Controls

The headphone power indicator and controls are located
on the right ear cup.

NOTE:

The rear video system must be turned on before

sound can be heard from the headphones. To conserve
battery life, the headphones will automatically turn off
approximately three minutes after the rear video system is
turned off.

Changing the Audio Mode for Headphones

1. Ensure the Remote Control channel/screen selector

switch is in the same position as the headphone selector
switch.

NOTE:

• When both the headphone and the remote control

channel selector switches are on Channel 1, the Re-
mote is controlling Channel 1 and the headphones are
tuned to the audio on Channel 1.

• When both the headphone and the remote control

channel selector switches are on Channel 2, the Re-
mote is controlling Channel 2 and the headphones are
tuned to the audio on Channel 2.

2. Push the SOURCE button on the remote control.

3. Pushing the SOURCE button will advance to the next

mode.

4. When the Mode Selection menu appears on screen, use

the cursor buttons on the remote control to navigate to
the available modes and push the OK button to select
the new mode.

5. To cancel out of the Mode Selection menu, push the

BACK button on the remote control.

Replacing The Headphone Batteries

Each set of headphones requires two AAA batteries for
operation. To replace the batteries:

1. Locate the battery compartment on the left ear cup of

the headphones, and then slide the battery cover down-
ward.

2. Replace the batteries, making sure to orient them ac-

cording to the polarity diagram shown.

3. Replace the battery compartment cover.

528

MULTIMEDIA

Accessibility — If Equipped

Accessibility is a feature of the DVD/Blu-ray system that
announces a function prior to performing the action. For
further information refer to “Uconnect Settings” in “Mul-
timedia.”

Unwired Stereo Headphone Lifetime Limited
Warranty

Who Does This Warranty Cover?

This warranty covers the

initial user or purchaser (

⬙you⬙ or ⬙your⬙) of this particular

Unwired Technology LLC (

⬙Unwired⬙) wireless headphone

(

⬙Product⬙). The warranty is not transferable.

How Long Does the Coverage Last?

This warranty lasts as

long as you own the Product.

What Does This Warranty Cover?

Except as specified

below, this warranty covers any Product that in normal use
is defective in workmanship or materials.

What Does This Warranty Not Cover?

This warranty does

not cover any damage or defect that results from misuse,
abuse or modification of the Product other than by Un-
wired. Foam earpieces, which will wear over time through
normal use, are specifically not covered (replacement foam
is available for a nominal charge). UNWIRED TECHNOL-
OGY IS NOT LIABLE FOR ANY INJURIES OR DAMAGES

TO PERSONS OR PROPERTY RESULTING FROM THE
USE OF, OR ANY FAILURE OR DEFECT IN, THE PROD-
UCT, NOR IS UNWIRED LIABLE FOR ANY GENERAL,
SPECIAL, DIRECT, INDIRECT, INCIDENTAL, CONSE-
QUENTIAL, EXEMPLARY, PUNITIVE OR OTHER DAM-
AGES OF ANY KIND OR NATURE WHATSOEVER. Some
states and jurisdictions may not allow the exclusion or
limitation of incidental or consequential damages, so the
above limitation may not apply to you. This warranty gives
you specific legal rights. You may also have other rights,
which vary from jurisdiction to jurisdiction.

What Will Unwired Do?

Unwired, at its option, will repair

or replace any defective Product. Unwired reserves the
right to replace any discontinued Product with a compa-
rable model. THIS WARRANTY IS THE SOLE WAR-
RANTY FOR THIS PRODUCT, SETS FORTH YOUR EX-
CLUSIVE

REMEDY

REGARDING

DEFECTIVE

PRODUCTS, AND IS IN LIEU OF ALL OTHER WARRAN-
TIES (EXPRESS OR IMPLIED), INCLUDING ANY WAR-
RANTY OR MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.

If you have any questions or comments regarding your
Unwired wireless headphones, please phone 1-888-293-3332
or email customersupport@unwiredtechnology.com.

MULTIMEDIA

529

You may register your Unwired wireless headphones by
phone at 1-888-293-3332.

System Information

Disc Menu

When listening to a CD Audio or CD Data disc, pushing
the remote control’s POP UP/MENU button displays a list
of all commands which control playback of the disc.

