Lexus GS300/400 (2000 year). Service manual - part 184

PP0O7–02

PP–86

–

PREPARATION

STEERING

138

LUBRICANT

Item

Capacity

Classification

Power steering fluid

Total

1.0 liters (1.1 US qts, 0.9 Imp.qts)

ATF DEXRON

®

 II or III

PP0O8–02

–

PREPARATION

STEERING

PP–87

139

SSM (Special Service Materials)

08833–00080

Adhesive 1344

THREE BOND 1344

LOCTITE 242 or equivalent

PS gear

PP0SY–01

PP–88

–

PREPARATION

SUPPLEMENTAL RESTRAINT SYSTEM

140

SUPPLEMENTAL RESTRAINT SYSTEM

SST (Special Service Tools)

09082–00700

SRS Airbag Deployment Tool

09082–00750

Airbag Deployment Wire

Sub–harness No.3

for Side Airbag Assembly

09082–00760

Airbag Deployment Wire

Sub–harness No.4

for Driver’s and Front Passenger

Airbag Assembly

09843–18020

Diagnosis Check Wire

PP28W–01

–

PREPARATION

SUPPLEMENTAL RESTRAINT SYSTEM

PP–89

141

RECOMMENDED TOOLS

09042–00010

Torx Socket T30 .

09042–00020

Torx Socket T40 .

09082–00050

TOYOTA Electrical Tester Set.

09082–00040

TOYOTA Electrical Tester.

(09083–00150)

Test Lead Set

Seat belt pretensioner connector
