

•

If there is the possibility of partial contact with a vehicle ahead.

•

The vehicle is driven on a slippery road surface such as wet roads or icy or snow-bound roads.

•

The braking performance is adversely affected due to cold temperatures or wet brakes.

•

The vehicle is driven at the same speed as the vehicle ahead.

•

The accelerator pedal is depressed.

•

The brake pedal is depressed.

•

The steering wheel is being operated.

•

The selector lever is being operated.

•

In the following cases, the Advanced SCBS may operate.

•

Objects on the road at the entrance to a curve.

•

Vehicles passing in the opposite lane while making a curve.

•

When passing through a toll gate.

•

When passing through low gates, narrow gates, car washing machines, or tunnels.

•

If you suddenly come close to a vehicle ahead.

•

2-wheeled vehicles, animals, or standing trees.

•

(Manual transaxle)
If the vehicle is stopped by the SCBS operation and the clutch pedal is not depressed, the engine stops.

When Driving

i-ACTIVSENSE

4-120

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Smart City Brake Support (SCBS)

Indicator Light (Red)

If the Advanced SCBS is operating, the
indicator light (red) flashes.

▼ Collision Warning

If there is the possibility of a collision with
a vehicle ahead, the beep sounds
continuously and a warning is indicated in
the active driving display.

NOTE

•

(Without SCBS OFF switch)
The operation distance and volume of
the collision warning can be changed.
Refer to Personalization Features on
page 9-9.

•

(With SCBS OFF switch)
The operation distance and volume of
the collision warning can be changed.
Consult an Authorized Mazda Dealer.

▼ Automatic Brake Operation Display

The automatic brake operation display is
indicated on the active driving display
after the Advanced SCBS is operated.

NOTE

•

The collision warning beep sounds
intermittently while the Advanced SCBS
brake or brake assist (Advanced SCBS
brake assist) is operating.

•

If the vehicle is stopped by the Advanced
SCBS operation and the brake pedal is
not depressed, the warning beep sounds
one time after about 2 seconds and the
Advanced SCBS brake is automatically
released.

▼ Stopping the Advanced Smart City

Brake Support (Advanced SCBS)
System Operation

The Advanced SCBS system can be
temporarily deactivated.
When the Advanced SCBS system is
turned off, the Smart City Brake Support
(SCBS) OFF indicator light turns on.

When the engine is restarted, the system
becomes operational.

Without SCBS OFF switch

Refer to Personalization Features on page
9-9.

NOTE
When the Advanced SCBS system is set to
inoperable, the Smart Brake Support
(SBS) are also set to inoperable.

When Driving

i-ACTIVSENSE

4-121

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Smart City Brake Support (SCBS)

The SCBS system alerts the driver of a possible collision using an indication in the display
and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead and
determines that a collision with a vehicle ahead is unavoidable while the vehicle is being
driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph). In addition, the system
reduces damage in the event of a collision by operating the brake control (Smart City Brake
Support (SCBS) brake) when the system determines that a collision is unavoidable while the
vehicle is being driven at a vehicle speed of about 4 to 30 km/h (2 to 18 mph). It may also
be possible to avoid a collision if the relative speed between your vehicle and the vehicle in
front of you is less than about 20 km/h (12 mph). In addition, when the driver depresses the
brake pedal while the system is in the operation range at about 4 to 30 km/h (2 to 18 mph),
the brakes are applied firmly and quickly to assist. (Brake Assist (Smart City Brake Support
(SCBS) brake assist))

Forward Sensing
Camera (FSC)

WARNING

Do not rely completely on the SCBS system:

The SCBS system is only designed to reduce damage in the event of a collision. Over reliance

on the system leading to the accelerator pedal or brake pedal being mistakenly operated
could result in an accident.

The SCBS is a system which operates in response to a vehicle ahead. The system may not be

able to detect or react to 2-wheeled vehicles or pedestrians.

When Driving

i-ACTIVSENSE

*Some models.

4-123

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

CAUTION

In the following cases, turn the system off to prevent a mis-operation:

The vehicle is being towed or when towing another vehicle.
The vehicle is on a chassis roller.
When driving on rough roads such as in areas of dense grass or off-road.

Refer to Stopping the Smart City Brake Support (SCBS) system Operation on page 4-126 on
how to turn off the SCBS system.

NOTE

•

The SCBS system will operate under the following conditions.

•

The engine is running.

•

The Smart Brake Support/Smart City Brake Support (SBS/SCBS) system warning light
(amber) does not illuminate.

