22
tion switch. The first position turns
on the parking lights, sidelights,
taillights and instrument panel
lights. The second position turns
on the headlights.
High-beam and Low-beam
To turn on the headlight high
beams, push the lever upward. For
low beams, pull the lever down.
The appropriate headlight beam in鄄
dicator light will come on at the
same time.
Passing switch
The headlights will be flashed
when the lever is pushed upward
and release automatically. The
headlights can be flashed even
though the headlight switch is in
the "OFF" position.
WINDSHIELD WIPER
The windshield wiper switch has
three positions:
INT: Intermittent wiper operation
LO : Low-speed operation
HI : High-speed operation
NOTE:
This function is operated when
the headlight switch is in the "
ON" position.
NOTE:
To prevent damage to the wiper
system, do not attempt to wipe
away heavy accumulations of
snow or ice.
Accumulated snow and ice
should be removed manually, If
there is only a light layer of snow
or ice, operate the heater in the
defrost mode to melt the snow or
ice before using the wiper.
INSTRUMENTS & CONTROLS
23
WINDSHIELD WASHER OPER鄄
ATION
To use the windshield washer,
press in on the button on the end
of the wiper/washer lever. When
the washer button is pressed, the
wipers automatically make two
passes across the windshield, And
the windshield wiper is operated 2
to 3 times at the same time, The
washer continues to operate as
long as the button is depressed.
EXHAUST BRAKE SWITCH
To use the exhaust brake, put the
"ON" position. The exhaust brake
operates when you remove your
foot from the accelerator pedal and
the clutch pedal. The exhaust
brake will not operate automatically
if you operate the accelerator ped鄄
al or the clutch pedal.
Use exhaust brake when going
down a slope.
HAZARD WARNING
The hazard warning lamp should
CAUTION:
荫 Do not use the wiper when
the windshield is dry.
荫 The washer button should
not be pressed if the washer
reservoir is empty. This can
damage the washer fluid pump.
Do not operate the washer for
more than 15 seconds at a
time.
