Parking aid
R
Parking aid
PRINCIPLE OF OPERATION
The Park Assist System provides the
driver with information on most
obstructions, and their distance from the
vehicle, when manoeuvring. This is
achieved by using four ultrasonic sensors
on each bumper.
When objects are detected the Park
Assist System will emit an audible
warning tone which increases in
frequency as the vehicle gets closer to
the object.
The Park Assist System is automatically
in standby when the ignition system is on.
USING THE PARKING AID
Touch-screen
To set the preferences of the parking
assist, the settings are accessed via the
touch-screen Home screen and Veh.
settings.
Select Parking.
There is a link to Vol. presets in order
that the volume of the parking assist
warning beeps may be adjusted.
Note: The volume adjusts both front and
rear speaker volume.
WARNINGS
It remains the driver’s
responsibility to be vigilant when
reversing. Small children or
animals may not be detected by the
system.
It remains the driver’s
responsibility to detect obstacles
and estimate the car’s distance
from them. Some overhanging objects,
barriers, thin obstructions or painted
surfaces which could possibly cause
damage to the vehicle may not be
detected by the system. Always be
vigilant when reversing.
CAUTIONS
Once the system has been
activated by selecting reverse or
using the switch, the front and rear
sensors are active when the gear
selector is in neutral. Therefore, if an
obstacle is detected an audible warning
tone will sound.
Objects moving away from the
vehicle will be reported. However,
whilst driving away, object warning
may be temporarily reported due to
ground reflection.
mirror dip
Vol. presets
Off
On
Vehicle
Security
Parking
Valet mode
Reverse
12 : 26 pm