•

(Rear-end collision warning)
The vehicle speed is about 4 to 80 km/h (2 to 50 mph).

•

(Brake control (Smart City Brake Support (SCBS) brake))
The vehicle speed is about 4 to 30 km/h (2 to 18 mph).

•

The SCBS system is not turned off.

•

Under the following conditions, the SCBS system may not operate normally:

•

The SCBS system will not operate if the driver is deliberately performing driving
operations (accelerator pedal and steering wheel).

•

If there is the possibility of partial contact with a vehicle ahead.

•

The vehicle is driven on a slippery road surface such as wet roads or icy or snow-bound
roads.

•

The braking performance is adversely affected due to cold temperatures or wet brakes.

•

The vehicle is driven at the same speed as the vehicle ahead.

•

The accelerator pedal is depressed.

•

The brake pedal is depressed.

•

The steering wheel is being operated.

•

The selector lever is being operated.

•

In the following cases, the Forward Sensing Camera (FSC) determines that there is a
vehicle ahead and the SCBS may operate.

•

Objects on the road at the entrance to a curve.

•

Vehicles passing in the opposite lane while making a curve.

•

Metal objects, bumps, or protruding objects on the road.

•

When passing through a toll gate.

•

When passing through low gates, narrow gates, car washing machines, or tunnels.

When Driving

i-ACTIVSENSE

4-124

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

•

If you suddenly come close to a vehicle ahead.

•

2-wheeled vehicles, pedestrians, animals or standing trees.

•

Vehicle is driven with some of the tires having significant wear.

•

(Manual transaxle)
If the vehicle is stopped by the Smart City Brake Support (SCBS) operation and the clutch
pedal is not depressed, the engine stops.

▼ Smart City Brake Support (SCBS)

Indicator Light (Red)

If the Smart City Brake Support (SCBS) is
operating, the indicator light (red) flashes.

▼ Collision Warning

If there is the possibility of a collision with
a vehicle ahead, the beep sounds
continuously and a warning is indicated in
the active driving display.

NOTE

•

(Without SCBS OFF switch)
The operation distance and volume of
the collision warning can be changed.
Refer to Personalization Features on
page 9-9.

•

(With SCBS OFF switch)
The operation distance and volume of
the collision warning can be changed.
Consult an Authorized Mazda Dealer.

▼ Automatic Brake Operation Display

The automatic brake operation display is
indicated on the active driving display
after the SCBS is operated.

NOTE

•

The collision warning beep sounds
intermittently while the SCBS brake or
brake assist (SCBS brake assist) is
operating.

•

If the vehicle is stopped by the SCBS
operation and the brake pedal is not
depressed, the warning beep sounds one
time after about 2 seconds and the SCBS
brake is automatically released.

When Driving

i-ACTIVSENSE

4-125

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Stopping the Smart City Brake

Support (SCBS) System Operation

The SCBS system can be temporarily
deactivated.
When the SCBS system is turned off, the
Smart City Brake Support (SCBS) OFF
indicator light turns on.

When the engine is restarted, the system
becomes operational.

Without SCBS OFF switch

Refer to Personalization Features on page
9-9.

NOTE
When the SCBS system is set to
inoperable, the Smart Brake Support
(SBS) are also set to inoperable.

With SCBS OFF switch

Press the SCBS OFF switch to turn off the
system. The Smart City Brake Support
(SCBS) OFF indicator light in the
instrument cluster will illuminate.

Press the switch again to turn the system
back on. The Smart City Brake Support
(SCBS) OFF indicator light will turn off.

When Driving

i-ACTIVSENSE

4-126

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Smart Brake Support (SBS)

The SBS system alerts the driver of a possible collision using a display and warning sound
if the radar sensor (front) and the Forward Sensing Camera (FSC) determine that there is the
possibility of a collision with a vehicle ahead while the vehicle is being driven at about 15
km/h or faster (10 mph or faster). Furthermore, if the radar sensor (front) and the Forward
Sensing Camera (FSC) determines that a collision is unavoidable, the automatic brake
control is performed to reduce damage in the event of a collision.
In addition, when the driver depresses the brake pedal, the brakes are applied firmly and
quickly to assist. (Brake Assist (SBS brake assist))

WARNING

Do not rely completely on the SBS system and always drive carefully:
The SBS is designed to reduce damage in the event of a collision, not avoid an accident. The
ability to detect an obstruction is limited depending on the obstruction, weather conditions,
or traffic conditions. Therefore, if the accelerator pedal or brake pedal is mistakenly operated
it could result in an accident. Always verify the safety of the surrounding area and depress the
brake pedal or accelerator pedal while keeping a safer distance from vehicles ahead or
on-coming vehicles.

