Mazda 3 Hatchback (2018 year). Manual

To use the auxiliary key, pull out the
auxiliary key from the transmitter while
pressing the knob.

Knob

Keyless Entry System

This system uses the key buttons to
remotely lock and unlock the doors and
the liftgate/trunk lid, and opens the trunk
lid.
The system can start the engine without
having to take the key out of your purse or
pocket.
It can also help you signal for attention or
help.
Operating the theft-deterrent system is
also possible on theft-deterrent
system-equipped vehicles.

System malfunctions or warnings are
indicated by the following warning lights
or beeps.



KEY Warning Light (Red)
Refer to Warning/Indicator Lights on
page 4-23.



Ignition Not Switched Off (STOP)
Warning Beep
Refer to Ignition Not Switched Off
(STOP) Warning Beep on page 7-39.



Key Removed from Vehicle Warning
Beep
Refer to Key Removed from Vehicle
Warning Beep on page 7-39.

If you have a problem with the key,
consult an Authorized Mazda Dealer.

If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to make the
lost or stolen key inoperative.

Before Driving

Keys

3-3

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

CAUTION

Radio equipment like this is governed by
laws in the United States.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority
to operate the equipment.

NOTE



The keyless entry system operation may
vary due to local conditions.



The keyless entry system is fully
operational (door/liftgate/trunk lid lock/
unlock) when the ignition is switched
off. The system does not operate if the
ignition is switched to any position other
than off.



If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be weak. To install a new battery,
refer to Key Battery Replacement (page
6-35).



Battery life is about one year. Replace
the battery with a new one if the KEY
indicator light (green) flashes in the
instrument cluster. Replacing the battery
about once a year is recommended
because the KEY warning light/
indicator light may not illuminate or
flash depending on the rate of battery
depletion.



Additional keys can be obtained at an
Authorized Mazda Dealer. Up to 6 keys
can be used with the keyless functions
per vehicle. Bring all keys to an
Authorized Mazda Dealer when
additional keys are required.

▼ Transmitter

Operation buttons

Operation indicator light

NOTE



(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-43.



(With the advanced keyless function)
A beep sound can be heard for
confirmation when the doors and the
liftgate/trunk lid are locked/unlocked
using the key. If you prefer, the beep
sound can be turned off.
The volume of the beep sound can also
be changed.
Refer to Personalization Features on
page 9-12.

Use the following procedure to change the
setting.
1. Switch the ignition off and close all of

the doors and the liftgate/trunk lid.

2. Open the driver's door.

Before Driving

Keys

3-4

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

3. Within 30 seconds of opening the

driver's door, press and hold the LOCK
button on the key for 5 seconds or
longer (All of the doors and the liftgate
are locked and unlocked when the
LOCK button on the key is pressed and
held for 5 seconds.).
The beep sound activates at the
currently set volume. The setting
changes each time the LOCK button on
the key is pressed and the beep sound
activates at the set volume. (If the beep
sound has been set to not activate, it
will not activate.)

4. The setting change is completed by

doing any one of the following:



Switching the ignition to ACC or
ON.



Closing the driver's door.



Opening the liftgate/trunk lid.



Not operating the key for ten
seconds.



Pressing any button except the
LOCK button on the key.



Pressing a request switch.

The operation indicator light flashes when
the buttons are pressed.

Lock button

To lock the doors and the liftgate/trunk lid,
press the lock button and the hazard
warning lights will flash once.
(With the advanced keyless function)
A beep sound will be heard once.

To confirm that all doors and the liftgate/
trunk lid have been locked, press the lock
button again within 5 seconds. If they are
closed and locked, the horn will sound.

NOTE



The doors and the liftgate/trunk lid can
be locked by pressing the lock button
while any other door or the liftgate/
trunk lid is open. The hazard warning
lights will not flash.
When the lock button is pressed while
any door is open and then the door is
closed, all the doors and the liftgate/
trunk lid are locked.



Confirm that all doors and the liftgate/
trunk lid are locked visually or audibly
by use of the double click.



Make sure all doors and the liftgate/
trunk lid are locked after pressing the
button.



(With theft-deterrent system)
When the doors are locked by pressing
the lock button on the key while the
theft-deterrent system is armed, the
hazard warning lights will flash once to
indicate that the system is armed.

Before Driving

Keys

3-5

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Unlock button

To unlock the driver's door, press the
unlock button and the hazard warning
lights will flash twice.
(With the advanced keyless function)
A beep sound will be heard twice.

To unlock all doors and the liftgate/trunk
lid, press the unlock button again within
three seconds and two more beep sounds
will be heard.

