Appendix 3: Oil type in lubrication Symbol in the table Illustration B L-BCD4 Diesel engine oil GB11123渊Summer冤袁LECD30 Diesel engine oil GB11123渊Winter冤 J 15W/20 or 15W/40 Thickened oil G GB49 2# Calcium base grease ZL GB5671 Lithium base grease Q Half of HU-20# gasoline engine oil渊GB2537冤and half of 45# transformer oil渊GB2536冤 Y Brake fluid JG3渊GB10830冤 Z Medium-load vehicle gear oil渊GL-4冤85W/90 D L-HM46渊GB11119冤(0益 above)袁antiwear hydraulic oil L-LM32渊GB11119冤(0益 below) 106 OWNER爷S MANUAL for HFC1061,HFC1063,HFC1083 series trucks Appendix 4: Tightening torques of main tightening parts渊for reference冤 No. 1 Name Unit院N.M(KGLF.M) Ball pin nuts of steering tie-rod 186依20渊19依2冤 Nuts connecting transmission and clutch casing 68.8-93.2渊7-9.5冤 Flange nuts of intermediate steering shaft 343-539渊35-55冤 Nuts on tyre 196-245渊20-25冤 Flange nuts of driving gear 220-250渊23-25.5冤 Fixing nuts of steering drag rod 441依49渊45依5冤 Front U-bolts 250 8 Rear U-bolts 350 9 Fixing nuts of steering gear 68.8-88.2渊7-9冤 10 Fixing nuts of steering bend arm 441依49渊45依5冤 11 Fixing nuts of steering wheel 49-78.4渊5-8冤 12 Flange of transmission >166.7渊17冤 13 Nuts of pitman arm shaft 196-235.2渊20-24冤 107 |
