Mazda CX-3 (2019 year). Manual

Operational Range

The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.

NOTE
When the battery power is low, or in
places where there are high-intensity radio
waves or noise, the operational range may
become narrower or the system may not
operate. For determining battery
replacement, Refer to Keyless Entry
System on page 3-3.

▼ Locking, Unlocking the Doors and

the Liftgate

Exterior antenna

Operational range

80 cm (31in)

Lock

Exterior antenna

Operational range

80 cm (31in)

Unlock

NOTE

•

The system may not operate if you are
too close to the windows or door
handles, or liftgate.

•

If the key is left in the following areas
and you leave the vehicle, the doors may
be locked depending on the radio wave
conditions even if the key is left in the
vehicle.

•

Around the dashboard

•

In the storage compartments such as
the glove compartment or the center
console

•

Next to a communication device such
as a mobile phone

▼ Opening the Liftgate

Exterior antenna

80 cm(31in)

Operational range

Before Driving

Advanced Keyless Entry System

3-10

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Door Locks

WARNING

Always take all children and pets with you
or leave a responsible person with them:
Leaving a child or a pet unattended in a
parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle can
become high enough to cause brain
damage or even death.

Do not leave the key in your vehicle with
children and keep them in a place where
your children will not find or play with
them:
Leaving children in a vehicle with the key is
dangerous. This could result in someone
being badly injured or even killed.

Keep all doors locked when driving:
Unlocked doors in a moving vehicle are
dangerous. Passengers can fall out if a
door is accidentally opened and can more
easily be thrown out in an accident.

Always close all the windows and
moonroof, lock the doors and the liftgate
and take the key with you when leaving
your vehicle unattended:
Leaving your vehicle unlocked is dangerous
as children could lock themselves in a hot
vehicle, which could result in death. Also, a
vehicle left unlocked becomes an easy
target for thieves and intruders.

After closing the doors and the liftgate,
always verify that they are securely closed:
Doors and the liftgate not securely closed
are dangerous, if the vehicle is driven with
a door and the liftgate not securely closed,
the door and the liftgate could open
unexpectedly resulting in an accident.

Always confirm the safety around the
vehicle before opening a door and the
liftgate:
Suddenly opening a door and the liftgate is
dangerous. A passing vehicle or a
pedestrian could be hit and cause an
accident.

CAUTION

Always confirm the conditions around

the vehicle before opening/closing the
doors and the liftgate and use caution
during strong winds or when parked on
an incline. Not being aware of the
conditions around the vehicle is
dangerous because fingers could get
caught in the door and the liftgate or a
passing pedestrian could be hit, resulting
in an unexpected accident or injury.

Before Driving

Doors and Locks

3-11

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

NOTE

•

Always stop the engine and lock the
doors. In addition, to prevent theft of
valuables, do not leave them inside the
cabin.

•

If the key is left in the following areas
and you leave the vehicle, the doors may
be locked depending on the radio wave
conditions even if the key is left in the
vehicle.

•

Around the dashboard

•

In the storage compartments such as
the glove compartment or the center
console

•

Next to a communication device such
as a mobile phone

•

When the ignition is switched to ACC or
ON, the vehicle lock-out prevention
feature prevents you from locking
yourself out of the vehicle.
All doors and the liftgate will
automatically unlock if they are locked
using the power door locks with any
door or the liftgate open.
The vehicle lock-out prevention feature
does not operate while the ignition is
switched off.
When all doors and the liftgate are
locked using the power door lock with
any door or the liftgate open, the closed
doors and the liftgate are locked. After
that, when all doors and the liftgate are
closed, all doors and the liftgate are
locked. However, if the key is inside the
vehicle, all doors and the liftgate are
automatically unlocked.

(With the advanced keyless function)
The beep sound is heard for about 10
seconds to notify the driver that the key
has been left in the vehicle.
(Without the advanced keyless
function)
The horn sound is heard twice to notify
the driver that the key has been left in
the vehicle.

•

(Door unlock (control) system with
collision detection)
This system automatically unlocks the
doors and the liftgate in the event the
vehicle is involved in an accident to
allow passengers to get out of the
vehicle immediately and prevent being
trapped inside. While the ignition is
switched ON and in the event the vehicle
receives an impact strong enough to
inflate the air bags, all the doors and the
liftgate are automatically unlocked after
about 6 seconds have elapsed from the
time of the accident.
The doors and the liftgate may not
unlock depending on how an impact is
applied, the force of the impact, and
other conditions of the accident.
If door-related systems or the battery is
malfunctioning, the doors and the
liftgate will not unlock.