NOTE



The system can be set to unlock all
doors by performing a single operation.
Refer to Personalization Features on
page 9-12.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all

of the doors and the liftgate/trunk
lid.

2. Open the driver's door.
3. Within 30 seconds of opening the

driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer (the sound of the
doors locking/unlocking can be
heard).
After this, the system switches the
setting each time the UNLOCK
button is pressed (the sound of the
doors locking/unlocking can be
heard).

4. The setting change is completed by

doing any one of the following:



Switching the ignition to ACC or
ON.



Closing the driver's door.



Opening the liftgate/trunk lid.



Not operating the key for ten
seconds.



Pressing any button except the
UNLOCK button on the key.



Pressing a request switch.



(Auto re-lock function)
After unlocking with the key, all doors
and the liftgate/trunk lid will
automatically lock if any of the
following operations are not performed
within about 60 seconds. If your vehicle
has a theft-deterrent system, the hazard
warning lights will flash for
confirmation.
The time required for the doors to lock
automatically can be changed.
Refer to Personalization Features on
page 9-12.



A door or the liftgate/trunk lid is
opened.



The ignition is switched to any
position other than off.



(With theft-deterrent system)
When the doors are unlocked by
pressing the unlock button on the key
while the theft-deterrent system is turned
off, the hazard warning lights will flash
twice to indicate that the system is
turned off.

Before Driving

Keys

3-6

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Trunk button (4–door)

To open the trunk lid, press and hold the
trunk button until the trunk lid opens.

Panic button

If you witness from a distance someone
attempting to break into or damage your
vehicle, press and hold the panic button to
activate the vehicle's alarm. Call
emergency services if necessary.

NOTE
The panic button will work whether any
door or the liftgate/trunk lid is open or
closed.

(Turning on the alarm)

Pressing the panic button for 1 second or
more will trigger the alarm for about 2
minutes and 30 seconds, and the following
will occur:



The horn sounds intermittently.



The hazard warning lights flash.

(Turning off the alarm)

The alarm stops by pressing any button on
the key.

▼ Operational Range

The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.

Starting the Engine

NOTE



Starting the engine may be possible even
if the key is outside of the vehicle and
extremely close to a door and window,
however, always start the engine from
the driver's seat.
If the vehicle is started and the key is not
in the vehicle, the vehicle will not restart
after it is shut off and the ignition is
switched to off.



The luggage compartment/trunk is out of
the assured operational range, however,
if the key (transmitter) is operable the
engine will start.

With the advanced keyless function

Interior antenna

Operational range

Before Driving

Keys

3-7

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Without the advanced keyless function

Operational range

Interior antenna

NOTE
The engine may not start if the key is
placed in the following areas:



Around the dashboard



In the storage compartments such as the
glove compartment or the center console



On the rear parcel shelf (4–door)

▼ Key Suspend Function

If a key is left in the vehicle, the functions
of the key left in the vehicle are
temporarily suspended to prevent theft of
the vehicle.
To restore the functions, press the unlock
button on the functions-suspended key in
the vehicle.

Before Driving

Keys

3-8

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Advanced Keyless Entry

System

WARNING

Radio waves from the key may affect
medical devices such as pacemakers:
Before using the key near people who use
medical devices, ask the medical device
manufacturer or your physician if radio
waves from the key will affect the device.

The advanced keyless function allows you
to lock/unlock the door and the liftgate, or
open the liftgate/trunk lid while carrying
the key.

System malfunctions or warnings are
indicated by the following warning beeps.



Request switch Inoperable Warning
Beep
Refer to Request Switch Inoperable
Warning Beep (With the advanced
keyless function) on page 7-39.



Key Left-in-luggage Compartment/
Trunk Warning Beep
Refer to Key Left-in-luggage
Compartment/Trunk Warning Beep
(With the advanced keyless function) on
page 7-40.



Key Left-in-vehicle Warning Beep
Refer to Key Left-in-vehicle Warning
Beep (With the advanced keyless
function) on page 7-40.

NOTE
The advanced keyless entry system
functions can be deactivated to prevent
any possible adverse effect on a user
wearing a pacemaker or other medical
device. If the system is deactivated, you
will be unable to start the engine by
carrying the key. Consult an Authorized
Mazda Dealer for details. If the advanced
keyless entry system has been deactivated,
you can start the engine by following the
procedure indicated when the key battery
goes dead.
Refer to Engine Start Function When Key
Battery is Dead on page 4-8.

Before Driving

Advanced Keyless Entry System

*Some models.

3-9

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Operational Range

The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.

NOTE
When the battery power is low, or in
places where there are high-intensity radio
waves or noise, the operational range may
become narrower or the system may not
operate. For determining battery
replacement, Refer to Keyless Entry
System on page 3-3.

