LEXUS GX 460 (2019 year). Manual - part 6

Instrument cl

■

The meters and display illuminate when
The engine switch is in IGNITION ON mode.

■

Instrument cluster brightness adjustment
The instrument cluster brightness levels when the tail lights are on and off can be

adjusted.

■

The brightness of the instrument cluster lights
When the tail lights are on, the brightness will change. However, when the surroundings

are bright (daytime, etc.) turning on the tail lights will not change the instrument cluster

brightness.

In addition, the brightness of the instrument cluster lights is automatically adjusted based

on the light sensor detecting how bright the surroundings are.

■

When disconnecting and reconnecting battery terminals
The trip meter data will be reset.

If the trip meter was displayed last, the odometer will be displayed after resetting.

■

Customization
Setting of sensitivity of the ambient light sensor used for dimming the meter lights can be

changed. (Customizable features:

P. 592)

NOTICE

■

To prevent damage to the engine and its components

●

Do not let the indicator needle of the tachometer enter the red zone, which indicates

the maximum engine speed.

●

The engine may be overheating if the engine coolant temperature gauge is in the red

zone (H). In this case, immediately stop the vehicle in a safe place, and check the

engine after it has cooled completely. (

P. 562)

Multi-information display

The multi-information display presents the driver with a variety of driving-related
data.

●

Trip information contents (

P. 91)

Displays driving range, fuel consump-

tion and other cruising related informa-

tion

●

Electronic features control contents
(

P. 92)

●

Other contents (

P. 93)

Display contents

Instrument cl

Menu switch

Changes modes to electronic features

control mode, customization mode or

back to normal display mode.

“ENTER” switch

Changes trip information items. This

switch is also used to turn on/off elec-

tronic features controls and to change

customization settings.

Trip information items displayed can be switched by pressing the “ENTER”
switch upwards or downwards.

■

Outside temperature
Displays the outside temperature

• The temperature range that can be displayed is from -40°F (-40°C) to 122°F

(50°C).

• When the outside temperature drops below 37°F (3°C), the outside temperature

display flashes several times.

■

Front tire angle
The direction of the front tires is displayed

The tire direction is displayed in 3 stages for both left and right, in accordance with

the angle of the tire.

■

Driving range
Displays the estimated maximum distance that can be driven with the quantity
of fuel remaining

• This distance is computed based on your average fuel consumption. As a result,

the actual distance that can be driven may differ from that displayed.

• When only a small amount of fuel is added to the tank, the display may not be

updated.

• When refueling, turn the engine switch off. If the vehicle is refueled without turning

the engine switch off, the display may not be updated.

■

Average fuel consumption after refueling
Displays the average fuel consumption since the vehicle was last refueled

Use the displayed average fuel consumption as a reference.

■

Current fuel consumption
Displays the current rate of fuel consumption

Switching the display

Trip information contents

■

Average fuel consumption and Eco Driving Indicator Zone Display
(

P. 94)

Displays the average fuel consumption since the function was reset

• The function can be reset by pressing the “ENTER” switch for longer than 1 second

when the average fuel consumption is displayed.

• Use the displayed average fuel consumption as a reference.

■

Average vehicle speed
Displays the average vehicle speed since the engine was started or the func-
tion was reset

The function can be reset by pressing the “ENTER” switch for longer than 1 second

when the average vehicle speed is displayed.

■

Elapsed time
Displays the elapsed time since the function was last reset

The function can be reset by pressing the “ENTER” switch for longer than 1 second

when the elapsed time is displayed.

■

Display off
A blank screen is displayed

■

Multi-terrain Select (if equipped) (

P. 312)

■

Intuitive parking assist (if equipped) (

P. 249)

■

BSM (Blind Spot Monitor) (if equipped) (

P. 361)

■

Second start mode (

P. 199)

Electronic features control contents

Instrument cl

■

Dynamic radar cruise control display

(if equipped) (

P. 232)

■

LDA (Lane Departure Alert) display

(if equipped) (

P. 243)

■

Intuitive parking assist display

(if equipped) (

P. 249)

■

Crawl Control display

(if equipped) (

P. 350)

■

Warning messages (

P. 526)

Automatically displayed when a malfunction occurs in one of the vehicles sys-
tems.

■

Customization
Settings (e.g. available language) can be changed.
(Customizable features:

P. 592)

: Automatically displayed when the system is used

■

Electronic features control can be turned on/off when
Engine switch is in IGNITION ON mode.

■

System check display
After turning the engine switch to IGNITION ON mode, “CHECKING” is displayed

while system operation is checked. When the system check is complete, the normal

screen will return.

■

Conditions for ending electronic features control
In the following situations, the electronic features control will end automatically:

●

The menu switch is pressed

●

Intuitive parking assist display starts operating

●

The Crawl Control is operated

●

The dynamic radar cruise control is operated

●

A warning message appears after the electronic features control screen is displayed

Other contents

■

Eco Driving Indicator

●

The vehicle speed is approximately 81 mph (130 km/h) or higher.

■

Outside temperature display
In the following situations, the correct outside temperature may not be displayed, or the

display may take longer than normal to change:

●

When stopped, or driving at low speeds (less than 12 mph [20 km/h])

●

When the outside temperature has changed suddenly (at the entrance/exit of a garage,

tunnel, etc.)