Display Settings

When watching a video source (Blu-ray Disc or DVD Video
with the disc in Play mode, Aux Video, etc.), pushing the
remote control’s SETUP button activates the Display Set-
tings menu. These settings control the appearance of the
video on the screen. The factory default settings are already
set for optimum viewing, so there is no need to change
these settings under normal circumstances.

Video Screen Display Settings

530

MULTIMEDIA

To change the settings, push the remote control’s naviga-
tion buttons (

䉱, 䉲) to select an item, then push the remote

control’s navigation buttons (

䉴, 䉳) to change the value for

the currently selected item. To reset all values back to the
original settings, select the Default Settings menu option
and push the remote control’s ENTER/OK button.

Disc Features control the remote Blu-ray Disc player’s
settings of DVD being watched in the remote player.

Listening To Audio With The Screen Closed

To listen to only audio portion of the channel with the
screen closed:
• Set the audio to the desired source and channel.
• Close the video screen.
• To change the current audio mode, push the remote

control’s SOURCE button. This will automatically select
the next available audio mode without using the Mode/
Source Select menu.

• When the screen is reopened, the video screen will

automatically turn back on and show the appropriate
display menu or media.

If the screen is closed and there is no audio heard, verify
that the headphones are turned on (the ON indicator is

illuminated) and the headphone selector switch is on the
desired channel. If the headphones are turned on, push the
remote control’s power button to turn audio on. If audio is
still not heard, check that fully charged batteries are
installed in the headphones.

Disc Formats

The Blu-ray Disc player is capable of playing the following
types of 4.7 in (12 cm) diameter discs:
• BD: BDMV (Profile 1.1), BDAV (Profile 1.1)
• DVD: DVD-Video, DVD-Audio, AVCREC, AVCHD,

DVD-VR

• CD: CD-DA, VCD, CD-TEXT
• DVD/CD: MP3, WMA, AAC, DivX (versions 3 – 6)

profile 3.0

DVD Region Codes

The Blu-ray Disc player and many DVD discs are coded by
geographic region. These region codes must match in order
for the disc to play. If the region code for the DVD disc does
not match the region code for the player, the disc will not
play.

MULTIMEDIA

531

DVD Audio Support

When a DVD-Audio disc is inserted in the Blu-ray Disc
player, the DVD-Audio title on the disc is played by default
(most DVD-Audio discs also have a Video title, but the Video
title is ignored). All multi-channel program material is auto-
matically mixed down to two channels, which may result in
a lowered apparent volume level. If you increase the volume
level to account for this change in level, remember to lower
the volume before changing the disc or to another mode.

Recorded Discs

The Blu-ray Disc player will play CD-R and CD-RW discs
recorded in CD-Audio or Video-CD format, or as a CD-
ROM containing MP3 or WMA files. The player will also
play DVD-Video content recorded to a DVD-R or DVD-RW
disc. DVD-ROM discs (either pressed or recorded) are not
supported.

If you record a disc using a personal computer, there may
be cases where the Blu-ray Disc player may not be able to
play some or the entire disc, even if it is recorded in a
compatible format and is playable on other players. To help
avoid playback problems, use the following guidelines
when recording discs.
• Open sessions are ignored. Only sessions that are closed

are playable.

• For multi-session CDs that contain only multiple CD-

Audio sessions, the player will renumber the tracks so
each track number is unique.

• For CD Data (or CD-ROM) discs, always use the ISO-

9660 (Level 1 or Level 2), Joliet, or Romeo format. Other
formats (such as UDF, HFS, or others) are not supported.

• The player recognizes a maximum of 512 files and 99

folders per CD-R and CD-RW disc.

• Mixed media recordable DVD formats will only play the

Video_TS portion of the disc.

If you are still having trouble writing a disc that is playable
in the Blu-ray Disc player, check with the disc recording
software publisher for more information about burning
playable discs.

The recommended method for labeling recordable discs
(CD-R, CD-RW, and DVD-R) is with a permanent marker.
Do not use adhesive labels as they may separate from the
disc, become stuck, and cause permanent damage to the
DVD player.

