Jeep Cherokee (2019 year). Manual

Daytime Running Lights (DRL) — If Equipped

The Daytime Running Lights will turn on when the engine
is started and remain on unless the headlamps are turned
on, the parking brake is applied, or the engine is shut OFF.

NOTE:

If allowed by law, in the country in which the

vehicle was purchased, the Daytime Running Lights can be
turned on and off using the Uconnect System, refer to
“Uconnect Settings” in “Multimedia” for further informa-
tion.

High/Low Beam Switch

Push the multifunction lever away from you to switch the
headlights to high beam. Pull the multifunction lever
toward you to switch the headlights back to low beam.

Automatic High Beam Headlamp Control — If
Equipped

The Automatic High Beam Headlamp Control system
provides increased forward lighting at night by automat-
ing high beam control through the use of a digital camera
mounted on the inside rearview mirror. This camera de-
tects vehicle specific light and automatically switches from
high beams to low beams until the approaching vehicle is
out of view.

NOTE:
• The multifunction lever must be in the high beam

position in order to activate the Automatic High Beams.

• The Automatic High Beam Headlamp Control can be

turned on or off using the Uconnect System. Refer to
“Uconnect Settings” in “Multimedia” for further infor-
mation.

• Broken, muddy, or obstructed headlights and taillights

of vehicles in the field of view will cause headlights to
remain on longer (closer to the vehicle). Also, dirt, film,
and other obstructions on the windshield or camera lens
will cause the system to function improperly.

Flash-To-Pass

You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward you. This
will cause the high beam headlights to turn on, and remain
on, until the lever is released.

Automatic Headlights — If Equipped

This system automatically turns the headlights on or off
according to ambient light levels. To turn the system on,
rotate the headlight switch clockwise to the last detent
(AUTO position) for automatic headlight operation. When

GETTING TO KNOW YOUR VEHICLE

the system is on, the headlight time delay feature is also on.
This means the headlights will stay on for up to 90 seconds
after you place the ignition into the OFF position. To turn
the automatic system off, move the headlight switch out of
the AUTO position.

NOTE:

The engine must be running before the headlights

will come on in the automatic mode.

Headlights On With Wipers (Available With
Automatic Headlights Only)

When this feature is active, the headlights will turn on after
the wipers are turned on if the headlight switch is placed in
the AUTO position and programmable feature is set to ON.
In addition, the headlights will turn off when the wipers
are turned off if they were turned on by this feature.

NOTE:

The Headlights On with Wipers feature can be

turned on or off using the Uconnect System. Refer to
“Uconnect Settings/Customer Programmable Features” in
“Multimedia” for further information.

Headlight Time Delay

This feature provides the safety of headlight illumination
for up to 90 seconds (programmable) when leaving your
vehicle in an unlit area.

To activate the delay feature, place the ignition in the OFF
position while the headlights are still on. Then, turn off the
headlights within 45 seconds. The delay interval begins
when the headlight switch is turned off.

NOTE:

The headlight delay feature is automatically acti-

vated if the customer leaves the headlight switch in the
AUTO position while the ignition is placed in the OFF
position.

If you turn the headlights or parking lights on, or place the
ignition in ACC or RUN, the system will cancel the delay.

If you turn the headlights off before the ignition, they will
turn off in the normal manner.

NOTE:
• The lights must be turned off within 45 seconds of

placing the ignition in the OFF position to activate this
feature.

• The headlight delay time is programmable using the

Uconnect System, refer to “Uconnect Settings” in “Mul-
timedia” for further information.

GETTING TO KNOW YOUR VEHICLE

Lights-On Reminder

If the headlights or parking lights are on after the ignition
is in the OFF position, a chime will sound to alert the driver
when the driver’s door is opened.

Fog Lights — If Equipped

The front fog light switch is built into the headlight switch.

To activate the front fog lights, turn on the parking lights or
the low beam headlights and push the headlight switch. To
turn off the front fog lights, either push the headlight
switch a second time or turn off the headlight switch.

An indicator light in the instrument cluster illumi-
nates when the fog lights are turned on.

NOTE:

The fog lights will operate with the low beam

headlights or parking lights on. However, selecting the
high beam headlights will turn off the fog lights.

Turn Signals

Move the multifunction lever up or down and the arrows on
each side of the instrument cluster display will flash to show
proper operation of the front and rear turn signal lights.

NOTE:
• If either light remains on and does not flash, or there is

a very fast flash rate, check for a defective LED turn
signal in the headlamp. Please see an authorized dealer
for service.

• A “Turn Signal On” message will appear in the instru-

ment cluster display and a continuous chime will sound
if the vehicle is driven more than 1 mile (1.6 km) with
either turn signal on.

