Air conditioner
Automatic temperature control system
Your vehicle is equipped with automatic
temperature control system. This system
allows you to control the refrigeration,
heating and ventilation of vehicle.
Below is the display screen of tempera鄄
ture control system: A. External temper鄄
ature (ambient temperature)
B. Defroster indicator
C. Air allocation mode indicator
D. AUTO mode indicator
E. Compressor switch indicator
F. External circulation mode indicator
G. Internal circulation mode indicator
H. Selected temperature (internal tem鄄
perature)
I. Fan working indicator
J. Fan speed indicator
Automatic operation
Set automatic operation as following:
AUTO (automatic): press AUTO button
to enable automatic control over internal
air temperature, air delivery mode and
fan speed. Then, the AUTO mode indi鄄
cator will present on the display.
OFF: press this button to shut down the
system.
Set the desired temperature according
to the following procedures:
1. Press AUTO button.
2. Turn the temperature control button
until the desired temperature appears
on the display screen. You can set the
desired temperature between 17益 and
32益.
3. Turn the knob clockwise, you can
raise the temperature by 0.5益. Turn the
knob counterclockwise, you can reduce
the desired temperature by 0.5益.
Instruction operation
(Fan) Turn the fan control button
(center control button) clockwise, you
can increase the fan speed; anticlock鄄
wise could reduce the fan speed. When
this button is turned, AUTO mode will
be cancelled. You can select the fol鄄
lowing modes by turning the control but鄄
ton near the second driver's seat:
(Instrument panel mode): this mode
will allow the air to flow to the instrument
panel air outlet.
(Double -function mode): this mode
will allow about half air to flow to instru鄄
ment panel air outlet and the rest air to
flow to the floor air outlet.
(Floor mode): this mode will allow
most air to flow to the floor air outlet. If
your vehicle is equipped with rear air
outlet, a portion of airflow will be guided
to it as well. Make sure there is no obsta鄄
cle under the front seat so as to allow
clear airflow to the compartment tail.
Demisting mode can be selected by
mode button. For information on demist鄄
ing and defrosting, refer to the following
in this chapter.
(Internal circulation mode): This
mode will prevent external air and ab鄄
normal taste entering the vehicle or
raise or reduce internal air temperature
faster.
Press this button, you can start or shut
down internal circulation mode.
Long term use of internal circulation
mode will result in mist on the window. If
there is mist on the window, please se鄄
lect defrosting mode.
Notes
Don't cover the right sunshine sensor at
right defrosting bar rack on the instru鄄
ment panel. To learn about the sun鄄
shine sensor in details, refer to the fol鄄
lowing section of Sensor in this chapter.
