Tightening Torques – 2.0 Liter Diesel Engine Components

107

Notes

To convert Nm to lbf ft:

Divide the Nm torque figure by 1.356

Oil Pan

Pre-torque to 7 Nm and tighten to 14 Nm in sequence

shown.

Oil Pan Drain Plug

23 Nm

Oil Pick-up Pipe

10 Nm

Oil Pressure Switch

15 Nm

Oil Pump

10 Nm

Piston Cooling Jet

10 Nm

Power Steering Pump to Coolant Pump

18 Nm

Component

Torque

Tightening Torques – 2.0 Liter Diesel Engine Components

108

Notes

To convert Nm to lbf ft:

Divide the Nm torque figure by 1.356

Rocker Shaft

13 Nm + 45 degrees (always use new bolts)

Stiffening frame

23 Nm – Tighten in sequence shown.

Thermostat Housing to Vacuum Pump

23 Nm

Timing Chain Guides

16 Nm

Timing Chain Tensioner

14 Nm

Timing Chain Tensioner Blade

14 Nm

Vacuum Pump to Engine

23 Nm

Component

Torque

Tightening Torques and Sequence – Cylinder Heads

109

Notes

V8 Engine
Tightening Torques in Nm and Degrees of Rotation
Cylinder head bolts can be used twice, for reference purposes mark for re-use.

Step

Apply each step in sequence shown:

1

Tighten bolts 1 to 10 to 20 Nm

2

Tighten bolts 1 to 10 to 35 Nm

3

Tighten bolts 1 to 10, 90 degrees

4

Tighten bolts 1 to 10, 90 degrees

5

Tighten bolts marked Y to 23 Nm

Bank 1

Bank 2

To convert Nm to lbf ft:

Divide the Nm torque figure

by 1.356

front of engine

J.303.1544

10

6

1

3

7

8

4

2

9

5

Y

J.303.1545

9

5

2

4

8

7

3

1

10

6

Y

Tightening Torques and Sequence – Cylinder Heads

110

Notes

V6 Engine
Tightening Torques in Nm and Degrees of Rotation
Use new bolts and washers.

Step

Apply each step in sequence shown to both cylinder heads.

1

Tighten to 30 Nm

2

Tighten 90 degrees

3

Loosen 360 degrees

4

Tighten to 30 Nm

5

Tighten 90 degrees

6

Tighten 90 degrees

To convert Nm to lbf ft:

Divide the Nm torque figure by 1.356

front of engine

1

3

4

2

6

7

8

5