• When the Daytime Running Lights are on and a turn

signal is activated, the Daytime Running Lamp will turn
off on the side of the vehicle in which the turn signal is
flashing. The Daytime Running Lamp will turn back on
when the turn signal is turned off.

Fog Light Switch

GETTING TO KNOW YOUR VEHICLE

Lane Change Assist — If Equipped

Tap the multifunction lever up or down once, without
moving beyond the detent, and the turn signal (right or
left) will flash three times then automatically turn off.

Battery Saver

To protect the life of your vehicle’s battery, load shedding
is provided for both the interior and exterior lights.

If the ignition is OFF and any door is left ajar for 10 minutes
or the dimmer control is rotated all the way up to the dome
on position for 10 minutes, the interior lights will automati-
cally turn off.

NOTE:

Battery saver mode is canceled if the ignition is

ON.

If the headlights remain on while the ignition is cycled OFF,
the exterior lights will automatically turn off after eight
minutes. If the headlights are turned on and left on for
eight minutes while the ignition is OFF, the exterior lights
will automatically turn off.

INTERIOR LIGHTS

The interior lights come on when a door is opened.

To protect the battery, the interior lights will turn off
automatically 10 minutes after the ignition is placed in the
OFF position. This will occur if the interior lights were
switched on manually or are on because a door is open.
The Battery Protection also includes the glove compart-
ment light and the cargo light. To restore interior light
operation after automatic battery protection is enabled
(Lights Off), either place the ignition in the ON/RUN
position or cycle the light switch.

GETTING TO KNOW YOUR VEHICLE

Interior Courtesy Lights

Front Map/Reading Lights

The front map/reading lights are mounted in the overhead
console. Each light can be turned on by pushing a switch
on either side of the console. To turn the lights off, push the
switch a second time. These lights also turn on when a door
is opened, or when the unlock button on the key fob is
pushed, or when the dimmer control is turned completely
upward to the second detent.

Instrument Panel Dimmer Control

The instrument panel dimmer control is part of the head-
light switch and is located on the driver’s side of the
instrument panel.

With the parking lights or headlights on, rotating the
instrument panel dimmer control upward will increase the
brightness of the instrument panel lights and lighted
cupholders — if equipped.

Front Map/Reading Light Switches

Instrument Panel Dimmer

GETTING TO KNOW YOUR VEHICLE

Dome Light Position

Rotate the instrument panel dimmer control completely
upward to the second detent to turn on the interior lights.
The interior lights will remain on when the instrument
panel dimmer control is in this position.

Ambient Light Control — If Equipped

Rotate the ambient dimmer control upward or downward
to increase or decrease the brightness of the ambient light
located in the overhead console, door handle lights, under
I/P lights, door map pocket lights, and cubby bin lights.

Interior Light Defeat (Off)

Rotate the instrument panel dimmer control to the extreme
bottom (O) off position. The interior lights will remain off
when the doors are open.

Parade Mode (Daytime Brightness Feature)

Rotate the instrument panel dimmer control upward to the
first detent. This feature brightens all text displays such as
the odometer, instrument cluster display, and radio when
the position lights or headlights are on.

Ambient Light/Door Handle Light Dimmer

GETTING TO KNOW YOUR VEHICLE

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer controls are located on the
windshield wiper/washer lever on the right side of the
steering column. The front wipers are operated by rotating
a switch, located on the end of the lever. For information on
the rear wiper/washer, refer to “Rear Window Features” in
this section.

Windshield Wiper Operation

Rotate the end of the lever to one of the first four detent
positions for intermittent settings, the fifth detent for low
wiper operation and the sixth detent for high wiper operation.

CAUTION!

Always remove any buildup of snow that prevents the
windshield wiper blades from returning to the “park”
position. If the windshield wiper switch is turned off,
and the blades cannot return to the “park” position,
damage to the wiper motor may occur.

Windshield Wiper/Washer Lever

Windshield Wiper Operation

GETTING TO KNOW YOUR VEHICLE

Windshield Washer Operation

To use the washer, pull the lever rearward toward you and
hold while spray is desired. If the lever is pulled while in
the intermittent setting, the wipers will turn on and operate
for several wipe cycles after the lever is released, and then
resume the intermittent interval previously selected.

If the lever is pulled while the wipers are in the off position,
the wipers will operate for several wipe cycles, then turn
off.

WARNING!

Sudden loss of visibility through the windshield could
lead to a collision. You might not see other vehicles or
other obstacles. To avoid sudden icing of the wind-
shield during freezing weather, warm the windshield
with the defroster before and during windshield
washer use.

Mist

Use the Mist feature when weather conditions make occa-
sional usage of the wipers necessary. Push the lever up-
ward to the MIST position and release for a single wiping
cycle.

