A- repeated short distance drive
B- persistent idling or long time intermittent drive
C- drive under dusty conditions
D- drive on road with salt content or corrosive substance,
or in very cold weather
E- drive on sandy ground
F- drive in crowded traffic in about 50% cases and with
ambient temperature over 90 (32益)
G- drive down slope
H- hauling
I- the vehicle is used for patrol by police, taxi, commer鄄
cial vehicle or hauling
J- drive at a speed over 170km/h
Maintenance in severe environment
The replacement mileage/ time of engine oil and oil filter and gearbox oil must be shortened if your vehicle drives in one
or more of the following conditions. Other maintenance will follow the items for ordinary driving conditions.
R: Replace
I: inspection, with necessary cleaning, adjustment, repair or replacement after the inspection.
Maintenance item
Maintenance operation
Maintenance interval
Driving condition
Engine oil and oil filter
R
Every 5000KM or 3 months
A, B, C, F, H, J
Air filter
R
More frequently
C, E
Spark plug
R
More frequently
B, H
Timing belt
R
Every 4000KM or 24 months
D, E, F, G
Braking lining/ clamp/ disc/ drum/ parking brake
I
More frequently
C, D, G, H
Power steering gear, linking device and dust hood
I
Every 10000KM or 6 months
C, D, E, F
Driving shaft and sleeve
I
Every 15,000KM or 12 months
C, D, E, F
Air conditioning filter (for vaporizer and blower)
R
More frequently
C, E
Manual gearbox oil
R
Every 4000KM or 24 months
A, C, D, E, F, G, H, I, J
Transfer case oil and main reducer oil (4WD)*1
R
Every 4000KM or 24 months
C, E, G, I
Vehicle maintenance requirements
104
*1: The transfer case oil and main reducer oil transfer case should be replaced in time if water has entered into oil.
Severe conditions:
Description of periodical mainte鄄
nance items
音 Engine oil and filter
The engine oil and filter should be
replaced according to the mainte鄄
nance schedule. Such replacement
shall be made frequently when the
vehicle is running under severe con鄄
ditions.
音 Driving belt
Avoid thread breaking, cracking, ex鄄
cessive wearing or oil contact with
the belt. Check all driving belts and
replace them when necessary. To
keep the belt tension, the belt should
be checked periodically and adjust鄄
ed when necessary.
音 Fuel filter
A faulty filter could limit the speed,
damage the exhaust system and re鄄
sult in difficult starting. The filter
should be replaced frequently if
there is excessive foreign substance
accumulated in the fuel tank.
After installing a new filter, start the
engine and check the connection for
oil leakage. The fuel filter should be
installed by trained technical person鄄
nel.
音 Inspection of fuel piping
Check the fuel hose and connection
piping for oil leakage or damage.
Damaged or leaking part should be
replaced by trained technical person鄄
nel.
音 Timing belt
To prevent damage or deformation of
timing belt, check all associated ac鄄
cessories. Immediately replace dam鄄
aged accessories.
音 Purge line and fuel filter
Check the purge line and fuel filter
as per the maintenance schedule.
Determine the purge line and fuel fil鄄
ter. Confirm that the purge line and
fuel filter have been replaced.
音 Vacuum and crankshaft case
Ventilation duct
Check if the surface of ventilation
duct has become hot or damaged
mechanically.
Caution:
音 Never bring the duct surface
close to devices with high tem鄄
perature, such as exhaust mani鄄
fold. Inspect the piping and de鄄