▼ Locking, Unlocking the Doors and

the Liftgate/Trunk Lid

Exterior antenna

Locking only
(5-door)

Operational range

80cm (31in)

NOTE



The system may not operate if you are
too close to the windows or door
handles, or liftgate.



If the key is left in the following areas
and you leave the vehicle, the doors may
be locked depending on the radio wave
conditions even if the key is left in the
vehicle.



Around the dashboard



In the storage compartments such as
the glove compartment or the center
console



Next to a communication device such
as a mobile phone

▼ Opening the Liftgate/Trunk Lid

Exterior antenna

Operational range

80cm (31in)

Before Driving

Advanced Keyless Entry System

3-10

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Door Locks

WARNING

Always take all children and pets with you
or leave a responsible person with them:
Leaving a child or a pet unattended in a
parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle can
become high enough to cause brain
damage or even death.

Do not leave the key in your vehicle with
children and keep them in a place where
your children will not find or play with
them:
Leaving children in a vehicle with the key is
dangerous. This could result in someone
being badly injured or even killed.

Keep all doors locked when driving:
Unlocked doors in a moving vehicle are
dangerous. Passengers can fall out if a door
is accidentally opened and can more easily
be thrown out in an accident.

Always close all the windows and
moonroof, lock the doors and the liftgate/
trunk lid and take the key with you when
leaving your vehicle unattended:
Leaving your vehicle unlocked is dangerous
as children could lock themselves in a hot
vehicle, which could result in death. Also, a
vehicle left unlocked becomes an easy
target for thieves and intruders.

After closing the doors and the liftgate/
trunk lid, always verify that they are
securely closed:
Doors and the liftgate/trunk lid not
securely closed are dangerous, if the vehicle
is driven with a door and the liftgate/trunk
lid not securely closed, the door and the
liftgate/trunk lid could open unexpectedly
resulting in an accident.

Always confirm the safety around the
vehicle before opening a door and the
liftgate/trunk lid:
Suddenly opening a door and the liftgate/
trunk lid is dangerous. A passing vehicle or
a pedestrian could be hit and cause an
accident.

CAUTION

Always confirm the conditions around

the vehicle before opening/closing the
doors and the liftgate/trunk lid and use
caution during strong winds or when
parked on an incline. Not being aware of
the conditions around the vehicle is
dangerous because fingers could get
caught in the door and the liftgate/trunk
lid or a passing pedestrian could be hit,
resulting in an unexpected accident or
injury.

Before Driving

Doors and Locks

3-11

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

NOTE



Always stop the engine and lock the
doors. In addition, to prevent theft of
valuables, do not leave them inside the
cabin.



If the key is left in the following areas
and you leave the vehicle, the doors may
be locked depending on the radio wave
conditions even if the key is left in the
vehicle.



Around the dashboard



In the storage compartments such as
the glove compartment or the center
console



Next to a communication device such
as a mobile phone



When the ignition is switched to ACC or
ON, the vehicle lock-out prevention
feature prevents you from locking
yourself out of the vehicle.
All doors and the liftgate/trunk lid will
automatically unlock if they are locked
using the power door locks with any
door open.
The vehicle lock-out prevention feature
does not operate while the ignition is
switched off.
When all doors and the liftgate/trunk lid
are locked using the power door lock
with any door or the liftgate/trunk lid
open, the closed doors and the liftgate/
trunk lid are locked. After that, when all
doors and the liftgate/trunk lid are
closed, all doors and the liftgate/trunk
lid are locked. However, if the key is
inside the vehicle, all doors and the
liftgate/trunk lid are automatically
unlocked.

(With the advanced keyless function)
The beep sound is heard for about 10
seconds to notify the driver that the key
has been left in the vehicle.
(Without the advanced keyless
function)
The horn sound is heard twice to notify
the driver that the key has been left in
the vehicle.



(Door unlock (control) system with
collision detection)
This system automatically unlocks the
doors and the liftgate/trunk lid in the
event the vehicle is involved in an
accident to allow passengers to get out
of the vehicle immediately and prevent
being trapped inside. While the ignition
is switched ON and in the event the
vehicle receives an impact strong
enough to inflate the air bags, all the
doors and the liftgate/trunk lid are
automatically unlocked after about 6
seconds have elapsed from the time of
the accident.
The doors and the liftgate/trunk lid may
not unlock depending on how an impact
is applied, the force of the impact, and
other conditions of the accident.
If door-related systems or the battery is
malfunctioning, the doors and the
liftgate/trunk lid will not unlock.