532

MULTIMEDIA

Compressed Audio Files (MP3 and WMA)

The Blu-ray Disc player is capable of playing MP3
(MPEG-1 Audio Layer 3) and WMA (Windows Media
Audio) files from a CD Data disc (usually a CD-R or
CD-RW).
• The Blu-ray Disc player always uses the file extension to

determine the audio format, so MP3 files must always
end with the extension

⬙.mp3⬙ or ⬙.MP3⬙ and WMA files

must always end with the extension

⬙.wma⬙ or ⬙.WMA⬙.

To prevent incorrect playback, do not use these exten-
sions for any other types of files.

• For MP3 files, only version 1 ID3 tag data (such as artist

name, track title, album, etc.) are supported.

• Any file that is copy protected (such as those down-

loaded from many online music stores) will not play. The
Blu-ray player will automatically skip the file and begin
playing the next available file.

• Other compression formats such as AAC, MP3 Pro, Ogg

Vorbis, and ATRAC3 will not play. The Blu-ray player
will automatically skip the file and begin playing the
next available file.

• If you are creating your own files, the recommended

fixed bit rate for MP3 files is between 96 and 192Kbps

and the recommended fixed bit rate for WMA files is
between 64 and 192Kbps. Variable bit rates are also
supported. For both formats, the recommended sample
rate is either 44.1kHz or 48kHz.

• To change the current file, use the remote control’s or

Blu-ray Disc player’s

䉱 button to advance to the next

file, or the

䉲 button to return to the start of the current

or previous file.

Disc Errors

If the Blu-ray Disc player is unable to read the disc, a

⬙Disc

Error

⬙ message is displayed on the rear screen and Radio

displays. A dirty, damaged, or incompatible disc format are
all potential causes for a

⬙Disc Error⬙ message.

If a disc has a damaged track which results in audible or
visible errors that persists for two seconds, the Blu-ray Disc
player will attempt to continue playing the disc by skip-
ping forward one to three seconds at a time. If the end of
the disc is reached, the Blu-ray Disc player will return to
the beginning of the disc and attempt to play the start of
the first track.

The Blu-ray Disc player may shut down during extremely
hot conditions, such as when the vehicle’s interior tem-
perature is above 120° F (48.9° C). When this occurs, the

MULTIMEDIA

533

player will display

⬙High Temp⬙ and will shut off the Rear

Seat displays until a safe temperature is reached. This
shutdown is necessary to protect the optics of the Blu-ray
Disc player.

Product Agreement

This product incorporates copyright protection technology
that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technol-
ogy must be authorized by Macrovision, and is intended
for home or other limited viewing uses otherwise autho-
rized by Macrovision. Reverse engineering or disassembly
is prohibited.

Dolby Digital and MLP Lossless Manufactured un-

der license from Dolby Laboratories.

⬙Dolby⬙, ⬙MLP Loss-

less

⬙, and the double-D symbol are trademarks of Dolby

Laboratories. Confidential unpublished works. Copyright
1992-1997 Dolby Laboratories. All right reserved.

RADIO OPERATION AND MOBILE PHONES

Under certain conditions, the mobile phone being on in
your vehicle can cause erratic or noisy performance from
your radio. This condition may be lessened or eliminated
by relocating the mobile phone antenna. This condition is
not harmful to the radio. If your radio performance does

not satisfactorily “clear” by the repositioning of the an-
tenna, it is recommended that the radio volume be turned
down or off during mobile phone operation when not
using Uconnect (if equipped).

Regulatory And Safety Information

USA/CANADA

Exposure to Radio Frequency Radiation

The radiated output power of the internal wireless radio is
far below the FCC and IC radio frequency exposure limits.
Nevertheless, the wireless radio will be used in such a
manner that the radio is 20 cm or further from the human
body.

The internal wireless radio operates within guidelines
found in radio frequency safety standards and recommen-
dations, which reflect the consensus of the scientific com-
munity.

The radio manufacturer believes the internal wireless radio
is safe for use by consumers. The level of energy emitted is
far less than the electromagnetic energy emitted by wire-
less devices such as mobile phones. However, the use of
wireless radios may be restricted in some situations or

534

MULTIMEDIA

environments, such as aboard airplanes. If you are unsure
of restrictions, you are encouraged to ask for authorization
before turning on the wireless radio.