CAUTION

In the following cases, turn the system off to prevent a mis-operation:

The vehicle is being towed or when towing another vehicle.
The vehicle is on a chassis roller.
When driving on rough roads such as in areas of dense grass or off-road.

NOTE

•

The SBS system operates when all of the following conditions are met:

•

The ignition is switched ON.

•

The SBS system is on.

•

The vehicle speed is about 15 km/h or faster (10 mph or faster).

•

The relative speed between your vehicle and the vehicle ahead is about 15 km/h or
faster (10 mph or faster).

•

The Dynamic Stability Control (DSC) is not operating.

•

The SBS system may not operate under the following conditions:

•

If the vehicle is accelerated rapidly and it comes close to a vehicle ahead.

When Driving

i-ACTIVSENSE

*Some models.

4-127

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

•

The vehicle is driven at the same speed as the vehicle ahead.

•

The accelerator pedal is depressed.

•

The brake pedal is depressed.

•

The steering wheel is being operated.

•

The selector lever is being operated.

•

The turn signal is being used.

•

When the vehicle ahead is not equipped with taillights or the taillights are turned off.

•

When warnings and messages, such as a dirty windshield, related to the Forward
Sensing Camera (FSC) are being displayed in the center display.

•

Although the objects which activate the system are four-wheeled vehicles, the radar
sensor (front) could detect the following objects, determine them to be an obstruction, and
operate the SBS system.

•

Objects on the road at the entrance to a curve (including guardrails and snow banks).

•

A vehicle appears in the opposite lane while cornering or rounding a curve.

•

When crossing a narrow bridge.

•

When passing under a low gate or through a tunnel or narrow gate.

•

When entering an underground parking area.

•

Metal objects, bumps, or protruding objects on the road.

•

If you suddenly come close to a vehicle ahead.

•

When driving in areas where there is high grass or forage.

•

Two-wheeled vehicles such as motorbikes or bicycles.

•

Pedestrians or non-metallic objects such as standing trees.

•

When the system operates, the user is notified by the active driving display.

•

The SBS warning indication (amber) turns on when the system has a malfunction.
Refer to Taking Action on page 7-34.

When Driving

i-ACTIVSENSE

4-128

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Smart Brake Support (SBS)

Indicator Light (Red)

If the SBS is operating, the indicator light
(red) flashes.

▼ Collision Warning

If there is the possibility of a collision with
a vehicle ahead, the beep sounds
continuously and a warning is indicated in
the active driving display.

▼ Stopping The Smart Brake Support

(SBS) System Operation

The SBS system can be temporarily
deactivated.
Refer to Personalization Features on page
9-9.
When the SBS system is turned off, the
SBS OFF indicator light turns on.

When the engine is restarted, the system
becomes operational.

NOTE
If the SBS system operation is turned off,
the Smart City Brake Support (SCBS)
system operation is turned off
simultaneously.

When Driving

i-ACTIVSENSE

4-129

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Forward Sensing Camera (FSC)

Your vehicle is equipped with a Forward Sensing Camera (FSC). The Forward Sensing
Camera (FSC) is positioned near the rearview mirror and used by the following systems.

•

High Beam Control System (HBC)

•

Lane Departure Warning System (LDWS)

•

Traffic Sign Recognition System (TSR)

•

Advanced Smart City Brake Support (Advanced SCBS)

•

Smart City Brake Support (SCBS)

•

Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)

•

Smart Brake Support (SBS)

Forward Sensing Camera (FSC)

The Forward Sensing Camera (FSC) determines the conditions ahead of the vehicle while
traveling at night and detects traffic lanes. The distance in which the Forward Sensing
Camera (FSC) can detect objects varies depending on the surrounding conditions.

WARNING

Do not modify the suspension:
If the vehicle height or inclination is changed, the system will not be able to correctly detect
vehicles ahead. This will result in the system not operating normally or mistakenly operating,
which could cause a serious accident.

CAUTION

Do not apply accessories, stickers or film to the windshield near the Forward Sensing

Camera (FSC).
If the area in front of the Forward Sensing Camera (FSC) lens is obstructed, it will cause the
system to not operate correctly. Consequently, each system may not operate normally
which could lead to an unexpected accident.

When Driving

i-ACTIVSENSE

4-130

*Some models.

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Do not disassemble or modify the Forward Sensing Camera (FSC).

Disassembly or modification of the Forward Sensing Camera (FSC) will cause a malfunction
or mistaken operation. Consequently, each system may not operate normally which could
lead to an unexpected accident.

