Front and Rear Bumper
Front and Rear Bumper
69 IV、Fixed Bracket of Front Bumper
(I)Removal
1. Open engine compartment cover 2. Disconnect battery negative electrode 3. Remove upper cover plate of front bumper Refer to "Upper cover plate of front bumper" 4. Remove front bumper assembly Refer to "Front bumper assembly" 5. Remove fixed bracket of front bumper 1). Remove fixed bolt ① and fixed bolt ② of fixed bracket of front bumper, disconnect buckle, and take down fixed bracket of front bumper;
(II)Installation
1. Install fixed bracket of front bumper 1). Place fixed bracket of front bumper to installation position, and tighten fixed bolts ① Tighten torque 9~11N·m
2). Tighten the other fixed bolt ② of fixed bracket of front bumper; Tighten torque 9~11N·m 2. Install front bumper assembly 3. Install upper cover plate of front bumper 4. Connect battery negative electrode 5. Close engine compartment cover
|