Before Driving

Doors and Locks

3-12

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

▼ Locking, Unlocking with Auxiliary

Key

Turn the auxiliary key toward the front to
lock, toward the back to unlock.

To lock

All doors and the liftgate/trunk lid lock
automatically when the driver's door is
locked using the auxiliary key.

To unlock

The driver’s door unlocks when the
auxiliary key is turned briefly to the
unlock position and then immediately
returned to the center position.
All doors and the liftgate/trunk lid unlock
when the driver's door is unlocked and the
auxiliary key is held in the unlock position
for one second or longer.

Lock

Unlock

▼ Locking, Unlocking with Request

Switch (With the advanced keyless
function)

All doors and the liftgate/trunk lid can be
locked/unlocked by pressing the request
switch on the front doors while the key is
being carried.
(5–door)
The request switch on the liftgate can only
be used to lock all doors and the liftgate.

Front doors

Request switch

Liftgate (5-door Lock only)

Request switch

To lock

To lock the doors and the liftgate/trunk lid,
press the request switch and the hazard
warning lights will flash once.
A beep sound will be heard once.

To unlock

Driver's door request switch

To unlock the driver's door, press the
request switch. A beep sound will be heard
twice and the hazard warning lights will
flash twice.
To unlock all doors and the liftgate/trunk
lid, press the request switch again within
three seconds and two more beep sounds
will be heard.

Before Driving

Doors and Locks

3-13

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Front passenger door request switch

To unlock all doors and the liftgate/trunk
lid, press the request switch. A beep sound
will be heard twice and the hazard
warning lights will flash twice.

NOTE



of the doors and the liftgate/trunk
lid.

2. Open the driver's door.
3. Within 30 seconds of opening the

driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer (the sound of the
doors locking/unlocking can be
heard).
After this, the system switches the
setting of pressing the driver's
request switch once or twice to
unlock all doors and the liftgate/
trunk lid each time the UNLOCK
button is pressed (the sound of the
doors locking/unlocking can be
heard).

4. The setting change is completed by

doing any one of the following:



Switching the ignition to ACC or
ON.



Closing the driver's door.



Opening the liftgate/trunk lid.



Not operating the key for ten
seconds.



Pressing any button except the
UNLOCK button on the key.



Pressing a request switch.



Confirm that all doors and the liftgate/
trunk lid are securely locked.
For the liftgate/trunk lid, move it
without pressing the electric liftgate/
trunk lid opener to verify that the
liftgate/trunk lid has not been left ajar.



All doors and the liftgate/trunk lid
cannot be locked when any door or the
liftgate is open.



It may require a few seconds for the
doors to unlock after the request switch
is pressed.



A beep sound is heard for confirmation
when the doors and the liftgate/trunk lid
are locked/unlocked using the request
switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also
be changed. Refer to Personalization
Features on page 9-12.
Use the following procedure to change
the setting.
1. Switch the ignition off and close all

of the doors and the liftgate/trunk
lid.

2. Open the driver's door.

Before Driving

Doors and Locks

3-14

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

3. Within 30 seconds of opening the

driver's door, press and hold the
LOCK button on the key for 5
seconds or longer (All of the doors
and the liftgate are locked and
unlocked when the LOCK button on
the key is pressed and held for 5
seconds.).
The beep sound activates at the
currently set volume. The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)

4. The setting change is completed by

doing any one of the following:



Switching the ignition to ACC or
ON.



Closing the driver's door.



Opening the liftgate/trunk lid.



Not operating the key for ten
seconds.



Pressing any button except the
LOCK button on the key.



Pressing a request switch.



(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page
3-43.



The setting can be changed so that the
doors and the liftgate/trunk lid are
locked automatically without pressing
the request switch.
Refer to Personalization Features on
page 9-12.
(Auto-lock function)
A beep sound is heard when all doors
and the liftgate are closed while the
advanced key is being carried. All doors
and the liftgate/trunk lid are locked
automatically after about three seconds
when the advanced key is out of the
operational range. Also, the hazard
warning lights flash once. (Even if the
driver is in the operational range, all
doors and the liftgate/trunk lid are
locked automatically after about 30
seconds.) If you are out of the
operational range before the doors and
the liftgate/trunk lid are completely
closed or another key is left in the
vehicle, the auto-lock function will not
work. Always make sure that all doors
and the liftgate/trunk lid are closed and
locked before leaving the vehicle. The
auto-lock function does not close the
power windows.



Auto re-lock function
After unlocking with the request switch,
all doors and the liftgate/trunk lid will
automatically lock if any of the
following operations are not performed
within about 60 seconds. If your vehicle
has a theft-deterrent system, the hazard
warning lights will flash for
confirmation.
The time required for the doors to lock
automatically can be changed.
Refer to Personalization Features on
page 9-12.