Heed the following cautions to assure the correct operation of the Forward Sensing Camera

(FSC).

Be careful not to scratch the Forward Sensing Camera (FSC) lens or allow it to get dirty.
Do not remove the Forward Sensing Camera (FSC) cover.
Do not place objects on the dashboard which reflect light.
Always keep the windshield glass around the camera clean by removing dirt or fogging.

Use the windshield defroster to remove fogging on the windshield.

Consult an Authorized Mazda Dealer regarding cleaning the interior side of the

windshield around the Forward Sensing Camera (FSC).

Consult an Authorized Mazda Dealer before performing repairs around the Forward

Sensing Camera (FSC).

The Forward Sensing Camera (FSC) is installed to the windshield. Consult an Authorized

Mazda Dealer for windshield repair and replacement.

When cleaning the windshield, do not allow glass cleaners or similar cleaning fluids to

get on the Forward Sensing Camera (FSC) lens. In addition, do not touch the Forward
Sensing Camera (FSC) lens.

When performing repairs around the rearview mirror, consult an Authorized Mazda

Dealer.

Consult an Authorized Mazda Dealer regarding cleaning of the camera lens.
Do not hit or apply strong force to the Forward Sensing Camera (FSC) or the area around

it. If the Forward Sensing Camera (FSC) is severely hit or if there are cracks or damage
caused by flying gravel or debris in the area around it, stop using the following systems
and consult an Authorized Mazda Dealer.

High Beam Control System (HBC)
Lane Departure Warning System (LDWS)
Traffic Sign Recognition System (TSR)
Advanced Smart City Brake Support (Advanced SCBS)
Smart City Brake Support (SCBS)
Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)
Smart Brake Support (SBS)

The direction in which the Forward Sensing Camera (FSC) is pointed has been finely

adjusted. Do not change the installation position of the Forward Sensing Camera (FSC) or
remove it. Otherwise, it could result in damage or malfunction.

Always use tires for all wheels that are of the specified size, and the same manufacturer,

brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle as the system may not operate normally.

When Driving

i-ACTIVSENSE

4-131

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

The Forward Sensing Camera (FSC) includes a function for detecting a soiled windshield

and informing the driver, however, depending on the conditions, it may not detect plastic
shopping bags, ice or snow on the windshield. In such cases, the system cannot accurately
determine a vehicle ahead and may not be able to operate normally. Always drive carefully
and pay attention to the road ahead.

NOTE

•

In the following cases, the Forward Sensing Camera (FSC) cannot detect target objects
correctly, and each system may be unable to operate normally.

•

The height of the vehicle ahead is low.

•

You drive your vehicle at the same speed as the vehicle ahead.

•

Headlights are not turned on during the night or when going through a tunnel.

•

In the following cases, the Forward Sensing Camera (FSC) may not be able to detect
target objects correctly.

•

Under bad weather condition, such as rain, fog and snow.

•

The window washer is being used or the windshield wipers are not used when it's
raining.

•

Ice, fog, snow, frost, rainfall, dirt, or foreign matter such as a plastic bag is stuck on the
windshield.

•

Trucks with low loading platforms and vehicles with an extremely low or high profile.

•

When driving next to walls with no patterning (including fences and longitudinally
striped walls).

•

The taillights of the vehicle ahead are turned off.

•

A vehicle is outside the illumination range of the headlights.

•

The vehicle is making a sharp turn, or ascending or descending a steep slope.

•

Entering or exiting a tunnel.

•

Heavy luggage is loaded causing the vehicle to tilt.

•

Strong light is shone at the front of the vehicle (back light or high-beam light from
on-coming vehicles).

•

There are many light emitters on the vehicle ahead.

•

When the vehicle ahead is not equipped with taillights or the taillights are turned off at
nighttime.

•

Elongated luggage or cargo is loaded onto installed roof rails and covers the Forward
Sensing Camera (FSC).

•

Exhaust gas from the vehicle in front, sand, snow, and water vapor rising from
manholes and grating, and water splashed into the air.

•

When towing a malfunctioning vehicle.

•

The vehicle is driven with tires having significantly different wear.

•

The vehicle is driven on down slopes or bumpy roads.

•

There are water puddles on the road.

When Driving

i-ACTIVSENSE

4-132

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

•

The surroundings are dark such as during the night, early evening, or early morning, or
in a tunnel or indoor parking lot.

•

The illumination brightness of the headlights is reduced or the headlight illumination is
weakened due to dirt or a deviated optical axis.

•

The target object enters the blind spot of the Forward Sensing Camera (FSC).