■

When “--” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Lexus dealer.

■

When disconnecting and reconnecting battery terminals
The following information data will be reset:

●

Average fuel consumption after refueling

●

Average fuel consumption

●

Average vehicle speed

●

Elapsed time

Eco Driving Indicator Light

During Eco-friendly acceleration (Eco driv-

ing), Eco Driving Indicator Light will turn on.
Eco Driving Indicator Zone Display

Suggests Zone of Eco driving with current

Eco driving ratio based on acceleration.
Zone of Eco driving
Eco driving ratio based on acceleration

If the vehicle exceeds Zone of Eco driving,

the right side of Eco Driving Indicator Zone

Display will blink and Eco Driving Indicator

Light will turn off.

Eco Driving Indicator Light will not operate in

the following conditions:

●

The shift lever is in anything other than D.

●

The vehicle is set to second start mode.

(

P. 199)

3
4

Instrument cl

CAUTION

■

The multi-information display at low temperatures
Allow the interior of the vehicle to warm up before using the information display. At

extremely low temperatures, the information display monitor may respond slowly, and

display changes may be delayed.

For example, there is a lag between the driver’s shifting and the new gear number

appearing on the display. This lag could cause the driver to downshift again, causing

rapid and excessive engine braking and possibly an accident resulting in death or seri-

ous injury.

■

Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that the vehicle

is parked in a place with adequate ventilation. In a closed area such as a garage,

exhaust gases including harmful carbon monoxide (CO) may collect and enter the

vehicle. This may lead to death or a serious health hazard.

NOTICE

■

During setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the dis-

play features.

Fuel consumption information

Press the “INFO”/“APPS” button, and then select “Fuel consumption”/“Eco” on
the screen.

Resetting the consumption data
Fuel consumption in the past 30
minutes
Cruising range

Average fuel consumption for the past 30 minutes is divided by color into past
averages and averages attained since the engine switch was last turned to
IGNITION ON mode. Use the displayed average fuel consumption as a refer-
ence.

The image is an example only.

■

Resetting the data
The data can be deleted by selecting “Clear”.

■

Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel

remaining.
This distance is computed based on your average fuel consumption. As a result, the

actual distance that can be driven may differ from that displayed.

Fuel consumption information can be displayed on the multimedia screen or
navigation system screen.

Operation of

each component

3-1. Key information

Keys....................................................98

3-2. Opening, closing and

locking the doors

Side doors...................................... 102
Back door....................................... 109
Glass hatch......................................114
Smart access system with

push-button start........................119

3-3. Adjusting the seats

Front seats.......................................126
Rear seats....................................... 128
Driving position memory......... 139
Head restraints .............................144

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ..............................147
Inside rear view mirror ............. 149
Outside rear view mirrors.........151

3-5. Opening, closing the windows

and moon roof

Power windows ........................... 154
Moon roof.......................................157

Keys

The following keys are provided with the vehicle.

Electronic keys

• Operating the smart access system

with push-button start (

P. 119)

• Operating the wireless remote con-

trol function

Mechanical keys
Key number plate

Locks the doors (

P. 102)

Unlocks the doors (

P. 102)

Opens the windows and moon roof

(

P. 102)

Opens the glass hatch (

P. 114)

Sounds the alarm (

P. 99)

: These settings must be customized at your Lexus dealer.

The keys

2
3

Wireless remote control

2
3

4
5

Op
era
tio

n of
ea

To take out the mechanical key, slide
the release lever and take the key out.

After using the mechanical key, store it

in the electronic key. Carry the mechan-

ical key together with the electronic key.

If the electronic key battery is depleted

or the entry function does not operate

properly, you will need the mechanical

key. (

P. 556)

■

Panic mode

■

When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. (

P. 410)

Remove the mechanical key for your own use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys
New genuine mechanical keys can be made by your Lexus dealer using another

mechanical key and the key number stamped on your key number plate. Keep the plate

in a safe place such as your wallet, not in the vehicle.

Using the mechanical key

When

is pressed for longer than about

one second, an alarm will sound intermittently

and the vehicle lights will flash to deter any per-

son from trying to break into or damage your

vehicle.
To stop the alarm, press any button on the elec-

tronic key.

100

■

When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any but-

tons on the electronic key while inside the aircraft cabin. If you are carrying an electronic

key in your bag etc., ensure that the buttons are not likely to be pressed accidentally.

Pressing a button may cause the electronic key to emit radio waves that could interfere

with the operation of the aircraft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine is stopped.

(

P. 537)

●

As the electronic key always receives radio waves, the battery will become depleted

even if the electronic key is not used. The following symptoms indicate that the elec-

tronic key battery may be depleted. Replace the battery when necessary. (

P. 489)

• The smart access system with push-button start or the wireless remote control does

not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the

following electrical appliances that produce a magnetic field:
• TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Table lamps

• Induction cookers

■

Replacing the battery
P. 489

■

Certification for the wireless remote control



For vehicles sold in the U.S.A., Hawaii, Guam, Saipan and Puerto Rico

101