Before Driving

Doors and Locks

3-12

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Locking, Unlocking with Auxiliary

Key

Turn the auxiliary key toward the front to
lock, toward the back to unlock.

To lock

All doors and the liftgate lock
automatically when the driver's door is
locked using the auxiliary key.

To unlock

The driver’s door unlocks when the
auxiliary key is turned briefly to the
unlock position and then immediately
returned to the center position.
All doors and the liftgate unlock when the
driver's door is unlocked and the auxiliary
key is held in the unlock position for one
second or longer.

Lock

Unlock

▼ Locking, Unlocking with Request

Switch (With the advanced keyless
function)

All doors and the liftgate can be locked/
unlocked by pressing the request switch on
the front doors while the key is being
carried.

The request switch on the liftgate can only
be used to lock all doors and the liftgate.
Front doors

Request switch

Liftgate (Lock only)

Request switch

Before Driving

Doors and Locks

3-13

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

To lock

To lock the doors and the liftgate, press the
request switch and the hazard warning
lights will flash once.
A beep sound will be heard once.

To unlock

Driver's door request switch

To unlock the driver's door, press the
request switch. A beep sound will be heard
twice and the hazard warning lights will
flash twice.
To unlock all doors and the liftgate, press
the request switch again within three
seconds and two more beep sounds will be
heard.

Front passenger door request switch

To unlock all doors and the liftgate, press
the request switch. A beep sound will be
heard twice and the hazard warning lights
will flash twice.

NOTE

•

The system can be set to unlock all
doors by performing a single operation.
Refer to Personalization Features on
page 9-9.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all

of the doors and the liftgate.

2. Open the driver's door.

3. Within 30 seconds of opening the

driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer (the sound of the
doors locking/unlocking can be
heard).
After this, the system switches the
setting of pressing the driver's
request switch once or twice to
unlock all doors and the liftgate
each time the UNLOCK button is
pressed (the sound of the doors
locking/unlocking can be heard).

4. The setting change is completed by

doing any one of the following:

•

Switching the ignition to ACC or
ON.

•

Closing the driver's door.

•

Opening the liftgate.

•

Not operating the key for ten
seconds.

•

Pressing any button except the
UNLOCK button on the key.

•

Pressing a request switch.

•

Confirm that all doors and the liftgate
are securely locked.
For the liftgate, move it without pressing
the electric liftgate opener to verify that
the liftgate has not been left ajar.

•

All doors and the liftgate cannot be
locked when any door or the liftgate is
open.

•

It may require a few seconds for the
doors to unlock after the request switch
is pressed.

•

A beep sound is heard for confirmation
when the doors and the liftgate are
locked/unlocked using the request
switch. If you prefer, the beep sound can
be turned off.

Before Driving

Doors and Locks

3-14

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

The volume of the beep sound can also
be changed. Refer to Personalization
Features on page 9-9.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all

of the doors and the liftgate.

2. Open the driver's door.
3. Within 30 seconds of opening the

driver's door, press and hold the
LOCK button on the key for 5
seconds or longer (All of the doors
and the liftgate are locked and
unlocked when the LOCK button on
the key is pressed and held for 5
seconds.).
The beep sound activates at the
currently set volume. The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)

4. The setting change is completed by

doing any one of the following:

•

Switching the ignition to ACC or
ON.

•

Closing the driver's door.

•

Opening the liftgate.

•

Not operating the key for ten
seconds.

•

Pressing any button except the
LOCK button on the key.

•

Pressing a request switch.

•

(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-41.

•

The setting can be changed so that the
doors and the liftgate are locked
automatically without pressing the
request switch.
Refer to Personalization Features on
page 9-9.
(Walk-away auto lock function)
A beep sound is heard when all doors
and the liftgate are closed while the
advanced key is being carried. All doors
and the liftgate are locked automatically
after about three seconds when the
advanced key is out of the operational
range. Also, the hazard warning lights
flash once. (Even if the driver is in the
operational range, all doors and the
liftgate are locked automatically after
about 30 seconds.) If you are out of the
operational range before the doors and
the liftgate are completely closed or
another key is left in the vehicle, the
walk-away auto lock function will not
work. Always make sure that all doors
and the liftgate are closed and locked
before leaving the vehicle. The
walk-away auto lock function does not
close the power windows.

•

(Auto re-lock function)
After unlocking with the request switch,
all doors and the liftgate will
automatically lock if any of the
following operations are not performed
within about 60 seconds. If your vehicle
has a theft-deterrent system, the hazard
warning lights will flash for
confirmation.

