1. Temp. control knob
3. Air inlet control bar
2. Fan flow knob
4. Air outlet control knob
36
OWNER爷S MANUAL
JAC High end Light Trucks
Air outlet control knob
Use different knobs to regulate the air from the heater, defroster and the air
conditioner, or the air flow out of the ventilation outlet.
淤Plane air outlet
于Dual planes
盂Bottom air outlets
榆Bottom air outlet and defroster
虞Defroster
Plane air outlet
Air is regulated when it passes the system, and is vented from the upper air outlet.
This position is used for most of the air conditioning cases.
