Crankshaft damper holding tool 303-D055
Assembly
1 .
CAUTION: Use only a plastic scraper when removing old gasket material.
Clean all the mating faces and reusable parts thoroughly and check for damage.
• If gasket material remains on the cylinder head after cleaning, use a plastic tipped scraper to remove remaining material.
2 . NOTE:
Never remove pipe plugs or alignment dowels unless they are to be serviced.
Reseal oil passage blanking plugs, as necessary.
3 . NOTE:
The main bearings are precision selective fit.
NOTE:
Lubricate the upper crankshaft main bearings and thrust washers.
Install the upper crankshaft main bearings. |