Before Driving

Doors and Locks

3-15

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21



Opening a door or the liftgate/trunk
lid.



Switching the ignition to any position
other than off.

▼ Locking, Unlocking with

Transmitter

All doors and the liftgate/trunk lid can be
locked/unlocked by operating the keyless
entry system transmitter, refer to Keyless
Entry System (page 3-3).

▼ Locking, Unlocking with Door-Lock

Switch

All doors and the liftgate/trunk lid lock
automatically when the lock side is
pressed. They unlock when the unlock
side is pressed.
Driver's door

Unlock

Lock

Front passenger's door

Unlock

Lock

To lock all the doors and the liftgate/trunk
lid from an open front door, press the lock
side of the door lock switch and then close
the door.

NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.

▼ Auto Lock/Unlock Function

WARNING

Do not pull the inner handle on a front
door:
Pulling the inner handle on a front door
while the vehicle is moving is dangerous.
Passengers can fall out of the vehicle if the
door opens accidentally , which could
result in death or serious injury.



When the vehicle speed exceeds 20
km/h (12 mph), all doors and the
liftgate/trunk lid lock automatically.



When the ignition is switched off, all
doors and the liftgate/trunk lid unlock
automatically.

These functions can also be disabled so
that they do not operate.

Auto lock/unlock function setting
change using door-lock switch

The doors and the liftgate/trunk lid can be
set to lock or unlock automatically by
selecting any one of the functions from the
following table and using the driver's
door-lock switch on the interior door
panel.

Before Driving

Doors and Locks

3-16

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

NOTE



Function number 3 in the following
table is the factory setting for your
vehicle.



There are only a total of five auto lock/
unlock settings available for automatic
transaxle vehicles, and three for manual
transaxle vehicles. Be sure to press the
unlock side of the driver's door-lock
switch the correct number of times
according to the selected function
number. If the switch is mistakenly
pressed six times on an automatic
transaxle vehicle or four times on a
manual transaxle, the procedure will be
cancelled. If this occurs, start the
procedure from the beginning.

Function

number

Function

The auto door-lock function is disa-
bled.

All the doors and the liftgate/trunk lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more.

3 (Factory

Setting)

All the doors and the liftgate/trunk lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more. All the doors and the liftgate/
trunk lid unlock when the ignition is
switched from ON to Off.

Function

number

Function

(Automatic transaxle vehicles only)
When the ignition is switched ON
and the shift lever is shifted from park
(P) to any other gear position, all the
doors and the liftgate/trunk lid lock
automatically.
When the shift lever is shifted to park
(P) while the ignition is switched ON,
all the doors and the liftgate/trunk lid
unlock automatically.

1 Other settings for the auto door lock function are

available at an Authorized Mazda Dealer. For
details consult an Authorized Mazda Dealer.
Refer to Personalization Features on page 9-12.

Settings can be changed using the
following procedure.
1. Safely park the vehicle. All doors must

remain closed.

2. Switch the ignition ON.
3. Press and hold the lock side of the

driver's door-lock switch within 20
seconds of switching the ignition ON,
and make sure a beep sound is heard
about eight seconds afterwards.

4. Refer to the auto lock/unlock function

setting table, determine the function
number for the desired setting. Press
the unlock side of the driver's
door-lock switch the same number of
times as the selected function number
(Ex. If you select function 2, press the
unlock side of the switch only 2 times).

5. Three seconds after the function

setting has been changed, a beep sound
will beep in the amount of the selected
function number. (Ex. Function
number 3 = 3 beep sounds)

Before Driving

Doors and Locks

3-17

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

(Manual transaxle vehicles)

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Function Number 3

Press 4 times

Press unlock side of
lock switch once

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

(Automatic transaxle vehicles)

Press unlock side of
lock switch once

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Press 4 times

Function Number 3

Press 5 times

Function Number 4

Press 6 times

Function Number 5

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

NOTE



The doors cannot be locked or unlocked
while the setting function is being
performed.



The procedure can be cancelled by
pressing the lock side of the driver's
door-lock switch.

▼ Locking, Unlocking with Door-Lock

Knob

Operation from inside

To lock any door from the inside, press the
door-lock knob.
To unlock, pull it outward.
This does not operate the other door locks.

Lock

Unlock

Unlocked: Red indicator

Before Driving

Doors and Locks

3-18

Mazda3_8GE4-EA-17F_Edition1

2017-4-7 11:59:21

Mazda 3 Hatchback (2018 year). Manual - part 5