The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:

This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-
tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

NOTE:
• This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio commu-
nications. However, there is no guarantee that interfer-
ence will not occur in a particular installation.

• If this equipment does cause harmful interference to

radio or television reception, which can be determined
by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of
the following measures:

1. Increase the separation between the equipment and

receiver.

2. Consult an authorized dealer or an experienced radio

technician for help.

MULTIMEDIA

535

UCONNECT VOICE RECOGNITION QUICK TIPS

Introducing Uconnect

Start using Uconnect Voice Recognition with these helpful
quick tips. It provides the key Voice Commands and tips
you need to know to control your Uconnect 4C/4C NAV
system.

If you see the NAV icon on your touchscreen, you have the
Uconnect 4C NAV system. If not, you have a Uconnect 4C
system.

Get Started

Helpful hints for using Voice Recognition:

1. Visit UconnectPhone.com to check mobile device and

feature compatibility and to find phone pairing instruc-
tions.

2. Reduce background noise. Wind and passenger conver-

sations are examples of noise that may impact recogni-
tion.

3. Speak clearly at a normal pace and volume while facing

straight ahead. The microphone is positioned in the
headliner and aimed at the driver.

4. Each time you give a Voice Command, you must first

push either the Voice Recognition (VR) or Phone button,
wait until after the beep, then say your Voice Command.

Uconnect 4C NAV

536

MULTIMEDIA

5. You can interrupt the help message or system prompts

by pushing the VR or Phone button and saying a Voice
Command from current category.

Basic Voice Commands

The basic Voice Commands below can be given at any
point while using your Uconnect system.

Push the VR button

. After the beep, say

• Cancel to stop a current voice session
• Help to hear a list of suggested Voice Commands
• Repeat to listen to the system prompts again
Notice the visual cues that inform you of your voice
recognition system’s status. Cues appear on the touch-
screen.

Radio

Use your voice to quickly get to the AM, FM or SiriusXM
Satellite Radio stations you would like to hear. (Subscrip-
tion or included SiriusXM Satellite Radio trial required.)

Push the VR button

. After the beep, say

• Tune to ninety-five-point-five FM
• Tune to Satellite Channel Hits 1

Uconnect Voice Command Buttons

1 — Push To Initiate Or To Answer A Phone Call, Send Or Receive
A Text
2 — For All Radios: Push To Begin Radio Or Media Functions. For
8.4–inch System Only: Push To Begin Navigation, Apps And Cli-
mate Functions
3 — Push To End Call

MULTIMEDIA

537

TIP:

At any time, if you are not sure of what to say or want

to learn a Voice Command, push the VR button

and say

“Help.”

The system will provide you with a list of

commands.

Media

Uconnect offers connections via USB, Bluetooth and auxil-
iary ports (if equipped). Voice operation is only available
for connected USB and AUX devices. (Remote CD player
optional and not available on all vehicles.)

Push the VR button

. After the beep, say one of the

following commands and follow the prompts to switch
your media source or choose an artist.
• Change source to Bluetooth
• Change source to AUX
• Change source to USB
• Play artist Beethoven; Play album Greatest Hits; Play

song

Moonlight Sonata; Play genre Classical

Uconnect 4C/4C NAV With 8.4–inch Display Radio

538

MULTIMEDIA

TIP:

Press the Browse button on the touchscreen to see all

of the music on your AUX or USB device. Your Voice
Command must match exactly how the artist, album, song
and genre information is displayed.

Phone

Making and answering hands-free phone calls is easy with
Uconnect. When the Phonebook button is illuminated on
your

touchscreen,

your

system

ready.

Check

UconnectPhone.com for mobile phone compatibility and
pairing instructions.

Push the Phone button

. After the beep, say one of the

following commands

• Call John Smith
• Dial 123-456-7890 and follow the system prompts
• Redial (call previous outgoing phone number)
• Call back (call previous incoming phone number)

Uconnect 4C/4C NAV Media

MULTIMEDIA

539

TIP:

When providing a Voice Command, push the Phone

button

and say “Call,” then pronounce the name

exactly

as it appears in your phone book. When a

contact has multiple phone numbers, you can say “Call
John Smith work.”