•

A person or object bursts onto the road from the shoulder or cuts right in front of you.

•

You change lanes and approach a vehicle ahead.

•

When driving extremely close to the target object.

•

Tire chains or a temporary spare tire is installed.

•

The vehicle ahead has a special shape. For example, a vehicle towing a trailer house or
a boat, or a vehicle carrier carrying a vehicle with its front pointed rearward.

•

If the Forward Sensing Camera (FSC) cannot operate normally due to backlight or fog,
the system functions related to the Forward Sensing Camera (FSC) are temporarily
stopped and the following warning lights turn on. However, this does not indicate a
malfunction.

•

High Beam Control System (HBC) warning light (amber)

•

Lane Departure Warning System (LDWS) warning light

•

Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) warning light

•

Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning light (amber)

•

If the Forward Sensing Camera (FSC) cannot operate normally due to high temperatures,
the system functions related to the Forward Sensing Camera (FSC) are temporarily
stopped and the following warning lights turn on. However, this does not indicate a
malfunction. Cool down the area around the Forward Sensing Camera (FSC) such as by
turning on the air conditioner.

•

High Beam Control System (HBC) warning light (amber)

•

Lane Departure Warning System (LDWS) warning light

•

Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) warning light

•

Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning light (amber)

•

If the Forward Sensing Camera (FSC) detects that the windshield is dirty or foggy, the
system functions related to the Forward Sensing Camera (FSC) are temporarily stopped
and the following warning lights turn on. However, this does not indicate a problem.
Remove the dirt from the windshield or press the defroster switch and defog the
windshield.

•

High Beam Control System (HBC) warning light (amber)

•

Lane Departure Warning System (LDWS) warning light

When Driving

i-ACTIVSENSE

4-133

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

•

Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go
function) warning light

•

Smart Brake Support/Smart City Brake Support (SBS/SCBS) warning light (amber)

•

If there are recognizable cracks or damage caused by flying gravel or debris on the
windshield, always have the windshield replaced. Consult an Authorized Mazda Dealer
for replacement.

•

(With Advanced Smart City Brake Support (Advanced SCBS))

•

The Forward Sensing Camera (FSC) recognizes pedestrians when all of the following
conditions are met:

•

The height of a pedestrian is about 1 to 2 meters.

•

An outline such as the head, both shoulders, or the legs can be determined.

•

In the following cases, the Forward Sensing Camera (FSC) may not be able to detect
target objects correctly:

•

Multiple pedestrians are walking, or there are groups of people.

•

A pedestrian is close to a separate object.

•

A pedestrian is crouching, lying, or slouching.

•

A pedestrian suddenly jumps into the road right in front of the vehicle.

•

A pedestrian opens an umbrella, or is carrying large baggage or articles.

•

A pedestrian is in a dark location such as during the night, or blends into the
background by wearing clothes matching the background color.

When Driving

i-ACTIVSENSE

4-134

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Radar Sensor (Front)

Your vehicle is equipped with a radar sensor (front).
The following systems also use the radar sensor (front).

•

Distance Recognition Support System (DRSS)

•

Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function)

•

Smart Brake Support (SBS)

The radar sensor (front) functions by detecting the radio waves reflected off a vehicle ahead
or an obstruction sent from the radar sensor.
The radar sensor (front) is mounted behind the front emblem.

Radar sensor (front)

If the Smart Brake Support/Smart City Brake Support (SBS/SCBS) Warning Light (amber)
is illuminated, the area around the radar sensor may be dirty. Refer to “Warning Guidance”
in the center display (Type B audio).
Refer to If a Warning Light Turns On or Flashes on page 7-27.

CAUTION

Heed the following precautions to assure correct operation of each system.

Do not adhere stickers (including transparent stickers) to the surface of the radiator grille

and front emblem in and around the radar sensor (front), and do not replace the radiator
grille and front emblem with any product that is not a genuine product designed for use
with the radar sensor (front).

The radar sensor (front) includes a function for detecting soiling of the radar sensor's front

surface and informing the driver, however, depending on the conditions, it may require
time to detect or it may not detect plastic shopping bags, ice or snow. If this occurs, the
system may not operate correctly, therefore always keep the radar sensor (front) clean.

Do not install a grille guard.
If the front part of the vehicle has been damaged in a vehicle accident, the position of the

radar sensor (front) may have moved. Stop the system immediately and always have the
vehicle inspected at an Authorized Mazda Dealer.

When Driving

i-ACTIVSENSE

*Some models.

4-135

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Mazda CX-3 (2019 year). Manual - part 16