Before Driving

Doors and Locks

3-15

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

The time required for the doors to lock
automatically can be changed.
Refer to Personalization Features on
page 9-9.

•

Opening a door or the liftgate.

•

Switching the ignition to any position
other than off.

▼ Locking, Unlocking with

Transmitter

All doors and the liftgate can be locked/
unlocked by operating the keyless entry
system transmitter, refer to Keyless Entry
System (page 3-3).

▼ Locking, Unlocking with Door-Lock

Switch

All doors and the liftgate lock
automatically when the lock side is
pressed. They unlock when the unlock
side is pressed.
Driver's door

Lock

Unlock

Front passenger's door

Unlock

Lock

To lock all the doors and the liftgate from
an open front door, press the lock side of
the door lock switch and then close the
door.

NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.

▼ Auto Lock/Unlock Function

WARNING

Do not pull the inner handle on a front
door:
Pulling the inner handle on a front door
while the vehicle is moving is dangerous.
Passengers can fall out of the vehicle if the
door opens accidentally , which could
result in death or serious injury.

•

When the vehicle speed exceeds 20
km/h (12 mph), all doors and the liftgate
lock automatically.

•

When the ignition is switched off, all
doors and the liftgate unlock
automatically.

These functions can also be disabled so
that they do not operate.

Before Driving

Doors and Locks

3-16

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Auto lock/unlock function setting
change using door-lock switch

The doors and the liftgate can be set to
lock or unlock automatically by selecting
any one of the functions from the
following table and using the driver's
door-lock switch on the interior door
panel.

NOTE

•

Function number 3 in the following
table is the factory setting for your
vehicle.

•

There are only a total of six auto lock/
unlock settings available for automatic
transaxle vehicles, and three for manual
transaxle vehicles. Be sure to press the
unlock side of the driver's door-lock
switch the correct number of times
according to the selected function
number. If the switch is mistakenly
pressed seven times on an automatic
transaxle vehicle or four times on a
manual transaxle, the procedure will be
cancelled. If this occurs, start the
procedure from the beginning.

Function

number

Function

The auto door-lock function is disa-
bled.

All the doors and the liftgate lock au-
tomatically when the vehicle speed is
about 20 km/h (12 mph) or more.

3 (Factory

Setting)

All the doors and the liftgate lock au-
tomatically when the vehicle speed is
about 20 km/h (12 mph) or more. All
the doors and the liftgate unlock
when the ignition is switched from
ON to Off.

Function

number

Function

(Automatic transaxle vehicles only)
When the ignition is switched ON
and the selector lever is shifted from
park (P) to any other gear position, all
the doors and the liftgate lock auto-
matically.
When the selector lever is shifted to
park (P) while the ignition is switched
ON, all the doors and the liftgate un-
lock automatically.

(Automatic transaxle vehicles only)
All the doors and the liftgate lock au-
tomatically when the vehicle speed is
about 20 km/h (12 mph) or more.
When the selector lever is shifted to
park (P) while the ignition is switched
ON, all the doors and the liftgate un-
lock automatically.

1 Other settings for the auto door lock function are

available at an Authorized Mazda Dealer. For
details consult an Authorized Mazda Dealer.
Refer to Personalization Features on page 9-9.

Settings can be changed using the
following procedure.
1. Safely park the vehicle. All doors and

the liftgate must remain closed.

2. Switch the ignition ON.
3. Press and hold the lock side of the

driver's door-lock switch within 20
seconds of switching the ignition ON,
and make sure a beep sound is heard
about eight seconds afterwards.

Before Driving

Doors and Locks

3-17

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

4. Refer to the auto lock/unlock function

setting table, determine the function
number for the desired setting. Press
the unlock side of the driver's
door-lock switch the same number of
times as the selected function number
(Ex. If you select function 2, press the
unlock side of the switch only 2 times).

5. Three seconds after the function

setting has been changed, a beep sound
will beep in the amount of the selected
function number. (Ex. Function
number 3 = 3 beep sounds)

(Manual transaxle vehicles)

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Function Number 3

Press 4 times

Press unlock side of
lock switch once

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

(Automatic transaxle vehicles)

Press unlock side of
lock switch once

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Press 4 times

Function Number 3

Press 5 times

Function Number 4

Press 7 times

Function Number 5

Press 6 times

Function Number 6

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

NOTE

•

The doors and the liftgate cannot be
locked or unlocked while the setting
function is being performed.