Windshield Washer Operation

GETTING TO KNOW YOUR VEHICLE

NOTE:

The mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on the
windshield. The wash function must be used in order to
spray the windshield with washer fluid.

Intermittent Wiper System

Use one of the four intermittent wiper settings when
weather conditions make a single wiping cycle, with a
variable delay between cycles, desirable. At driving speeds
above 10 mph (16 km/h), the delay can be regulated from
a maximum of approximately 18 seconds between cycles
(first detent), to a cycle every one second (fourth detent).

NOTE:

If the vehicle is moving less than 10 mph

(16 km/h), delay times will be doubled.

Rain Sensing Wipers — If Equipped

This feature senses rain or snowfall on the windshield and
automatically activates the wipers for the driver. The
feature is especially useful for road splash or overspray
from the windshield washers of the vehicle ahead. Rotate
the end of the multifunction lever to one of four settings to
activate this feature.

Mist Control

Intermittent Wiper Operation

GETTING TO KNOW YOUR VEHICLE

The sensitivity of the system can be adjusted with the
multifunction lever. Wiper delay position one is the least
sensitive, and wiper delay position four is the most sensi-
tive.

NOTE:

Setting three should be used for normal rain

conditions.

Settings one and two can be used if the driver desires less
wiper sensitivity. Setting four can be used if the driver
desires more sensitivity. Place the wiper switch in the OFF
position when not using the system.

NOTE:
• The Rain Sensing feature will not operate when the

wiper switch is in the low or high-speed position.

• The Rain Sensing feature may not function properly

when ice or dried salt water is present on the wind-
shield.

• Use of Rain-X or products containing wax or silicone

may reduce Rain Sensing performance.

• The Rain Sensing feature can be turned on and off using

the Uconnect System, refer to “Uconnect Settings” in
“Multimedia” for further information.

The Rain Sensing system has protection features for the
wiper blades and arms, and will not operate under the
following conditions:
• Low Ambient Temperature — When the ignition is first

turned ON, the Rain Sensing system will not operate
until the wiper switch is moved, vehicle speed is greater
than 3 mph (5 km/h) or the outside temperature is
greater than 32°F (0°C).

• Transmission In NEUTRAL Position — When the igni-

tion is ON, and the automatic transmission is in the
NEUTRAL position, the Rain Sensing system will not
operate until the wiper switch is moved, vehicle speed is
greater than 3 mph (5 km/h) or the gear selector is
moved out of the NEUTRAL position.

Remote Start Mode Inhibit

— On vehicles equipped with

Remote Starting system, Rain Sensing wipers are not
operational when the vehicle is in the remote start mode.
Once the operator is in the vehicle and has placed the
ignition switch in the RUN position, rain sensing wiper
operation can resume, if it has been selected, and no other
inhibit conditions (mentioned previously) exist.

GETTING TO KNOW YOUR VEHICLE

Rear Window Wiper/Washer

The rear wiper/washer controls are located on the wind-
shield wiper/washer lever on the right side of the steering
column. The rear wiper/washer is operated by rotating a
switch, located at the middle of the lever.

Rotate the center portion of the lever upward to the
first detent for intermittent operation and to the

second detent for continuous rear wiper operation.

To use the washer, push the lever forward and
hold while spray is desired. If the lever is pushed
while in the intermittent setting, the wiper will

turn on and operate for several wipe cycles after the end of
the lever is released, and then resume the intermittent
interval previously selected.

If the lever is pushed while the wiper is in the off position,
the wiper will operate for several wipe cycles, then turn off.

NOTE:

As a protective measure, the pump will stop if the

switch is held for more than 20 seconds. Once the lever is
released the pump will resume normal operation.

If the rear wiper is operating when the ignition is turned
OFF, the wiper will automatically return to the “park”
position.

Windshield Wiper De-Icer — If Equipped

Your vehicle may be equipped with a Windshield Wiper
De-Icer feature that may be activated under the following
conditions:
• Activation By Front Defrost — The Windshield Wiper

De-Icer shall be activated automatically in the case of a
cold weather manual start with full front defrost, and
when the ambient temperature is below 33° F (0.6° C).

Rear Wiper/Washer Control

GETTING TO KNOW YOUR VEHICLE

• Activation By Rear Defrost — The Windshield Wiper

De-Icer shall be activated automatically when the rear
defrost is turned on and when the ambient temperature
is below 33° F (0.6° C).

• Activation By Remote Start Operation — When remote

start is active and the outside ambient temperature is
less than 33° F (0.6° C), the Windshield Wiper De-Icer
shall be enabled. On exiting remote start resume previ-
ous operation except, if the Windshield Wiper De-Icer
timer and operation shall continue.

