PP0Q1–02

–

PREPARATION

MAINTENANCE

PP–1

53

MAINTENANCE

EQUIPMENT

Mirror

Brake hose

Torque wrench

PP0SN–01

PP–100

–

PREPARATION

AIR CONDITIONING

152

AIR CONDITIONING

SST (Special Service Tools)

07110–58060

Air Conditioner Service Tool Set

(07117–58060)

Refrigerant Drain Service Valve

(07117–58070)

T–Joint

(07117–58080)

Quick Disconnect Adapter

High pressure side

(07117–58090)

Quick Disconnect Adapter

Low pressure side

(07117–88060)

Refrigerant Charging Hose

High pressure side

(Color: Red)

(07117–88070)

Refrigerant Charging Hose

Low pressure side

(Color: Blue)

(07117–88080)

Refrigerant Charging Hose

Utility

(Color: Green)

07110–61050

Wrench Set

Expansion valve

(07111–21020)

Holder

(07111–32020)

Hexagon Wrench

5 mm (0.20 in.)

07112–66040

Magnetic Clutch Remover

–

PREPARATION

AIR CONDITIONING

PP–101

153

07112–76060

Magnetic Clutch Stopper

07114–84010

Snap Ring Pliers

07114–84020

Snap Ring Pliers

07116–38360

Gas Leak Detector Assembly

PP0SO–01

PP–102

–

PREPARATION

AIR CONDITIONING

154

RECOMMENDED TOOLS

09044–00020

Torx Socket E10 .

Compressor (GS300)

09082–00040

TOYOTA Electrical Tester.