•

The procedure can be cancelled by
pressing the lock side of the driver's
door-lock switch.

▼ Locking, Unlocking with Door-Lock

Knob

Operation from inside

To lock any door from the inside, press the
door-lock knob.
To unlock, pull it outward.

Before Driving

Doors and Locks

3-18

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

This does not operate the other door locks.

Lock

Unlock

Unlocked: Red indicator

Operation from outside

To lock any door using its door-lock knob
from the outside, press the door-lock knob
to the lock position and close the door
(holding the door handle in the open
position is not required).
This does not operate the other door locks.

Door-lock knob

NOTE
When locking the door this way:

•

Be careful not to leave the key inside the
vehicle.

•

The doors cannot be locked using the
driver's door lock knob if any door is
open when the ignition is switched to
ACC or ON.

▼ Rear Door Child Safety Locks

These locks are intended to help prevent
children from accidentally opening the
rear doors. Use them on both rear doors
whenever a child rides in the rear seat of
the vehicle.

If you slide the child safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can only be opened by pulling
the outside handle.

Lock

Unlock

Before Driving

Doors and Locks

3-19

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Liftgate

WARNING

Never allow a person to ride in the luggage
compartment:
Allowing a person to ride in the luggage
compartment is dangerous. The person in
the luggage compartment could be
seriously injured or killed during sudden
braking or a collision.

Do not drive with the liftgate open:
Exhaust gas in the cabin of a vehicle is
dangerous. An open liftgate in a moving
vehicle will cause exhaust gas to be drawn
into the cabin. This gas contains CO
(carbon monoxide), which is colorless,
odorless, and highly poisonous, and it can
cause loss of consciousness and death.
Moreover, an open liftgate could cause
occupants to fall out in an accident.

Do not stack or leave loaded luggage
unsecured in the luggage compartment:
Otherwise, the luggage may move or
collapse, resulting in injury or an accident.
In addition, do not load luggage higher
than the seatbacks. It may affect the side or
rear field of view.

CAUTION

Before opening the liftgate, remove any

snow and ice accumulation on it.
Otherwise, the liftgate could close under
the weight of the snow and ice resulting
in injury.

Be careful when opening/closing the

liftgate during strong winds. If a strong
gust blows against the liftgate, it could
close suddenly resulting in injury.

Fully open the liftgate and make sure

that it stays open. If the liftgate is only
opened partially, it could slam shut by
vibration or wind gusts resulting in
injury.

When loading or unloading luggage in

the luggage compartment, turn off the
engine. Otherwise, you could get burned
by the heat of the exhaust gas.

Be careful not to apply excessive force to

the damper stay on the liftgate such as
by putting your hand on the stay.
Otherwise, the damper stay may bend
and affect the liftgate operation.

Damper stay

Do not modify or replace the liftgate

damper stay. Consult an Authorized
Mazda Dealer if a liftgate damper stay is
deformed or damaged for reasons such
as a collision or if there is some other
problem.

Before Driving

Doors and Locks

3-20

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Opening and Closing the Liftgate

Opening the liftgate with Electric
liftgate opener

Unlock the doors and liftgate, then press
the electric liftgate opener on the liftgate
and raise the liftgate when the latch
releases.

Electric liftgate
opener

NOTE
(With the advanced keyless function)

•

A locked liftgate can also be opened
while the key is being carried.

•

When opening the liftgate with the doors
and the liftgate locked, it may require a
few seconds for the liftgate latch to
release after the electric liftgate opener
is pressed.

•

The liftgate can be closed when the
doors are locked with the key left in the
vehicle. However, to prevent locking the
key in the vehicle, the liftgate can be
opened by pressing the electric liftgate
opener. If the liftgate cannot be opened
despite doing this procedure, first push
the liftgate completely closed, then press
the electric liftgate opener to fully open
the liftgate.

•

When the liftgate latch is released by
pressing the electric liftgate opener, the
liftgate raises slightly. If the liftgate is
not operated for a certain period of
time, the liftgate cannot be raised.
To open
Press the electric liftgate opener again.
To close
To close the liftgate from its slightly
raised position, open it first by pressing
the electric liftgate opener, then close it
after waiting at least 1 second.

•

If the liftgate is not fully closed, the
driver is notified by a warning indicated
in the instrument cluster.

•

If the vehicle battery is dead or there is
a malfunction in the electrical system
and the liftgate cannot be unlocked, the
liftgate can be opened by performing the
emergency procedure.
Refer to When Liftgate Cannot be
Opened on page 7-48.

