2002 ES 300 Driver s Side Front Airbag


22

(e) Using a screwdriver, disconnect the airbag

connectors.

Extra Airbag
Serial Number
Label

Airbag Serial
Number. Copy
if Extra label
not provided.
DO NOT
REMOVE!

3.  NEW AIRBAG NUMBER REGISTRATION

The new airbag will also include an extra airbag
serial number label in either of two locations.  You
are required to submit the airbag serial number
with the vehicle s VIN to assure proper
registration.  The SSC claim will be debited if this
step is not followed properly.

(a) The new airbag must be registered to the

vehicle. Remove the Extra Airbag Serial
Number Label and apply it to the

Airbag

Serial Number Registration

 postcard

supplied in the owner letter. The VIN on the
postcard must match the VIN on the vehicle.

(b) If the new airbag does not contain an extra

serial number label or the customer does
not provide the Airbag Serial Number
Registration postcard, you are required to
complete a blank postcard by hand writing
the appropriate information.

(c) Additional postcards, in packs of 50

(P/N 00410 − 92005), may be ordered
through the non−parts system on the TDN
system.