Climate (4C/4C NAV)

Too hot? Too cold? Adjust vehicle temperatures hands-free
and keep everyone comfortable while you keep moving
ahead. (If vehicle is equipped with climate control.)

Push the VR button

. After the beep, say one of the

following commands:
• Set driver temperature to 70 degrees
• Set passenger temperature to 70 degrees

TIP:

Voice Command for Climate may only be used to

adjust the interior temperature of your vehicle. Voice
Command will not work to adjust the heated seats or
steering wheel if equipped.

Uconnect 4C/4C NAV Phone

540

MULTIMEDIA

Navigation (4C/4C NAV)

The Uconnect navigation feature helps you save time and
become more productive when you know exactly how to get
to where you want to go. (Navigation is optional on the
Uconnect 8.4 system. See your dealer to activate navigation at
any time.)
1. To enter a destination, push the VR button

. After the

beep, say:

• For the 4C Uconnect System, say: “Enter state.”

• For the 4C NAV Uconnect System, say: “Find address

800 Chrysler Drive Auburn Hills, Michigan.”

2. Then follow the system prompts.

TIP:

To start a POI search, push the VR button

. After

the beep, say: “ Find nearest coffee shop.”

Uconnect 4C/4C NAV Climate

Uconnect 4C NAV Navigation

MULTIMEDIA

541

SiriusXM Guardian (4C NAV) — If Equipped

CAUTION!

Some SiriusXM Guardian services, including SOS Call
and Roadside Assistance Call will NOT work without
an operable LTE (voice/data) or 3G or 4G (data) net-
work connection compatible with your device.

NOTE:

Your vehicle may be transmitting data as autho-

rized by the subscriber.

An included trial and/or subscription is required to take
advantage of the SiriusXM Guardian services in the next
section of this guide. To register with SiriusXM Guardian,
press the Apps button on the Uconnect 4C/4C NAV
touchscreen to get started.

NOTE:

SiriusXM Guardian is available only on equipped

vehicles purchased within the continental United States,
Alaska, Hawaii and Canada. Services can only be used
where coverage is available; see coverage map for details.

SOS Call

Theft Alarm Notification

Remote Door Lock/Unlock

Send & Go

Vehicle Finder

Stolen Vehicle Assistance

Remote Vehicle Start**

Remote Horn & Lights

Roadside Assistance Call

Vehicle Health Reports**

Vehicle Health Alert**

Performance Pages Plus**

**If vehicle is equipped.

Register (4C NAV)

To unlock the full potential of SiriusXM Guardian in your
vehicle, you must activate your SiriusXM Guardian ser-
vices.

1. Press the Apps icon on the bottom of your in-vehicle

touchscreen.

2. Select the Activate Services icon from your list of apps.

542

MULTIMEDIA

3. Select “Customer Care” to speak with a SiriusXM

Guardian Customer Care agent who will activate ser-
vices in your vehicle, or select “Enter Email” to activate
on the web.

• U.S. residents visit: www.siriusxm.com/guardian.
• Canadian residents visit: www.siriusxm.com/guardian/ca.

Vehicle Health Report/Alert (4C NAV)

Your vehicle will send you a monthly email report, which
summarizes the performance of your vehicle’s key systems so
you can stay on top of your vehicle’s maintenance needs if you
are registered for SiriusXM Guardian. Your vehicle will also
send you Vehicle Health Alerts when it detects issues with its
key systems that need your attention. For further information
go to the Owner Site website at www.mopar.com (U.S. resi-
dents) or http://owners.mopar.ca/en/ (Canadian Residents).

Mobile App (4C NAV)

You’re only a few steps away from using remote com-
mands.

To use the Uconnect App:
• Download the Uconnect App to your mobile device.
• Press the Info button on the navigation bar at the bottom

of the app for Vehicle Info.

• Press the Remote button on the navigation bar at the

bottom of the app to Lock/Unlock, Remote Start, and
activate your horn and lights remotely.

Mobile App

MULTIMEDIA

543

Content .. 32 33 34 35 ..