Before Driving

Doors and Locks

3-21

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Closing the liftgate

CAUTION

(With luggage board)
When closing the liftgate, return the
luggage board to its original position. If the
liftgate is closed with the luggage board
standing upright, the luggage
compartment cover could be damaged.

Luggage compartment cover

Luggage board

Lower the liftgate slowly using the liftgate
grip recess, then push the liftgate closed
using both hands.
Do not slam it. Pull up on the liftgate to
make sure it is secure.

Liftgate grip recess

NOTE
Confirm that the liftgate is securely closed.
The liftgate, move it without pressing the
electric liftgate opener to verify that the
liftgate has not been left ajar.

▼ Luggage Compartment

Luggage compartment cover

WARNING

Do not place anything on top of the cover:
Placing luggage or other cargo on top of
the luggage compartment cover is
dangerous. During sudden braking or a
collision, the cargo could become a
projectile that could hit and injure
someone. The vehicle has a light weight
luggage compartment cover to keep the
contents of your luggage area out of sight;
it will not retain heavy objects that are not
tied down in an accident such as a rollover.
Tie down all heavy objects, whether
luggage or cargo, using the tie down
hooks.

Make sure luggage and cargo are secured
before driving:
Not securing cargo while driving is
dangerous as it could move or be crushed
during sudden braking or a collision and
cause injury.

CAUTION

Make sure the luggage compartment cover
is firmly secured. If it is not firmly secured, it
could unexpectedly disengage resulting in
injury.

Before Driving

Doors and Locks

3-22

*Some models.

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

The luggage compartment can be accessed
by opening the liftgate when the straps are
attached to the sides of the liftgate.

Strap

Removing the cover

This cover can be removed for more room.
1. Remove the straps from the hooks.
2. Lift the end of the luggage

compartment cover a little, pull it
outward, and remove it from the pins.

3. Lift the front end of the luggage

compartment cover and remove it.

Before Driving

Doors and Locks

3-23

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Fuel and Engine Exhaust Precautions

▼ Fuel Requirements

Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.

This vehicle will perform best with fuel listed in the table.

Fuel

Octane Rating

(Anti-knock index)

Regular unleaded fuel

87 [(R M)/2 method] or above (91 RON or above)

∗ U.S. federal law requires that octane ratings be posted on gasoline station pumps.

Fuel with a rating lower than 87 octane (91 RON) will negatively affect the emission control
system performance and could also cause engine knocking and serious engine damage.

CAUTION

USE ONLY UNLEADED FUEL.

Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead to
deterioration of the emission control system and or failures.

This vehicle can only use oxygenated fuels containing no more than 10 % ethanol by

volume. Damage to the vehicle may occur when ethanol exceeds this recommendation, or
if the gasoline contains any methanol. Stop using gasohol of any kind if your vehicle engine
is performing poorly.

Never add fuel system additives, otherwise the emission control system could be damaged.

Consult an Authorized Mazda Dealer for details.

Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".

Vehicle damage and drivability problems resulting from the use of the following may not be
covered by the warranty.

•

Gasohol containing more than 10 % ethanol.

•

Gasoline or gasohol containing methanol.

•

Leaded fuel or leaded gasohol.

Before Driving

Fuel and Emission

3-24

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Emission Control System

This vehicle is equipped with an emission control system (the catalytic converter is part of
this system) that enables the vehicle to comply with existing exhaust emissions
requirements.

WARNING

Never park over or near anything flammable:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with the
engine turned off, the exhaust system remains very hot after normal use and could ignite
anything flammable. A resulting fire could cause serious injury or death.

CAUTION

Ignoring the following precautions could cause lead to accumulate on the catalyst inside the
converter or cause the converter to get very hot. Either condition will damage the converter
and cause poor performance.

USE ONLY UNLEADED FUEL.
Do not drive your Mazda with any sign of engine malfunction.
Do not coast with the ignition switched off.
Do not descend steep grades in gear with the ignition switched off.
Do not operate the engine at high idle for more than 2 minutes.
Do not tamper with the emission control system. All inspections and adjustments must be

made by a qualified technician.

Do not push-start or pull-start this vehicle.

NOTE

•

Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.

•

While the engine is off, the sound of a valve opening and closing can be heard at the rear
of the vehicle, however this does not indicate an abnormality. The vehicle has a
self-checking device and it operates while the engine is off.

Before Driving

Fuel and Emission

3-25

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Mazda CX-3 (2019 year). Manual - part 6