CLIMATE CONTROLS

Manual Climate Control Without A Touchscreen
Overview

The controls for the manual heating and air conditioning
system in this vehicle consist of a series of outer rotary
dials and inner push knobs. These comfort controls can be
set to obtain desired interior conditions.

Manual Climate Controls Without A Touchscreen

GETTING TO KNOW YOUR VEHICLE

Manual Climate Control Without A Touchscreen Descriptions

Icon

Description

Blower Control
Use this control to regulate the amount of air forced through the system in any mode you select.
The blower speed increases as you move the control clockwise from the off position.

Temperature Control
Use this control to regulate the temperature of the air inside the passenger compartment. Rotat-
ing the knob counterclockwise, from top center into the blue area of the scale, indicates cooler
temperatures. Rotating the knob clockwise, into the red area, indicates warmer temperatures.
Modes Control Knob
Turn the knob to adjust airflow distribution. The airflow distribution mode can be adjusted so
air comes from the instrument panel outlets, floor outlets, defrost outlets and demist outlets.

Panel Mode

Panel Mode
Air comes from the outlets in the instrument panel. Each of these outlets can be individually
adjusted to direct the flow of air. The air vanes of the center outlets and outboard outlets can be
moved up and down or side to side to regulate airflow direction. There is a shut off wheel lo-
cated below the air vanes to shut off or adjust the amount of airflow from these outlets.

Bi-Level Mode

Bi-Level Mode
Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed
through the defrost and side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort conditions to provide cooler air out of the

panel outlets and warmer air from the floor outlets.

GETTING TO KNOW YOUR VEHICLE

Icon

Description

Floor Mode

Floor Mode
Air comes from the floor outlets. A slight amount of air is directed through the defrost and side
window demister outlets.

Mix Mode

Mix Mode
Air is directed through the floor, defrost, and side window demister outlets. This setting works
best in cold or snowy conditions that require extra heat to the windshield. This setting is good
for maintaining comfort while reducing moisture on the windshield.

A/C Button
Push the A/C button to engage the Air Conditioning (A/C). A LED will illuminate when the
A/C system is engaged.

MAX A/C Setting
Turn the temperature control knob to the MAX Air Conditioning (A/C) setting to engage MAX
Air Conditioning (A/C). This is the coldest setting.

Recirculation Button
Press and release this button on the touchscreen, or push the button on the faceplate, to change
the system between recirculation mode and outside air mode. Recirculation can be used when
outside conditions, such as smoke, odors, dust, or humidity are present. Recirculation can be
used in all modes. The A/C can be deselected manually without disturbing the mode control
selection. Continuous use of the Recirculation mode may make the inside air stuffy and window
fogging may occur. Extended use of this mode is not recommended.

GETTING TO KNOW YOUR VEHICLE

Icon

Description

Front Defrost Setting
Turn the Mode Control knob to the Front Defrost position. Air comes from the windshield and
side window demist outlets. Use Defrost mode with maximum temperature settings for best
windshield and side window defrosting and defogging.
Rear Defrost Button
Push and release the Rear Defrost Control button to turn on the rear window defroster and the
heated outside mirrors (if equipped). An indicator will illuminate when the rear window de-
froster is on. The rear window defroster automatically turns off after ten minutes.

GETTING TO KNOW YOUR VEHICLE

Economy Mode

If ECONOMY mode is desired, push the A/C button to
turn off the LED indicator and the A/C compressor. Rotate
the temperature control knob to the desired temperature.
Also, make sure to select only Panel, Bi-Level, or Floor
modes.

Stop/Start System — If Equipped

While in an Autostop, the Climate Controls system may
automatically adjust airflow to maintain cabin comfort.
Customer settings will be maintained upon return to an
engine running condition.

Windshield Wiper De-icer — If Equipped

The windshield wiper de-icer is a heating element located
at the base of the windshield.

It operates automatically once the following conditions are
met:
• Activation By Front Defrost

The wiper de-icer activates automatically during a cold
weather manual start with full defrost, and when the
ambient temperature is below 33° F (0.6° C)

• Activation By Rear Defrost

The wiper de-icer activates automatically when the Rear
Defrost is operating and the ambient temperature is below
33° F (0.6° C)

• Activation By Remote Start Operation

When the Remote Start is activated and the outside ambi-
ent temperature is less than 33° F (0.6° C)

the windshield

wiper de-icer is activated. Upon exiting Remote Start, the
climate control functions will resume their previous opera-
tion except, if the de-icer is active, the de-icer timer and
operation will continue.

GETTING TO KNOW YOUR VEHICLE

Jeep Cherokee (2019 year). Manual - part 5
